1. Unpack all parts and check for damage that may have occurred during shipping. If damage has occurred,
notify Kwik Goal immediately. Lay out all parts. Remove all cardboard and packaging immediately. Wet or
damp packaging may damage contents.
2. Read through entire instruction before beginning assembly and installation.
Parts
Swivel Wheel Mounting Bracket (4)
(Part# UZ1356)
Swivel Wheel (4)
(Part# VZ629)
This goal has been designed to be used for the game of soccer only. Goal posts must be anchored AT ALL TIMES
and shall be secured against overturning. Do not climb on the net or goal framework at any time! All fastenings
must be checked to insure they are fully tightened before and after each use of this product. Goal posts not in use
must be disassembled and properly stored in a safe, secure area (See included Guidelines for Movable Soccer Goal
Safety.). Assembled goal posts should not be left unattended. Remove nets when goals are not in use. Do not use
this equipment during the threat of high winds. Goal posts should be checked for safety before and after each use.
All warning and safety labels included with this product must be visible at all times.
Any modifications to this or any Kwik Goal product will void any and all warranties.
ASSEMBLY INSTRUCTIONS FOR SWIVEL WHEELS
Rubber Pad (8)
(Part# VZ654)
***CAUTION***
140 Pacific Drive Quakertown, PA 18951
800-531-4252 Kwikgoal.com
©
2019 Kwik Goal Ltd.
Mounting Bracket Pin (4)
Part#
Dim (A)
TZ347
3-5/16"
2B3306SW
TZ348
5-5/8"
2B2001SW
TZ378
4-3/16"
2B3006SW
Cable Lanyard (4)
(Part# VZ653)
12"
Goal Model Number
2B3406SW
2B3706SW
2B3806SW
2B9006SW
-
-
(A)"
Hairpin Cotter (4)
(Part# TZ351)
-
2B9004SW
-
NZ346 Rev. 09/30/22
Advertisement
Table of Contents
Related Manuals for KwikGoal 2B3306SW
Summary of Contents for KwikGoal 2B3306SW
- Page 1 2. Read through entire instruction before beginning assembly and installation. Parts Mounting Bracket Pin (4) Swivel Wheel Mounting Bracket (4) Part# Dim (A) Goal Model Number (Part# UZ1356) TZ347 3-5/16” 2B3306SW 2B3406SW 2B3706SW TZ348 5-5/8” 2B2001SW 2B3806SW 2B9006SW 2B9004SW TZ378 4-3/16”...
- Page 2 If this is not practical, store movable soccer goals in a place where children cannot have access to them. 10. Fully disassemble goals for seasonal storage. 140 Pacific Drive Quakertown, PA 18951 800-531-4252 Kwikgoal.com © 2019 Kwik Goal Ltd. NZ346 Rev. 09/30/22...
- Page 3 Mounting Bracket Rubber Pad Add Pad For 2B3806SW 2B3706SW 2B3306SW 5. Attach mounting bracket pin to swivel wheel bracket. To tighten lock nut, insert a phillips screwdriver in Swivel Wheel hole on mounting bracket pin. Orient hole to bracket as shown.
- Page 4 6. Attach swivel wheel assembly on the outside of goal frame by lifting goal frame at wheel locations Anchor Hole and insert mounting bracket pin into base (NO Bushing) bushing. Never install pin into anchor hole. Base Bushing Note: Attach one wheel at a time and secure in place (See step 7 &...
- Page 5 10. Grease wheels and casters as needed to keep them spinning freely. AT ALL TIMES Go to kwikgoal.com for additional product information. ***CAUTION*** This goal has been designed to be used for the game of soccer only. Goal posts must be anchored AT ALL TIMES and shall be secured against overturning.
