Operator's Manual
1830HV / 96193007300
Gasoline containing up to 10% ethanol (E10) is acceptable for use in this machine.
The use of any gasoline exceeding 10% ethanol (E10) will void the product warranty.
Please read the owner's manual carefully and make sure you
understand the instructions before using the machine.
532 44 34-17
English
Advertisement
Table of Contents
Related Manuals for Husqvarna 1830HV
Summary of Contents for Husqvarna 1830HV
- Page 1 Operator’s Manual 1830HV / 96193007300 Gasoline containing up to 10% ethanol (E10) is acceptable for use in this machine. The use of any gasoline exceeding 10% ethanol (E10) will void the product warranty. Please read the owner's manual carefully and make sure you understand the instructions before using the machine.
-
Page 2: Safety Rules
IMPORTANT Safe Operation Practices for Walk-Behind Snow Throwers This snow thrower is capable of amputating hands and feet and throwing objects. Failure to observe the following safety instructions could result in serious injury. WARNING: Snow throwers have ex- Look for this symbol to point out im- posed rotating parts, which can cause por tant safety precautions. -
Page 3: Table Of Contents
6. When cleaning, repairing or inspecting the snow thrower, 16. Never touch a hot engine or muffler. stop the engine and make certain the collector/impel- ler and all moving parts have stopped. Disconnect Clearing a Clogged Discharge Chute the spark plug wire and keep the wire away from the Hand contact with the rotating impeller inside the discharge plug to prevent someone from accidentally starting the chute is the most common cause of injury associated with... -
Page 4: Assembly / Pre-Operation
PARTS PACKED SEPARATELY IN CARTON (1) POWER CORD (1) MULTI- (3) RETAINER (198563) WRENCH SPRINGS (180684) (169675) (6) LOCKNUTS (6) SHEAR BOLTS 1/4-20 x 1-3/4 1/4-20 (192090) (73800400) (2) FLAT WASHERS SAFTEY IGNITION KEY (S) (443059) (2) CARRIAGE BOLTS (1) LOCKNUT (1) CARRIAGE BOLT 3/8-16 x 2.25 5/16-18... - Page 5 ASSEMBLY / PRE-OPERATION NOTE: The multi-wrench may be used for assembly of the INSTALL TRACTION DRIVE CONTROL ROD chute rotator head to snow thrower and making ad just ments (See Figs. 3 and 4) to the skid plates. The traction drive control rod is installed on the snow thrower. UNFOLD UPPER HANDLE 1.
- Page 6 ASSEMBLY / PRE-OPERATION INSTALL AUGER CONTROL ROD (See Figs. 5 and 6) INSTALL DISCHARGE CHUTE / CHUTE ROTATER HEAD (See Fig. 7) 1. Retrieve vinyl sleeve and spring from bag of parts and retrieve the auger control rod from carton chute tray. NOTE: The multi-wrench provided in your parts bag may Slide straight rod end through the small hole in the be used to install the chute rotater head.
- Page 7 ASSEMBLY / PRE-OPERATION INSTALL CHUTE DEFLECTOR REMOTE CONTROL (See Figs. 8 and 9) 1. Install remote cable bracket to discharge chute with 5/16-18 carriage bolt and 5/16-18 locknut as shown. Tighten securely. 2. Install remote cable eyelet to chute deflector with 1/4-20 shoulder bolt and 1/4-20 locknut as shown.
-
Page 8: Operation
OPERATION KNOW YOUR SNOW THROWER READ THIS OWNER'S MANUAL AND ALL SAFETY RULES BEFORE OPERATING YOUR SNOW THROWER. Compare the illustrations with your snow thrower to familiarize yourself with the location of various controls and adjustments. Save this manual for future reference. These symbols may appear on your snow thrower or in literature supplied with the product. - Page 9 OPERATION MUF FLER ELECTRIC DISCHARGE CHUTE CONTROL LEVER START BUTTON AUGER DEFLECTOR REMOTE GAS O LINE CONTROL CONTROL LEVER FILLER CAP DRIVE SPEED POWER LEVER CON TROL LEVER CORD PLUG CHOKE CON- CHUTE TRACTION TROL DE FLEC TOR DRIVE CONTROL LEVER SAFETY IGNITION...
-
Page 10: How To Use Your Snow Thrower
OPERATION The operation of any snow thrower can result TO CONTROL SNOW DISCHARGE (See Fig. 13) in foreign objects thrown into the eyes, which can result in severe eye damage. Always wear WARNING: Snow throwers have ex- safety glasses or eye shields while operating posed rotating parts, which can cause your snow thrower or performing any ad just- severe injury from contact, or from ma-... - Page 11 OPERATION TO MOVE FORWARD AND BACKWARD (See Fig. 16) TO THROW SNOW (See Fig. 14) SELF-PROPELLING, forward and reverse movement of The auger rotation is controlled by the auger control lever the snow thrower, is controlled by the traction drive control located on the right side handle.
-
Page 12: Before Starting The Engine
OPERATION BEFORE STARTING THE ENGINE POWER STEERING OPERATION (See Fig. 17) Steering triggers are used to assist in steering your snow CHECK ENGINE OIL LEVEL (See Fig. 19) thrower. The triggers are located on the underside of each The engine on your snow thrower has been shipped from handle. -
Page 13: Before Stopping
OPERATION TO START ENGINE 5. Pull recoil starter handle quickly. Do not allow starter rope to snap back. • Be sure fuel shut-off valve is in the “OPEN” position. 6. When the engine starts, release the recoil starter han dle Your snow thrower engine is equipped with both a 120 Volt and slowly move the choke control to the “OFF”... -
Page 14: Maintenance Schedule
MAINTENANCE GENERAL REC OM MEN DA TIONS LUBRICATION CHART The warranty on this snow thrower does not cover items that have been sub ject ed to operator abuse or negligence. ➀ SAE 30 Motor Oil To receive full value from the warranty, operator must ➁... - Page 15 MAINTENANCE BELTS TO CHANGE ENGINE OIL Check belts for deterioration and wear after every 50 hours Determine temperature range anticipated before next oil of operation and replace if necessary. The belts are not change. All oil must meet API service classification SG–SL. ad just able.
-
Page 16: Service And Adjustments
SERVICE AND ADJUSTMENTS 1. Disengage all controls and move throttle control to WARNING: To avoid serious injury, before STOP position. Wait for all moving parts to stop. performing any service or ad just ments: 2. Remove safety ignition key and disconnect spark plug 1. - Page 17 SERVICE AND ADJUSTMENTS TO REPLACE BELTS (See Fig. 22) HINT: Insert a 3/8" drive ratchet (in the “ON” position) into the square hole in idler arm and rotate ratchet clockwise The auger and traction drive belts are not adjustable. If to relieve tension.
-
Page 18: Engine Speed
SERVICE AND ADJUSTMENTS ENGINE TO REMOVE WHEELS (See Fig. 23) • Remove the wheel pin and retainer pin and remove See engine manual. wheel from axle. CARBURETOR NOTE: To seal punctures or prevent flat tires due to slow Your carburetor is not adjustable. Engine performance leaks, tire sealant may be purchased from your local parts should not be affected at altitudes up to 7,000 feet (2,134 dealer. -
Page 19: Storage
STORAGE Immediately prepare your snow thrower for storage at • Empty the fuel tank by starting the engine and letting it run until the fuel lines and car bu re tor are empty. the end of the season or if the unit will not be used for 30 days or more. -
Page 20: Troubleshooting
TROUBLESHOOTING See appropriate section in manual unless directed to an authorized service center/department. PROBLEM CAUSE CORRECTION Does not start 1. Fuel shut-off valve (if so 1. Turn fuel shut-off valve to OPEN position. equipped) in OFF position. 2. Safety ignition key 2. -
Page 25: Service Notes
SERVICE NOTES... - Page 26 SERVICE NOTES...
- Page 27 SERVICE NOTES...
- Page 28 06/17/2011 TH...
