Fulham FHS2-UNV-56S General Installation Manuallines

Description: Emergency LED Driver For Back-up Lighting.
This Driver Will Operate Constant Current LED Arrays With a Working Voltage Between
11-56VDC And Not Exceeding 20W.
INPUT VOLTAGE
INPUT CURRENT
INPUT POWER
RED LEAD
WHITE/BLACK LEAD
OUTPUT CURRENT
OUTPUT WORKING VOLTAGE
RECHARGE TIME REQUIRED
BATTERY TYPE
BATTERY CAPACITY AVAILABLE
ILLUMINATION TIME
TOTAL MAX. LED POWERED
OUTPUT CLASSIFICATION
SURGE PROTECTION
INPUT PROTECTION
OUTPUT SHORT CIRCUIT PROTECTION
OPEN CIRCUIT PROTECTION
AMBIENT TEMPERATURE
APPROVALS/CLASS
EMERGENCY LED DRIVER & LiFePO4 BATTERIES
MECHANICAL DATA
Where : L = Length, W = Width, H = Height, Tolerance=±0.02"
Accessory Harness (Need separately purchase)
Part Number Descrip on
FHS-HARNESS-100 100 mA LED Harness FHS-HARNESS-150
FHS-HARNESS-200 200 mA LED Harness FHS-HARNESS-250
FHS-HARNESS-300 300 mA LED Harness FHS-HARNESS-350
FHS-HARNESS-400 400 mA LED Harness FHS-HARNESS-450
FHS-HARNESS-500 500 mA LED Harness FHS-HARNESS-550
FHS-HARNESS-600 600 mA LED Harness FHS-HARNESS-650
FHS-HARNESS-700 700 mA LED Harness
This product does not meet CEC Title 20 Code of Regulations. Fulham extends a limited warranty only to the original purchaser or to the first user for a
period of 5 years from the date of manufacture when properly installed and operated under normal conditions of use. For complete terms and conditions,
please reference the Fulham product catalog (www.fulham.com) Due to a program of continuous improvement, Fulham reserves the right to make
modifications or variations in design or constructionto the equipment described. © Fulham Company Limited, All Rights Reserved.
SPECIFICATION SHEET:
This Is An Original Product From Fulham Co., Inc
ELECTRICAL DATA
Part Number Descrip on
150 mA LED Harness
250 mA LED Harness
350 mA LED Harness
450 mA LED Harness
550 mA LED Harness
650 mA LED Harness
FHS2-UNV-56S
100-277VAC±10%, 50/60Hz
43mA Max.
2.82W Max.
3A, 60V Max.
100W Max.
100mA-700mA (Refer to accessory chart)
11-56VDC
24-48Hours (Refer to battery chart)
NiCd 9.6VDC or LiFePO4 9.6VDC
.9Ah, 1Ah, 1.2Ah, 1.5Ah, 1.8Ah, 3Ah, 4Ah, 6Ah
90Minutes Min.
ANSI/IEEE C62.41 CLASS A
Self Resetting PTC
0°C-50°C NiCd, 10°C-50°C LiFePO4, -20°C-50°C (FHSBATCC3-3)
cUR Class 2, Dry and Damp Locations, CE
WIRING DIAGRAMS
WIRE
BLACK WHITE RED BLK/WHT BATTERY LEAD
LENGTH - INCHES
13±.5" 13±.5" 21±.5"
INPUT SIDE
SWITCH TEST
INPUT/OUTPUT
WIRES (REFER TO WIRING
DIAGRAM BELOW)
LINE
WHITE
WALL
SWITCH
LED DRIVER
BLACK
DRIVER MUST
BE GROUNDED
NiCd/LiFePO4
20W
Class 2
FUSE
YES
RoHS
LED HARNESS-TEST SWITH
15±.5" 12±.5"
OUTPUT SIDE
100mA - 700mA harness
(Need separately purchase)
LED ARRAY
BATTERY
WIRING DIAGRAM (TYP)
WHITE(COMMON)
BLACK
HOT( 100V - 277V)
WHT/BLK
RED (+)
RED (+)
BLUE (-)
TEST
SWITCH
BLK
RED
LED ARRAY
E313578
MECHANICAL DATA
24 ±1"
BATTERY
2015-574-1 REV C
