- Page 1 HPE Aruba Networking BR-150 5G Cellular Bridge Installation Guide...
- Page 2 Hewlett Packard Enterprise Company. To obtain such source code, please check if the code is available in the HPE Software Center at https://myenterpriselicense.hpe.com/cwp-ui/software but, if not, send a written request for specific software version and product for which you want the open source code.
-
Page 3: Table Of Contents
Hardware Overview Installation Before You Begin Precautions Selecting a Location SIM Tray Installation IP55 Kit Installation Mounting the HPE Aruba Networking BR-150 5G Cellular Bridge Verifying Post-Installation Connectivity Specifications, Safety and Compliance Specifications Medical Regulatory Model Name Safety and Regulatory Compliance... -
Page 4: About This Guide
About This Guide About This Guide This document describes the hardware features of the HPE Aruba Networking BR-150 5G Cellular Bridge. It provides a detailed overview of the physical and performance characteristics of the BR-150 5G Cellular Bridge and explains how to install the BR-150 5G Cellular Bridge. -
Page 5: Hardware Overview
Chapter 2 Hardware Overview Hardware Overview HPE Aruba Networking BR-150 5G Cellular Bridge is a cloud-managed 5G cellular bridge with dual multi- gigabit Ethernet ports (2.5GbE) that provides wired WAN Ethernet connectivity, enabling high-speed network connectivity for business critical operations. -
Page 6: System Status Led
System Status LED Cellular Status LED Central Connection Status LED The status LEDs can be enabled or turned off by the system management software. System Status LED Table 2: System Status LED Color/State Meaning No lights The BR-150 5G Cellular Bridge has no power Red- Solid The BR-150 5G Cellular Bridge has a system error and requires immediate action... - Page 7 The BR-150 5G Cellular Bridge is trying to connect to Central or there is a problem connecting to Central. Amber- Flashing The BR-150 5G Cellular Bridge has a problem connecting to Central. Figure 2 Side View Kensington Security Slot HPE Aruba Networking BR-150 5G Cellular Bridge | Installation Guide...
-
Page 8: Ethernet Ports
Figure 3 Rear View Figure 4 Bottom View DC Power Slot Reset Button USB-C console USB-A 3.0 Nano SIM Tray E0 Ethernet Port E1 Ethernet Port (PoE) Ethernet Ports The BR-150 5G Cellular Bridge is equipped with two Ethernet ports E0 and E1. Both the E0 and E1 ports are 100/1000/2500 Base-T, auto-sensing MDI/MDX, which supports uplink connectivity when linked by an Ethernet cable. -
Page 9: Power Sources
Ethernet port. BR-150 5G Cellular Bridge supports a 12V/48W AC/DC power adapter. The power adapter is not included with the package, it is sold separately. To purchase the power adapter separately, contact your HPE Aruba Networking sales representative for details and assistance. Part Number... - Page 10 SIM Tray The BR-150 5G Cellular Bridge is equipped with a single nano-SIM tray. Hardware Overview |...
-
Page 11: Installation
Installation Installation All HPE Aruba Networking devices should be professionally installed by a professional installer. The installer is responsible for ensuring that grounding is available and meets applicable national and electrical codes. Failure to properly install this product may result in physical injury and/or damage to property. -
Page 12: Selecting A Location
Do not disassemble the BR-150 5G Cellular Bridge. Selecting a Location The HPE Aruba Networking BR-150 5G Cellular Bridge , like other network and computing devices, requires the following “electronic- friendly” environment. Reliable power Verify that your electrical outlet is compatible with the BR-150 5G Cellular Bridge power supply. - Page 13 HPE Aruba Networking also provides the single nano-SIM tray kit as a spare kit for the BR-150 5G Cellular Bridge. The spare SIM tray kit comes with an ejector pin that is used to remove the SIM tray from the device for installing the SIM card into the tray slot.
- Page 14 Part Number Description S4P36A HPE ANW BR-150 SIM Spare Tray Kit Installation |...
-
Page 15: Ip55 Kit Installation
IP55 Kit Installation The IP55 kit is not included with the package. To purchase the IP55 kit, contact your HPE Aruba Networking sales representative for details and assistance. Part Number Description S3M48A HPE ANW BR-150 IP55 Spare Kit To connect a cable and attaching the IP55 kit to the BR-150 5G Cellular Bridge unit, follow these steps: All illustrations depict the RJ45 cable installation as reference. - Page 16 4. Align the IO cap with the hole in the IP55 kit and insert the IO cap into the IP55 kit. If any opening on the IP55 kit is not used to connect a cable, make sure to cover the hole using the IO cap.
-
Page 17: Mounting The Hpe Aruba Networking Br-150 5G Cellular Bridge
Mounting the HPE Aruba Networking BR-150 5G Cellular Bridge The BR-150 5G Cellular Bridge can be mounted on a wall or ceiling by using a compatible mount kit. HPE Aruba Networking provides several mount kits to use with the BR-150 5G Cellular Bridge. These mount kits are available as accessories and must be ordered separately. -
Page 18: Verifying Post-Installation Connectivity
AP-MNT-E Mount Kit Installation Guide ceiling All HPE Aruba Networking devices should be professionally installed by a professional installer. The installer is responsible for ensuring that grounding is available and meets applicable national and electrical codes. Failure to properly install this product may result in physical injury and/or damage to property. -
Page 19: Specifications, Safety And Compliance
Chapter 4 Specifications, Safety and Compliance Specifications, Safety and Compliance This chapter provides an overview of the HPE Aruba Networking BR-150 5G Cellular Bridge specifications, safety and compliance information. Specifications Electrical Ethernet E0 and E1 port: Supports 100Base-T/1000Base-T/2500GBase-T Power E1 Power over Ethernet (PoE) port: 802.3at compliant source or 12VDC (18W or greater) AC/DC power adapter. -
Page 20: Regulatory Model Name
This device is intended for indoor use in professional healthcare facilities. This device has no IEC/EN60601-1-2 essential performance. Compliance is based on the use of HPE Aruba Networking approved accessories. Refer to the HPE Aruba Networking BR-150 5G Cellular Bridge data sheet. - Page 21 Innovation, Sciences et Développement économique Canada Cet appareil numérique de Classe B répond à toutes les exigences de la réglementation canadienne sur le matériel brouilleur. HPE Aruba Networking BR-150 5G Cellular Bridge | Installation Guide...
- Page 22 EU & UK Declaration of Conformity Compliance is only assured if Hewlett Packard Enterprise approved accessories as listed in the HPE Aruba Networking BR-150 5G Cellular Bridge data sheet are used.
- Page 23 ауданы, Әл-Ф араби даңғылы, 77/7, Т елеф он/ф акс: +7 727 355 35 50 Ukraine Hereby, HPE Aruba Networking declares that the radio equipment type [The Regulatory Model Number [RMN] for this device can be found in the Regulatory Model Name section of this document] is in compliance with Ukrainian Technical Regulation on Radio Equipment, approved by resolution of the CABINET OF MINISTERS OF UKRAINE dated May 24, 2017, No.
-
Page 24: Proper Disposal Of Hewlett Packard Enterprise Equipment
Х ’Ю ЛЕ Т Т П АК АР Д Е НТ Е Р П Р АЗ , 6280 АМЕ Р ИК А Ц Е НТ Р Д -Р , С АН-Х О С Е , К АЛІФ О Р НІЯ 95002, С ША. Proper Disposal of Hewlett Packard Enterprise Equipment Hewlett Packard Enterprise equipment complies with countries' national laws for proper disposal and electronic waste management. -
Page 25: European Union Rohs
0.1 weight % and 0.01 weight % for cadmium, except for the exemptions set in Schedule II of the Rule. China RoHS HPE Aruba Networking products also comply with China environmental declaration requirements and are labeled with the “EFUP 50” label shown at the left. - Page 26 Specifications, Safety and Compliance |...
-
Page 27: Taiwan Rohs
Taiwan RoHS Turkey RoHS material content declaration Türkiye Cumhuriyeti: AEEE Yönetmeliğine Uygundur HPE Aruba Networking BR-150 5G Cellular Bridge | Installation Guide...
