- Page 1 INKLUD PORCELAIN STEEL FLIPPER Part Numbers: IN1T10ADJ-PORC-CHAR INSTRUCCIONES DE INSTRUCTIONS DE ASSEMBLY INSTRUCTIONS ENSEMBLAJE MONTAGE DO NOT THROW AWAY! NO LA TIRE NE PAS JETER Revised: 18 Dec 2024 Page 1 of 6...
-
Page 2: Parts List
PART No.: MATL: INFORMATION WHICH IS THE EXCLUSIVE PROPERTY DO NOT SCALE DRAWING DWG SIZE OF MOORECO. IT MAY NOT BE REPORDUCED, USED OR DISCLOSED WITHOUT SHEET 1 OF 1 WRITTEN PERMISSION OF SAID COMPANY C - M6 x 15 Screw... -
Page 3: Warranty
WARNINGS AND DISCLAIMERS ADVERTENCIAS Y RENUNCIAS AVERTISSEMENTS Review full assembly instructions and Por favor leer las instrucciones previo a Avant de commencer l’ assamblage check that all parts are present before comenzar el proceso de ensamblaje o veuillez consulter instructions beginning assembly. - Page 4 Here is a list of tools and safety equipment recommended for a successful and safe installation. OSHA Approved Safety Goggles Work Gloves #3 Phillips Screwdriver Bit 4mm Allen Wrench Power Drill UNLESS OTHERWISE SPECIFIED: NAME DATE MOORECO INC. DRAWN DIMENSIONS ARE IN INCHES TOLERANCES: TITLE: CHECKED FRACTIONAL Hex L-Key ANGULAR: MACH BEND ENG APPR.
- Page 5 STEP 1 Align (P2) Flipper Mech with the 4 holes towards the 30” sides of (P1) Top. Screw the Flipper Mech using eight (D) #10x1 screws. Repeat for the other side. Ensure that the Flipper Handle wire is coming out towards the 60”...
- Page 6 STEP 3 Screw (P6) Flipper T-Leg Base to (P5) Flipper Leg Upright using (E) M12x75 screw and (A) M12 Split Lock Washer. Repeat for the other side. Ensure that the threaded ends of (P6) Flipper T-Leg Base are facing up during assembly. *Use a 10mm allen wrench STEP 4 Insert (B) 3/8”...
