INSTALLER'S
GUIDE
ALL phases of this installation must comply with
NATIONAL, STATE AND LOCAL CODES
Horizontal Hanging Kit:
BAYHHKIT001A
Air Handler Installations
IMPORTANT — This Document is customer property and is to remain with this unit. Please return to service information
pack upon completion of work.
Section 1. Safety Information
!
SAFETY HAzARD!
by individuals possessing adequate backgrounds of electrical and
mechanical experience. Any attempt to repair a central air condition-
ing product may result in personal injury and/or property damage.
The manufacturer or seller cannot be responsible for the interpreta-
tion of this information, nor can it assume any liability in connection
with its use.
!
SAFETY HAzARD!
edges on equipment or any cuts made on sheet metal while install-
ing or servicing. Personal injury may result.
Section 2. General Information
Open and inspect contents for
damage or missing items.
© 2010 Trane
for 1-1/2 - 5 Ton
WARNING
This information is intended for use
WARNING
Sharp Edge Hazard. Be careful of sharp
Each kit will contain:
Qty
Description
2 - 2" SS Screw
2 - 1.5" SS Screw
4 - Nut, Lifting Eye, SS
4 - Lock Washer, SS
8 - Flat Washer, SS
1 - Installer's Guide
Fits Models:
Hyperion
ForeFront
Air Handlers
Important: Due to the unique design of this unit, which
allows the electrical wiring to be routed within the insula-
tion, do not screw, cut, or otherwise puncture the unit
cabinet in any location other then the ones illustrated
in this Installer's Guide or in an approved accessory's
Installer's Guide.
Important: Make certain that the unit has been installed
in a level position to ensure proper draining.
Important: Under no condition should metal strapping
be attached to the unit to be used as support mecha-
nisms for carrying or suspension purposes.
18-GJ26D1-1
and
TM
TM
11/10
