ASSEMBLY INSTRUCTIONS
INSTRUCCIONES DE ENSEMBLAJE
INSTRUCTIONS DE MONTAGE
DO NOT THROW AWAY!
NO LA TIRE
NE PAS JETER
UPDATED AS OF: 09/18/2023
1 of 6

Advertisement

loading
Need help?

Need help?

Do you have a question about the Inklud and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Mooreco Inklud

  • Page 1 Inklud Tables ASSEMBLY INSTRUCTIONS INSTRUCCIONES DE ENSEMBLAJE INSTRUCTIONS DE MONTAGE DO NOT THROW AWAY! NO LA TIRE NE PAS JETER UPDATED AS OF: 09/18/2023 1 of 6...
  • Page 2: Parts List

    Parts List Hardware P1 - Table Top A - M6 x 5mm Screw P2 - Table Top Bracket x1, x2 B - M12 x 75mm Screw x1, x2 C - #10 - 1” Screw x12, x16 P3 - Base Vertical x1, x2 D - Casters/Glides P4 - Base Horizonal...
  • Page 3 WARNINGS AND DISCLAIMERS Review full assembly instructions and check that all parts are present before beginning assembly. Heavy or large furniture may require multiple persons in order to properly assemble. If you have questions regarding assembly, contact the manufacturer before continuing. Damage due to incorrect assembly may not be covered by warranty.
  • Page 4 Attach table top bracket (P2) to base vertical (P3) using M6 x 15 countersink screw (A) and STEP 1 allen wrench (G). Attach table top bracket to table top (P1) using #10-1” wood screws (D). STEP 2 UPDATED AS OF: 09/18/2023 4 of 6...
  • Page 5 Attach base horizontal with M12 x 35mm screws (B). STEP 3 Thread the four (4) Casters or Glides (E) into the Bases. STEP 4 UPDATED AS OF: 09/18/2023 5 of 6...
  • Page 6 For adjustable-height base, remove M8x1.25 Set Screws, adjust leg to desired height, and STEP 5 reinsert screws. Ensure screws are fully tightened. Turn table upright when complete. THIS COMPLETES ASSEMBLY INSTRUCTION UPDATED AS OF: 09/18/2023 6 of 6...
