Student Desk Tote Tray 2
45128, 45131

ASSEMBLY INSTRUCTIONS

INSTRUCCIONES DE ENSEMBLAJE
INSTRUCTIONS DE MONTAGE
DO NOT THROW AWAY!
NO LA TIRE
NE PAS JETER
UPDATED AS OF: 06/09/2022
1 of 6

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Tote Tray 2 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Mooreco Tote Tray 2

  • Page 1 Student Desk Tote Tray 2 45128, 45131 ASSEMBLY INSTRUCTIONS INSTRUCCIONES DE ENSEMBLAJE INSTRUCTIONS DE MONTAGE DO NOT THROW AWAY! NO LA TIRE NE PAS JETER UPDATED AS OF: 06/09/2022 1 of 6...
  • Page 2 Parts List Hardware P1 - Rail Bracket A - #10 x 1”Wood Screw B - M5 - 12mm Screw P2 - Rail C - M5 Steel Cap Nut Optional: P3 - Tray UPDATED AS OF: 06/09/2022 2 of 6...
  • Page 3 WARNINGS AND DISCLAIMERS Review full assembly instructions and check that all parts are present before beginning assembly. Heavy or large furniture may require multiple persons in order to properly assemble. If you have questions regarding assembly, contact the manufacturer before continuing. Damage due to incorrect assembly may not be covered by warranty.
  • Page 4 Place one Rail Bracket (P2) on table and secure assembly using four (4) #10 x 1” STEP 1 Wood Screws (A). With one Rail assembly screwed into the top, measure 13” from the center of the bracket STEP 2 and make a mark. 13”...
  • Page 5 Line up the second Rail Bracket (P1) with the mark made from previous step. Screw in the STEP 3 second Rail Bracket (P1) using four (4) #10 x 1” Wood Screws. STEP 4 Screw together the Rail Bracket (P1) to one of the Rails (P2) using three (3) M5 - 12mm Screws (B) and three (3) M5 Steel Cap Nuts (C).
  • Page 6 Optional Repeat with other side by mirroring bracket. STEP 5 Insert tray into rail assembly. Optional THIS COMPLETES ASSEMBLY INSTRUCTION UPDATED AS OF: 06/09/2022 6 of 6...
