Fulham Firehorse Hotspot Manual

Emergency led driver

Advertisement

Quick Links

FHSCP-UNV3-5W-L-SD
Emergency LED Driver
Emergency LED Driver
Universal Voltage: 100-347V~
Output Voltage Range: 12-55V
Output Current: 417mA Max
General Specifications
Input Voltage / Frequency
Input Current
Input Power
Standby Power
Input Power Pass-Through Rating (AC Driver Line)
Max Output Rating (LED+ LED-
Output Power
Output Voltage Range
Output Current Rated
Number of Output Channels
Test Switch
Input Surge Protection
Emergency Mode Protections
RFI/EMI
Ambient Operating Temperature Range
Tc
Sound Rating
Battery Type
Battery Voltage
Battery Capacity
Battery Rating
Battery Recharge Time
Battery Discharge Time
IP Rating
Test Switch Remote Mounting Distance
Service Life
Warranty
Safety Standards
Fulham Co. Inc.: 12705 South Van Ness Ave., Hawthorne, CA 90250 Tel.: 1-323-779-2980 Fax.: 1-323-754-9060.
Specifications subject to change without notice.
Output Wattage: 5W

Output Type: LED Class 2

Number of Output Channels: 1 Channel

Dry and Damp Location
100-347V~ , 50/60Hz
<0.08A
<5W
0.85W
3A
3A, 55V Max
5W
12-55V
0.417A Max
1 Channel
Plastic Bi-Color Test Switch
3KV/6KV Ring wave, 1KV/2KV Combine surge
Output Open Protection
Output Overload Protection
Output Short Circuit Protection
Output Temperature Protection
FCC Part 15 ClassA
0°C To 55 °C( 32 °F To 131 °F)
TBD
A
Ternary lithium battery
7.3V
2600mAh
18.98Wh
24 Hours
Min 1.5 Hours
IP
20
65.6' (20m) Max.
50,000 hours
5 Years From the date of manufacture when properly installed
UL 924/UL 1310/CSA C22.2 No.141
Lithium-ion
order@fulham.com www.fulham.com
Page 1 of 7

Advertisement

loading
Need help?

Need help?

Do you have a question about the Firehorse Hotspot and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Fulham Firehorse Hotspot

  • Page 1 5 Years From the date of manufacture when properly installed Safety Standards UL 924/UL 1310/CSA C22.2 No.141 Fulham Co. Inc.: 12705 South Van Ness Ave., Hawthorne, CA 90250 Tel.: 1-323-779-2980 Fax.: 1-323-754-9060. order@fulham.com www.fulham.com Specifications subject to change without notice.
  • Page 2 [188.5mm] FHSCP-UNV3-5W-L-SD Overall Dimensions 8.07" Length [205mm] 1.7" Width [43mm] 1.14" Height [29mm] order@fulham.com www.fulham.com Fulham Co. Inc.: 12705 South Van Ness Ave., Hawthorne, CA 90250 Tel.: 1-323-779-2980 Fax.: 1-323-754-9060. Specifications subject to change without notice. Page 2 of 7...
  • Page 3 LED Lamp Mounting hole: ø0.472" - 0.492" [ø12mm-12.5mm] Ø.3"[Ø7.6mm] Metal cap 0.621"[15.78mm] 0.544"[13.82mm] Fulham Co. Inc.: 12705 South Van Ness Ave., Hawthorne, CA 90250 Tel.: 1-323-779-2980 Fax.: 1-323-754-9060. order@fulham.com www.fulham.com Specifications subject to change without notice. Page 3 of 7...
  • Page 4 2. (2) 6-32 x ½”LG mounting screws Wall plate and screw color: Pure white with black lettering Fulham Co. Inc.: 12705 South Van Ness Ave., Hawthorne, CA 90250 Tel.: 1-323-779-2980 Fax.: 1-323-754-9060. order@fulham.com www.fulham.com Specifications subject to change without notice.
  • Page 5 FHSCP-UNV3-5W-L-SD WHT/BLK(N-OUT) test switch BATTERY CONNECTOR RED (From LED driver) BLU/WHT RED/WHT LEDARRAY Fulham Co. Inc.: 12705 South Van Ness Ave., Hawthorne, CA 90250 Tel.: 1-323-779-2980 Fax.: 1-323-754-9060. order@fulham.com www.fulham.com Specifications subject to change without notice. Page 4 of 7...
  • Page 6 Press and hold the test switch for 5 seconds during EM output condition to turn off EM output. This is useful for production environment to turn off the EM output once a luminaire has completed functionality testing. Fulham Co. Inc.: 12705 South Van Ness Ave., Hawthorne, CA 90250 Tel.: 1-323-779-2980 Fax.: 1-323-754-9060. order@fulham.com www.fulham.com Specifications subject to change without notice.
  • Page 7 Driver must be grounded by means of the Driver case. LED load • Fulham’s Hotspot Constant Power Emergency LED drivers are designed to drive passive LEDs, -COB's and -LED assemblies Proper function is not guaranteed when (LED) loads with active components are used. Mounting / Cooling •...
  • Page 8: Outer Dimension

    Product Image: LED Driver FHSCP-UNV3-5W-L-SD Packaging Master Carton OUTER DIMENSION Gross QUANTITY Weight Weight Fulham Co. Inc.: 12705 South Van Ness Ave., Hawthorne, CA 90250 Tel.: 1-323-779-2980 Fax.: 1-323-754-9060. order@fulham.com www.fulham.com Specifications subject to change without notice. Page 7 of 7...
