ON Semiconductor KAI-4011 User Manual

EVBUM2279/D
KAI-4011 / KAI-4021 /
KAI-04022 Imager Board
User's Manual
Description
The KAI−4011 / KAI−4021 / KAI−04022
Evaluation Board, referred to in this document as the Imager
Board, is designed to be used as part of a two−board set, used
in conjunction with a Timing Generator Board.
ON Semiconductor offers an Imager Board / Timing
Generator Board package that has been designed and
configured to operate with the KAI−4011 / KAI−4021 /
KAI−04022 Image Sensors.
The Timing Generator Board generates the timing signals
necessary to operate the CCD, and provides the power
required by the Imager Board. The timing signals, in LVDS
format, and the power, are provided to the Imager Board via
the interface connector (J1). In addition, the Timing
Generator Board performs the processing and digitization of
the analog video output of the Imager Board.
The KAI−4011 / KAI−4021 / KAI−04022 Imager Board
has been designed to operate the KAI−4011 / KAI−4021 /
Table 1. POWER REQUIREMENTS
Power Supplies
+5 V_MTR Supply
−5 V_MTR Supply
VPLUS Supply
VMINUS Supply
Table 2. SIGNAL LEVEL REQUIREMENTS
Input Signals (LVDS)
H1A (±)
H1B (±)
H2A (±)
H2B (±)
FDG
R (±)
V1 (±)
V2 (±)
© Semiconductor Components Industries, LLC, 2014
October, 2014 − Rev. 2
Imager
INPUT REQUIREMENTS
Minimum Typical
4.9
−5.1
18
−21
V V
min threshold
0 ±0.1
0
±0.1
0 ±0.1
0 ±0.1
0 ±0.1
0 ±0.1
0 ±0.1
0 ±0.1
EVAL BOARD USER'S MANUAL
KAI−04022 CCDs with the specified performance at
40 MHz pixel clocking rate and nominal operating
conditions. (See the KAI−4011 / KAI−4021 / KAI−04022
performance specifications for details).
For testing and characterization purposes, the KAI−4011 /
KAI−4021 / KAI−04022 Imager board provides the ability
to adjust many of the CCD bias voltages and CCD clock
level voltages by adjusting potentiometers on the board. The
Imager Board provides the means to modify other device
operating parameters (CCD reset clock pulse width, VSS
bias voltage) by populating components differently on the
board.
Maximum
5.0 5.1
1400
−5.0 −4.9
200
20 21
175
−20 −18
150
V Units
max
2.4 V
2.4 V
2.4 V
2.4 V
2.4 V
2.4 V
2.4 V
2.4 V
1
www.onsemi.com
Units
V
mA
V
mA
V
mA
V
mA
Comments
H1A clock
H1B clock
H2A clock
H2B clock
Fast Dump clock
Reset clock
V1 clock
V2 clock
Publication Order Number:
EVBUM2279/D
