Installation Instructions
0 to 50% Manual Outside Air
Damper
Precedent™ Packaged Rooftop Units
3 to 12.5 tons
Model Numbers:
Used With:
T/Y/WSC060EDK, T/Y/WSC060ED, T/YHC036E1,3,4,
BAYDMPR053*
T/YHC037E3,4, T/Y/WSC060ED, T/YSC036-060G3,4,W,
D/WHC036H, WSC036-048H
T/Y/WSC072-120EDK, T/Y/WSC072-120ED, T/YSC072-120H3,4,W,
T/YSC120FK, WSC072-120E3,4,W, T/YHC047-067E3,4,
BAYDMPR056*
T/YHC072-102F3,4, T/YHC120E3,4, T/YHC120F, WSC060-120H,
D/WHC048-120H
FIADMPR001* - Precedent A Cabinet (Digit 39 = A),
FIADMPR001*
FIADMPR002* - Precedent B/C Cabinet (Digit 39 = B, C),
T/Y/W/DS*036-060, T/YH*036
T/YHK*048-060, W/DHK*036-060, T/Y/W/D**072-120, T/YS*150, T/YH*072-120,
FIADMPR002*
W/D**072-120
Only qualified personnel should install and service the equipment. The installation, starting up, and servicing of
heating, ventilating, and air-conditioning equipment can be hazardous and requires specific knowledge and training.
Improperly installed, adjusted or altered equipment by an unqualified person could result in death or serious injury.
When working on the equipment, observe all precautions in the literature and on the tags, stickers, and labels that are
attached to the equipment.
September 2024
SAFETY WARNING
ACC-SVN01R-EN
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Trane BAYDMPR053 Series
Summary of Contents for Trane BAYDMPR053 Series
- Page 1 Installation Instructions 0 to 50% Manual Outside Air Damper Precedent™ Packaged Rooftop Units 3 to 12.5 tons Model Numbers: Used With: T/Y/WSC060EDK, T/Y/WSC060ED, T/YHC036E1,3,4, BAYDMPR053* T/YHC037E3,4, T/Y/WSC060ED, T/YSC036-060G3,4,W, D/WHC036H, WSC036-048H T/Y/WSC072-120EDK, T/Y/WSC072-120ED, T/YSC072-120H3,4,W, T/YSC120FK, WSC072-120E3,4,W, T/YHC047-067E3,4, BAYDMPR056* T/YHC072-102F3,4, T/YHC120E3,4, T/YHC120F, WSC060-120H, D/WHC048-120H FIADMPR001* - Precedent A Cabinet (Digit 39 = A), FIADMPR001*...
-
Page 2: Warnings, Cautions, And Notices
When working with or around hazardous chemicals, these compounds have the same potential impact to the ALWAYS refer to the appropriate SDS and OSHA/GHS environment. Trane advocates the responsible handling of all (Global Harmonized System of Classification and refrigerants. Labeling of Chemicals) guidelines for information on... -
Page 3: Revision History
Copyright This document and the information in it are the property of Trane, and may not be used or reproduced in whole or in part without written permission. Trane reserves the right to revise this publication at any time, and to make changes to its content without obligation to notify any person of such revision or change. -
Page 4: General Information
General Information Carefully review installation instructions. • Manual outside air damper supplied in return air section of unit. • To access, remove unit end panel, remove and discard shipping bracket, reinstall screw into unit base, and follow installation instructions. • This instruction covers field installation of BAYDMPR053* (Precedent™... -
Page 5: Installation
Installation Figure 2. Sliding baffle/rear panel WARNING Hazardous Voltage! Failure to disconnect power before servicing could result in death or serious injury. Disconnect all electric power, including remote disconnects before servicing. Follow proper lockout/ tagout procedures to ensure the power can not be inadvertently energized. - Page 6 Installation 5. Position the LH panel by aligning the three tabs with the Figure 7. Mist eliminator slots on the unit end panel in Step 2. Rotate in place and insert two screws to connect the LH side panel to the rear panel.
- Page 7 Installation Table 6. W/D*K120, T/YS*150, WSC120, T/YHC120, D/ Table 2. T/Y/W/DS*048 WHC120 Return Static - Inch W.G. Damper Return Static - Inch W.G. Damper Position -0.10 -0.20 -0.30 -0.40 -0.50 -0.60 -0.70 Position -0.10 -0.20 -0.30 -0.40 -0.50 -0.60 -0.70 1040 1160 1080...
