KwikGoal 2B3706 Assembly Instruction Manual

ASSEMBLY INSTRUCTIONS FOR 2B3706, (W & SW) FUSION HIGH SCHOOL MATCH GOAL
1. Unpack all parts and check for damage that may have occurred during shipping. If damage has occurred,
notify trucking company immediately. Lay out all parts. Remove all cardboard and packaging immediately.
Wet or damp packaging may damage contents.
2. Read through entire instruction before beginning assembly and installation.
Date of
manufacture
sticker
This goal has been designed to be used for the game of soccer only. Goal posts must be anchored AT ALL TIMES
and shall be secured against overturning. Do not climb on the net or goal framework at any time! All fastenings
must be checked to insure they are fully tightened before and after each use of this product. Goal posts not in use
must be disassembled and properly stored in a safe, secure area (See included Guidelines for Moveable Soccer Goal
Safety.). Assembled goal posts should not be left unattended. Remove nets when goals are not in use. Do not use
this equipment during the threat of high winds. Goal posts should be checked for safety before and after each use.
All warning and safety labels included with this product must be visible at all times.
Any modifications to this or any Kwik Goal product will void any and all warranties.
Part#
UZ1421
UZ1477
Left Post (1)
(Part# UZ1422)
86"
140 Pacific Drive Quakertown, PA 18951
(P) 215-536-2200 / (P) 800-531-4252 / (F) 215-536-4309 / (F) 800-778-8869
Visit our website @ kwikgoal.com
Base (2)
Goal#
2B3706 2B3706W
2B3706SW
94"
Crossbar (2)
(Part# UZ399)
280"
***CAUTION***
2014, Rev 2018, Kwik Goal Ltd.
®
Right Post (1)
(Part# UZ1423)
86"
NZ362 Rev. 07/25/18
