Required Crew: 2-4
Required Concrete: 18-22, 80 lb. bags
Required Tools:
● Wheelbarrow
● Step Ladder (6' or taller)
● Shovel
● Tape Measure
● Digging Bar or Pick
● Level
● Allen Wrench (Provided)
● Open end or Box Wrenches: 9/16", ¾"
● Hammer or Mallet
● Ratchet Handle & Sockets: 9/16", ¾"
● Marker Pen
● Drill: Cordless or electric, or impact driver
● Stakes (for Pirate Climber)
Component Playgrounds is concerned about the safety of your vision. It
is important that you choose to protect your vision by wearing proper
safety glasses during each and every phase of this construction
PLEASE READ AND UNDERSTAND ALL INSTRUCTIONS BEFORE BEGINNING
*Before digging, please obey local laws by notifying your local
underground utilities marking organization*
Installation Instructions
PH35
process.
Advertisement
Related Manuals for Component Playgrounds PH35
Summary of Contents for Component Playgrounds PH35
- Page 1 ● Drill: Cordless or electric, or impact driver ● Stakes (for Pirate Climber) Component Playgrounds is concerned about the safety of your vision. It is important that you choose to protect your vision by wearing proper safety glasses during each and every phase of this construction process.
- Page 2 PH20 Swing Set Parts Identification Page The Small Parts Note: Pictures are not to scale. The purpose of this sheet is to get you acquainted with the general shape and names of each part of your swing set.
- Page 3 Installation Instructions 1. Select an area in your yard that is reasonably level and meets the play space requirements for your equipment. PH35 Ground space: 8’ x 26’. Play Space: 12’ x 41’ 2. Position the horizontal ladder in your yard where you want the unit to finally stand.
- Page 4 8’ top rail. (refer to the detail on the front page of the PH35 Installation Instructions.) 13. Install the 8’ top rail into the top sleeve of the vertical ladder at the swing end of the horizontal ladder.
- Page 6 Model PH35 Continued...
- Page 7 **Important Notice! Please read and understand prior to proceeding** Pre-Assembly: Assembling the Play House Floor Joists 2.a. Locate the Floor Joist End with the four holes in it as shown below and determine which holes you will be using for your particular swing set configuration.
- Page 8 2.c. Position assembled deck frame on the ground as shown below. Mark the holes for the Play House Legs. Dig the holes to the specifications below.
- Page 9 Assembling Ladders and Attaching to Deck Support Structure 3.a. Make a mark 108” up from the bottom of the ladder onto each ladder rail. Move the adjustable sleeves to these marks and position them to receive the horizontal ladder by turning them to point at a 90 degree angle (towards what will become the inside of the Horizontal Ladder section of the structure.) Secure the set screws.
- Page 10 3.b. The vertical ladders should be positioned on the ground with the bottom of the ladder placed just over the hole where it will finally stand. (Please make sure that the drilled ladder is placed at the end that is next to the Play House Platform).
- Page 11 Installing the Plastic Lumber Tools Needed: Electric drill, 13/64” drill bit, 18 or 20 volt impact driver (preferred tool), or a cordless or electric drill can be used to drive the screws. 4.a. Secure the first two boards into place at each end of the platform structure using the 13/64” drill bit to pre-drill the holes through the plastic and into the floor joist.
- Page 12 4.b. Having pre-assembled the floor joist system, it is now best to have at least three people to assemble the Play House Legs to the floor joists. Insert all four legs. Then insert and secure one set screw into each leg to hold them in place. *Note: We suggest you use a structure of some kind to support the platform as you place the assembled deck structure in the previously dug holes as shown.
- Page 13 4.c. Place the assembled structure into the holes previously dug. 4.d. Attach the Platform Support Structure to the vertical ladder using the 5” carriage bolts pushed through the ladder and through the support structure as shown, attaching platform to 8’ vertical ladder.
- Page 14 4.e. Level out the structure. 4.f. Insert top rails as shown below to marks previously made. Secure them with set screws. 4.g. Level the Play House platform and the swing structure. If you are assembling this structure in one day, disregard this step: When you are satisfied that the structure is level, mix and pour the concrete according to the package directions.
- Page 15 Installing the Plastic Lumber 5.a. With the first two boards secured into place, lay out the remaining boards onto the support structure. Evenly space the boards as shown in the diagram below. Beginning at one end, it works best to secure each board in turn using one screw at each end of the board to secure it to the support structure, repeating this process until all of the boards are attached to the support structure.
- Page 16 Assembling the Barriers 6.a. Position the Barriers onto the platform and connect the corners together at 45 degree angles as shown below. Use two of the eight sets of panel clamps with the ⅜” x 2” carriage bolt and ⅜” hex nut that are provided at each corner.
- Page 17 Assembling the Canopy Kit 7.a. Attach the canopy ridge pole brackets to the center of both of the six foot barriers with panel clamps as shown below. 7.b. Insert the canopy ridge pole into the brackets previously attached to the barriers.
- Page 18 7.c. Insert canopy supports in through the sleeves of the canopy as shown below. 7.d. Attach canopy to barriers as shown below.
- Page 19 Step 1: Position slide on deck in desired location Step 2: Attach slide to deck with two #14 x 1 ½” Truss Screws...
- Page 20 Installation Instructions: Fire Pole Dig the hole for the footing about 15” away from the Play House Platform and center the hole with the desired opening in the barrier. Attach the Fire Pole to the Barrier using two sets of Panel Clamps, two ⅜” x 2” carriage bolts and two ⅜”...
- Page 21 1. Loosen and remove the two nylock jam nuts. 2. Reassemble onto swing top rail. The hex bolt can be positioned as it is pictured or flipped around so the hex bolt is on the bottom. Tighten securely so that the hanger is firmly attached in place and cannot slide or swivel along top rail.
-
Page 22: Steering Wheel
Steering Wheel Installation Instructions Assemble the Steering Wheel as shown above. Then attach Bracket to the Barrier with panel clamps and ⅜” and 2” carriage bolts and hex nuts. - Page 23 Telescope Installation Instructions...
-
Page 24: Read Before Use
Do not attempt to use equipment for something other than the use for which it was designed and intended, or in a manner other than that for which it was designed and intended. While every attempt is made by Component Playgrounds to ensure the highest degree of safety in all of our equipment, we cannot guarantee freedom from injury. The user assumes all risk of injury due to use. - Page 25 We hope that you and your family will enjoy many hours of great family fun while using your Component Playgrounds Products. We appreciate your business. Our goal is to provide safe, durable and fun products using the best materials available. Your product should be mostly maintenance free.
- Page 26 This damage to the galvanizing is restricted to the actual weld. When your equipment is built, Component Playgrounds will repair this damage using a cold galvanizing compound spray along with a top coat of silver aluminum.
- Page 27 To Help Prevent Injuries from Falls & Other Hazards 1. Never attach, or allow children to attach the following items to your swing set: Ropes, jump ropes, clotheslines, pet leashes or any similar type of item to your swing set. Any item such as these may present a strangulation hazard.
- Page 28 Warranty Component Playgrounds works to build heavy duty products that will stand up to the heavy use of active children. You can trust Component Playgrounds because of the way we design and build our products. We make products that are simple to own, and easy to maintain.
