- Page 1 Modular Teacher Desk - Basic Desk Part Numbers: 90455-XXXX-XX / 90456-XXXX-XX ASSEMBLY INSTRUCTIONS INSTRUCCIONES DE ENSEMBLAJE INSTRUCTIONS DE MONTAGE DO NOT THROW AWAY! NO LA TIRE NE PAS JETER UPDATED AS OF: 09/04/2019 1 of 8...
- Page 2 Parts 90390 - 1 Side Leg 58590 - Support Tube 58259 (72”)/ 58258 (60”) - Modesty Panel Table Top (Custom) ASSEMBLY INSTRUCTIONS DO NOT THROW AWAY! INSTRUCCIONES DE ENSEMBLAJE NO LA TIRE INSTRUCTIONS DE MONTAGE NE PAS JETER UPDATED AS OF: 09/04/2019 2 of 8...
- Page 3 Hardware 90390 - 1 Sided Leg x2 P1 - Adjustable Leg P2 - V Bracket: Inner A - M6 x 42mm B - M6 x 12mm E - Non-Locking Caster F - Locking Caster G - Lock Washer Tool(s): -Allen Wrench -Caster Wrench 58590 - Support Tube P1 - Support Tube...
- Page 4 WARNINGS AND DISCLAIMERS ADVERTENCIAS Y RENUNCIAS AVERTISSEMENTS Review full assembly instructions and Previo a comenzar el proceso de Avant de commencer l’ assamblage check that all parts are present before ensamblaje favor revisar veuillez consulter instructions beginning assembly. Heavy or large instrucciones y asegurarse que cuenta con complètes et vérifier si vous avez toutes furniture may require multiple persons in...
- Page 5 STEP 1 Attach two casters (E,F) to Adjustable Leg (P1) with Caster Wrench included. Be sure to include Lock Washer (G) on each. Locking Caster installed in front. Do this for both Legs. Hardware Required: -Adjustable Leg x2 90390 - P1 -Non-locking Caster 90390 - E -Locking Caster...
- Page 6 STEP 3 Slide modesty panel V-bracket Inners into outer brackets on both legs. Secure modesty panel in place with two screws (B) inserted through bottom of brackets. Hardware Required: -M6 x 12mm x2 90390 (1) - B 90390 (2) - B Tool(s) Required: -Allen Wrench STEP 4...
- Page 7 STEP 5 Loosen set screws (C) on sliding outer members of Support Tube (P1). Fasten one side of tube to side of leg with screws (A) then after adjusting tube to appropriate length, fasten opposite side of tube to other leg with same screws. Retighten set screws on Support Tube when finished.
- Page 8 STEP 7 Install U-Clamps by sliding over Support Tube and securing with two wood screws each (D). Screws are driven directly into underside of table. Position clamps approximately half- way along each sliding tube. Hardware Required: -U-Clamp x2 58590 - P2 -Wood Screw x4 58590 - D Tool(s) Used...
