FHSCP-UNV4-20W-L-SD-A
Emergency LED Driver
Universal Voltage: 100-480VAC, 50/60Hz
Output Voltage Range: 15-55V
Output Current: 1333mA Max
Input Voltage / Frequency
Input Current
Input Power
Maintain Power
Input Power Pass-Through Rating (AC Driver Line)
Max Output Rating (LED+ LED- Terminal)
Output Power
Output Current Rated
Output Voltage Range
Number of Output Channels
Test Switch
Input Surge Protection
Protections
RFI/EMI
Ambient Operating Temperature Rang
Tc
Sound Rating
Battery Type
Battery Voltage
Pack Capacity
Battery Rating
Battery Count
Battery Recharge Time
Battery Discharge Time
IP Rating
Test Switch Remote Mounting Distance
Service Life
Warranty
Safety Standard
Fulham Co. Inc.: 12705 South Van Ness Ave., Hawthorne, CA 90250 Tel.: 1-323-779-2980 Fax.: 1-323-754-9060.
Specifications subject to change without notice.
Output Wattage: 20W
Output Type: LED Class 2
Number of Output Channels: 1 Channel
Dry and Damp
100-480VAC , 50/60Hz
＜0.12 A
＜6.5W
<0.85W
5A
3A Max
55V Max
Typical 20W
1A Max
15 - 55V
1 Channel
Bi-Color
3KV/6KV Ring wave, 1KV/2KV Combine surge
Output Open Protection
Output Overload Protection
Output Short Circuit Protection
Over Temperature Protection
FCC Part15A
0°C To 55°C (32°F To 131F°)
TBD
A
Ternary lithium battery
10.95V
5200mAh
56.94Wh
6 Cells
24 Hours
1.5 Hours Min.
IP
20
20' (6m) Max.
50,000 hours
5 Years From the date of manufacture when properly installed
UL 924, UL 1310, CSA C22.2 No.141
Lithium-ion
order@fulham.com www.fulham.com
2024-xxx Rev A
Page 1 of 7
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Fulham Hotspot FHSCP-UNV4-20W-L-SD-A
Summary of Contents for Fulham Hotspot FHSCP-UNV4-20W-L-SD-A
- Page 1 5 Years From the date of manufacture when properly installed Safety Standard UL 924, UL 1310, CSA C22.2 No.141 Fulham Co. Inc.: 12705 South Van Ness Ave., Hawthorne, CA 90250 Tel.: 1-323-779-2980 Fax.: 1-323-754-9060. order@fulham.com www.fulham.com Specifications subject to change without notice.
-
Page 2: Mechanical Data
Height (34mm) 9.646" [245mm] 9.291" [236mm] 29.5" MIN. [750mm MIN.] Fulham Co. Inc.: 12705 South Van Ness Ave., Hawthorne, CA 90250 Tel.: 1-323-779-2980 Fax.: 1-323-754-9060. order@fulham.com www.fulham.com Specifications subject to change without notice. Page 2 of 7 2024-xxx Rev A... - Page 3 1.“Charge push to Test”plate 2. (2) 6-32 x ½”LG mounting screws Fulham Co. Inc.: 12705 South Van Ness Ave., Hawthorne, CA 90250 Tel.: 1-323-779-2980 Fax.: 1-323-754-9060. order@fulham.com www.fulham.com Specifications subject to change without notice. Page 3 of 7...
-
Page 4: Wiring Diagram
WHT/BLK(N-OUT) BATTERY CONNECTOR RED (Form LED driver) BLU/WHT RED/WHT LEDARRAY Fulham Co. Inc.: 12705 South Van Ness Ave., Hawthorne, CA 90250 Tel.: 1-323-779-2980 Fax.: 1-323-754-9060. order@fulham.com www.fulham.com Specifications subject to change without notice. Page 4 of 7 2024-xxx Rev A... - Page 5 Press and hold the test switch for 5 seconds during EM output condition to turn off EM output. This is useful for production environment to turn off the EM output once a luminaire has completed functionality testing. Fulham Co. Inc.: 12705 South Van Ness Ave., Hawthorne, CA 90250 Tel.: 1-323-779-2980 Fax.: 1-323-754-9060. order@fulham.com www.fulham.com Specifications subject to change without notice.
-
Page 6: Warranty
LED Load • Fulham’s Hotspot Constant Power Emergency LED drivers are designed to drive passive LED’s, COB’s and LED assemblies. Proper function is not guaranteed when (LED) loads with active components are used. Mounting and cooling •... -
Page 7: Outer Dimension
Product Image: FHSCP-UNV4-20W-L-SD-A Packaging OUTER DIMENSION Gross QUANTITY Weight Weight Fulham Co. Inc.: 12705 South Van Ness Ave., Hawthorne, CA 90250 Tel.: 1-323-779-2980 Fax.: 1-323-754-9060. order@fulham.com www.fulham.com Specifications subject to change without notice. Page 7 of 7 2024-xxx Rev A...
