KLI-4104 Imager Board
User's Manual
Description
The KLI−4104 Imager Evaluation Board, referred to in
this document as the Imager Board, is designed to be used
as part of a two−board set, used in conjunction with a Timing
Generator Board. ON Semiconductor offers an Imager
Board / Timing Generator Board package that has been
designed and configured to operate with the KLI−4104
Image Sensors.
The Timing Generator Board generates the timing signals
necessary to operate the CCD, and provides the power
required by the Imager Board. The timing signals, in LVDS
format, and the power, are provided to the Imager Board via
the interface connector (J5). In addition, the Timing
Generator Board performs the processing and digitization of
the analog video output of the Imager Board.
The KLI−4104 Imager Board has been designed to
operate the KLI−4104 with the specified performance at
Table 1. POWER REQUIREMENTS
Power Supplies
+5 V_MTR Supply
−5 V_MTR Supply
VPLUS Supply
Total Power Dissipation
Table 2. SIGNAL LEVEL REQUIREMENTS
Input Signals (LVDS)
H1A (±)
H1B (±)
H2A (±)
H2B (±)
FDG
R (±)
V1 (±)
V2 (±)
V2B (±)
V3RD (±)
VES (±)
© Semiconductor Components Industries, LLC, 2014
October, 2014 − Rev. 2
INPUT REQUIREMENTS
Minimum
Typical
4.9
5.0
1.3
−5.1
−5.0
0.2
18
20
1.8
42
V
V
min
threshold
0
±0.1
0
±0.1
0
±0.1
0
±0.1
0
±0.1
0
±0.1
0
±0.1
0
±0.1
0
±0.1
0
±0.1
0
±0.1
EVAL BOARD USER'S MANUAL
30 MHz pixel clocking rate and nominal operating
conditions. (See the KLI−4104 performance specifications
for details).
For testing and characterization purposes, the KLI−4104
Imager board provides the ability to adjust many of the CCD
bias voltages and CCD clock level voltages by adjusting
potentiometers on the board. The Imager Board provides the
means to modify other device operating parameters (e.g.,
CCD Reset clock pulse width, Input Diode clock pulse
width) by populating components differently on the board.
Maximum
Units
5.1
V
A
−4.9
V
A
21
V
A
W
V
Units
max
2.4
V
2.4
V
2.4
V
2.4
V
2.4
V
2.4
V
2.4
V
2.4
V
2.4
V
2.4
V
2.4
V
1
www.onsemi.com
Comments
Air cooling recommended
Comments
H1 clock
ID clock
H2 clock
(not used)
LOGR clock
Reset clock
TG1 clock
TG2 clock
LOGB clock
LOGG clock
LOGL clock
Publication Order Number:
EVBUM2284/D
