Caution : You must read this before you proceed
Read all instructions before assembling and using this product.
1. Select ideal location. Set out all parts on a clear and level surface prior to assembly.
Ideally, the Gazebo should be set up in the desired location to avoid moving it after
assembly.
2. Team Work. We recommend 4-5 adults and it may require 3 to 4 hours to fully
assemble the Gazebo. If possible, please use safety ladders.
3. Use caution. During the entire assembly process, especially when lifting heavy or
large parts or using ladders, pay attention to safety. No one other than the adult
assistants should be allowed in the work area.
4. Check all available parts. Before assembling your Gazebo Frame, make sure that you
have all the parts described in the Parts List.
5. Ensure that ALL BOLTS and NUTS are fully and securely tightened before you
proceed to attach the Canopies.
6. Keep children away. Children shouldn't be allowed in the work area. Do not let them
handle parts and tools. Do not allow children to climb the Gazebo.
Gazebo
Page 1 OF 11
Noble House Home Furnishings LLC
Advertisement
Related Manuals for Noble House Home Furnishings Gazebo
Summary of Contents for Noble House Home Furnishings Gazebo
- Page 1 Read all instructions before assembling and using this product. 1. Select ideal location. Set out all parts on a clear and level surface prior to assembly. Ideally, the Gazebo should be set up in the desired location to avoid moving it after assembly.
- Page 2 Long Corner Roof Bar Column Short Roof Bar Top Connector Base Side Panel Top Connector Side Panel Bottom Connector Decorative Ball Canopy Curtain Mosquito Netting Corner Brace Hang Tube Clip Sidewall Hang Tube Page 2 OF 11 Noble House Home Furnishings LLC...
- Page 3 ① Bolt (M6*15mm) ② Bolt (M6*25mm) ③ Bolt (M6*70mm) ④ Bolt (M6*75mm) ⑤ Bolt (M6*65mm) ⑥ Bolt Cap ⑦ ⑧ Nut Cap ⑨ Washer ⑩ Spanner ⑪ Curtain Ring ⑫ Stake Page 3 OF 11 Noble House Home Furnishings LLC...
- Page 4 Before Beginning Assembly: Page 4 OF 11 Noble House Home Furnishings LLC...
- Page 5 Base (F) Mosquito Netting (L) This Gazebo has multiple parts and may require up to 4 hours to assemble.To give you an overview of the Gazebo parts, the above picture is to help you put the various parts into perspective. Please read through the instructions below to familiarise yourself with the parts and steps before assembly.
- Page 6 Repeat this process with the remaining Side Panels(A) until all Side Panels are connected. Tighten the Bolts and Nuts fully in a sequential manner. Then cover the Bolts and Nuts with Bolt Caps(⑥) and Nut Caps(⑧). Page 6 OF 11 Noble House Home Furnishings LLC...
- Page 7 Repeat this process until all Corner Braces(M), Columns(C) and Side Panels(A) are connected. Note: Please use a ladder, if you can't reach it. Tighten the Bolts fully in a sequential manner. Then cover the Bolts with Bolt Caps(⑥). Page 7 OF 11 Noble House Home Furnishings LLC...
- Page 8 Insert the Long Corner Roof Bars(B) into the Columns(C) and the Short Roof Bars(D) into the Side Panel Top Connectors(G) one-by-one. Note: Please use a ladder, if you can't reach it. Page 8 OF 11 Noble House Home Furnishings LLC...
- Page 9 Step 8 8.1) Put the Canopy(J) onto the Gazebo Roof Fram e. Insert the bolts on the Decorative Balls(I) into the ring of Canopy(J), then screw the Decorative Balls into the Columns(C) and Top connector(E). 8.2) Then securely fasten the Canopy(J) into position using the velcro strips.
- Page 10 Install the Curtains(K) along the outside Sidewall Hang Tubes(O) using the Curtain Rings(⑪) as pictured above. Affix the Gazebo to the ground by inserting the Stakes( ⑫) through the Bases(F). Your Gazebo is ready for use. This Gazebo can only be used on a flat, level surface.
- Page 11 Proposition 65 warnings have become so common in California that it is hard to take a trip to a local bank, grocery store, or restaurant without finding at least one warning. In fact, even the Disney Land Resort has a Proposition 65 warning: Page 11 OF 11 Noble House Home Furnishings LLC...
