Fulham Hotspot FHSCP-UNV-10W-L-SD Manual

FHSCP-UNV-10W-L-SD
Emergency LED Driver
Universal Voltage: 120-277VAC, 50/60Hz
Output Voltage Range: 15-55V
Output Current: 181-666mA
Input Voltage / Frequency
Input Current
Input Power
Maintain Power
Input Power Pass-Through Rating (AC Driver Line)
Max Output Rating (LED+ LED- Terminal)
White/Black Lead
Output Power
Output Current Rated
Output Voltage Range
Number of Output Channels
Test Switch
Input Surge Protection
Protections
RFI/EMI
Ambient Operating Temperature Rang
Tc
Sound Rating
Battery Type
Battery Voltage
Pack Capacity
Battery Rating
Battery Count
Battery Recharge Time
Battery Discharge Time
IP Rating
Test Switch Remote Mounting Distance
Service Life
Warranty
Safety Standard
Fulham Co. Inc.: 12705 South Van Ness Ave., Hawthorne, CA 90250 Tel.: 1-323-779-2980 Fax.: 1-323-754-9060.
Specifications subject to change without notice.
Output Wattage: 10W
Output Type: LED Class 2
 Number of Output Channels: 1 Channel
 Dry and Damp
120-277VAC , 50/60Hz
0.1A
5W Typical
<0.85W
5A
3A Max
55V Max
2A Max
Typical 10W
181-666mA
15 - 55V
1 Channel
Bi-Color
3KV/6KV Ring wave, 1KV/2KV Combine surge
Output Open Protection
Output Overload Protection
Output Short Circuit Protection
FCC Part15A
0°C To 55°C (32°F To 131F°)
62°C (143.6°F)
A
Lithium-ion
10.95V
2600mAh
28.47Wh
3 Cells
24 Hours
1.5 Hours Min.
IP 20
20' (6m) Max.
50,000 hours @62°C (143.6°F)
@62°C (143.6°F) 5 Years From the date of manufacture when properly installed
UL 924, UL 1310, CSA C22.2 No.141
Lithium
E477042
order@fulham.com www.fulham.com
2023-963 Rev A
Page 1 of 7
