Assembly Instructions
Caution: You should read this carefully before you proceed
Please look in the dummy box for hardware packs.
UMBRELLA BASE
CAUTION: This Umbrella Base is NOT a TOY.
Keep your child/children at bay during the assembly process.
Whenever lifting or moving the Umbrella Base and to prevent any damage to it, two adults may be
needed to execute these actions.
Noble House Home Furnishings LLC
PAGE 1 of 6
Advertisement
Table of Contents
Related Manuals for Noble House Home Furnishings UMBRELLA BASE
Summary of Contents for Noble House Home Furnishings UMBRELLA BASE
- Page 1 CAUTION: This Umbrella Base is NOT a TOY. Keep your child/children at bay during the assembly process. Whenever lifting or moving the Umbrella Base and to prevent any damage to it, two adults may be needed to execute these actions.
- Page 2 Part List Label Picture Description Base Wheel Tube Hardware Label Picture Description Washer ① (80x12x2mm) Adapter 1 ② (59x10mm) Adapter 2 ③ (53x26mm) Washer ④ (M8.5/20x2mm) Spanner ⑤ (F13)
- Page 3 FRONT FACING This Umbrella Base has multiple parts and may require up to 20 minutes to assemble. To give you an overview of the Umbrella Base parts, the above picture is provided to help you put the various parts into perspective. Please read through the instructions below to familiarise yourself with the parts and steps before assembly.
- Page 4 Insert the Washer (② ), the Adapter 1 (② ), and the Tube (C) into the Base (A) in order, then turn the Tube (C) clockwise as shown in the picture above. Noble House Home Furnishings LLC PAGE 4 of 6...
- Page 5 Adapter 2 (③), tighten/loosen the knobs on the tube (C) to make sure the umbrella stick properly fits inside the Tube (C) as shown in the pictures above. Step 5.2: Lock or Unlock the Wheels (B) in order to affix the umbrella base in place or move it around as shown in the pictures above.
- Page 6 • Where can I get more information on Proposition 65? If you have specific questions on the administration or implementation of Proposition 65, you can contact OEHHA's Proposition 65 program at P65.Questions@oehha.ca.gov, or by phone at (916) 445-6900. Noble House Home Furnishings LLC PAGE 6 of 6...
