Required Crew: 2 Required but 4 Recommended
Concrete: 12-16, 80 lb. bags
Required Tools:
● Wheelbarrow
● Step Ladder (6' or taller)
● Shovel
● Tape Measure
● Digging Bar or Pick
● Level
● Allen Wrench (Provided)
● Open end or Box Wrenches: 9/16", ¾"
● Hammer or Mallet
● Ratchet Handle & Sockets: 9/16", ¾"
● Marker Pen
● Drill: Cordless or electric, or impact driver
Component Playgrounds is concerned about the safety of your vision. It
is important that you choose to protect your vision by wearing proper
safety glasses during each and every phase of this construction
process.
PLEASE READ AND UNDERSTAND ALL INSTRUCTIONS BEFORE BEGINNING
The HL50-10 can be installed as a one day project. The normal time
required to install the HL50-10 is about 3-6 hours for a two man crew. This
time requirement will vary dependent upon the composition of the soil and
the speed of the installers. Mix and pour the concrete as the last step.
*Before digging, please obey local laws by notifying your local
underground utilities marking organization*
Installation Instructions
HL50-10
Advertisement
Related Manuals for Component Playgrounds HL50-10
Summary of Contents for Component Playgrounds HL50-10
- Page 1 The HL50-10 can be installed as a one day project. The normal time required to install the HL50-10 is about 3-6 hours for a two man crew. This time requirement will vary dependent upon the composition of the soil and the speed of the installers.
- Page 2 Installation Instructions 1. Select an area in your yard that is reasonably level and meets the space requirements for your equipment. Ground Space: 9’ x 19’ Play Space: 13’ x 31’. 2. Using the measurements from the top view diagram, measure and mark the position of the Swing Hangers and Ladders on both 9’...
- Page 3 into the holes. Install plugs into the ends of the Top Rails. Slide Top Rails into Top Sleeve of the Upright Ladders (see #2 Ladder to Top Rail assembly.) Secure set screws. Slide 3rd leg sleeve onto the top rail that is sleeved into the 10’ ladder.
- Page 4 #1 Holes Sizes for Cementing in the Set...
- Page 5 #2 Ladder to Top Rail Assembly #3 Horizontal Ladder to Upright Ladder Assembly...
- Page 6 Component Playgrounds BRASS BUSHING SWING HANGER 1. Loosen and remove the two nyloc jam nuts. 2. Reassemble on to swing top rail. Tighten securely so that the hanger is firmly attached in place and cannot slide or swivel along top rail.
-
Page 7: Read Before Use
While every attempt is made by Component Playgrounds to ensure the highest degree of safety in all of our equipment, we cannot guarantee freedom from injury. The user assumes all risk of injury due to use. - Page 8 We hope that you and your family will enjoy many hours of great family fun while using your Component Playgrounds Products. We appreciate your business. Our goal is to provide safe, durable and fun products using the best materials available. Your product should be mostly maintenance free.
- Page 9 This damage to the galvanizing is restricted to the actual weld. When your equipment is built, Component Playgrounds will repair this damage using a cold galvanizing compound spray along with a top coat of silver aluminum.
- Page 10 To Help Prevent Injuries from Falls & Other Hazards 1. Never attach, or allow children to attach the following items to your swing set: Ropes, jump ropes, clotheslines, pet leashes or any similar type of item to your swing set. Any item such as these may present a strangulation hazard.
- Page 11 Limited Lifetime Warranty Component Playgrounds works to build heavy duty products that will stand up to the heavy use of active children. You can trust Component Playgrounds because of the way we design and build our products. We make products that are simple to own, and easy to maintain.
-
Page 12: Warranty Registration Sheet
Return this form via e-mail to: State: Zip: s a les@componentplaygrounds.com Phone: Or via U.S. mail to: Purchase Date: Completion Date: Component Playgrounds 1630 North Beck Street Sales Representative/Dealer Information Salt Lake City, UT 84116 (If different from manufacturer) Organization: Today’s Date: City: State:...
