NEO HD Powered Stair
Climbing Hand Truck
Important Startup Instructions
Read the Owners Manual thoroughly before first use.
Date of Purchase: ________________________
MAGLINE
INC.
®
1205 West Cedar Street
Standish, Michigan 48658
1-800-MAGLINE (624-5463)
Email: customerservice@magliner.com
www.magliner.com
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Magliner NEO
Summary of Contents for Magliner NEO
- Page 1 NEO HD Powered Stair Climbing Hand Truck Important Startup Instructions Read the Owners Manual thoroughly before first use. Date of Purchase: ________________________ MAGLINE INC. ® 1205 West Cedar Street Standish, Michigan 48658 1-800-MAGLINE (624-5463) Email: customerservice@magliner.com www.magliner.com...
-
Page 2: Table Of Contents
CONTACT � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 24 1-800-MAGLINE (624-5463) www.magliner.com... -
Page 3: Introduction
INTRODUCTION Congratulations! Thank you for purchasing the Magliner HD Powered Stair Climbing Hand Truck. You have chosen a unit especially designed for carrying loads of up to 725 lbs. using the very latest stair climber technology for negotiating different types of steps and stairs safely and efficiently. -
Page 4: 1� Safety Guidelines / Technical Data
A: Sliding Arm - B: Dolly-System • Each time before starting up the hand truck, make sure that the protection system is properly folded away (retracted, figure D). 1-800-MAGLINE (624-5463) www.magliner.com... -
Page 5: Technical Data
Climbing speed II 485 lbs: approx. 15 steps/min, 725 lbs.: approx. 10 steps/min, Nose dimensions 20.85 x 7.2 in. 1�4� TECHNICAL DATA OF QUICK-CHANGE BATTERY UNIT Weight: 3.5 lbs. Capacity: 7.2 Ah Voltage: 29 VDC Battery type: Lithium ion 1-800-MAGLINE (624-5463) www.magliner.com... -
Page 6: 2� Control Features
2� CONTROL FEATURES 2�1� UNI MODEL Figure 1 1. Up/Down button 2. Handlebar 3. Control unit 4. Quick-change battery pack 5. Climber unit 6. Main wheels 1-800-MAGLINE (624-5463) www.magliner.com... -
Page 7: Control Unit
2�2� FOLD MODEL Figure 2 1. Up/Down button 2. Handlebar 3. Control unit 4. Handle adjustment lever 5. Quick-change battery pack 6. Climber unit 7. Main wheels 1-800-MAGLINE (624-5463) www.magliner.com... - Page 8 2�3� DOLLY MODEL Figure 3 1. Up/Down button 2. Handlebar 3. Control unit 4. 4 wheel attachment 5. Quick-change battery pack 6. Climber unit 7. Main wheels 1-800-MAGLINE (624-5463) www.magliner.com...
- Page 9 2�4� FOLD-L MODEL Figure 4 1. Up/Down button 2. Control unit 3. Handlebar 4. 4 wheel attachment 5. Quick-change battery pack 6. Climber unit 7. Main wheels 1-800-MAGLINE (624-5463) www.magliner.com...
- Page 10 Use the speed switch to select higher or lower climbing speeds. The stair climbing speed depends on the model, see Technical Data section 1.3. The lower speed is recommended for beginners, heavy loads and difficult situations. Press the speed button for approx. 10 seconds to activate the stair light. 1-800-MAGLINE (624-5463) www.magliner.com...
-
Page 11: Up/Down Switch On Handlebar
Figure 8 1. Activation button charging status display 2. LED display 3. Visualization Pressing the activation button switches on the LED charging status indicator; if all five LEDs light up, the quick change battery pack is 100% charged. 1-800-MAGLINE (624-5463) www.magliner.com... -
Page 12: Switching Off
3�1 FITTING THE BATTERY PACK • Align the battery pack between the guides on the frame. • Gently press the battery pack downwards. The battery pack clicks into place. • Your hand truck is ready for use. 1-800-MAGLINE (624-5463) www.magliner.com... -
Page 13: Removing Battery Pack
The cycle is repeated until the switch is released (Continuous mode). In Single-Step mode, the hand truck stops when the main wheels reach the next step. 1-800-MAGLINE (624-5463) www.magliner.com... - Page 14 For climbing DOWN start on the inside� If you do start moving too close to the banisters/wall then shift the unit to the side by reversing (on a landing or wider step if possible) and start again at a tighter angle. 1-800-MAGLINE (624-5463) www.magliner.com...
-
Page 15: Enabling The System
IMPORTANT Make sure that the system is switched ON again before starting each movement downwards to the next step. This is easily recognizable by the green status indicator. Only then is the edge braking system engaged. 1-800-MAGLINE (624-5463) www.magliner.com... -
Page 16: Automatic Switch-Off After Extended Period Of No Operation
Correct functioning of the step edge braking system is essential for safe operation of the hand truck. It is therefore essential that you check the function of the step edge braking system each time before you use the hand truck. 1-800-MAGLINE (624-5463) www.magliner.com... -
Page 17: 6�Charging The Quick-Change Battery Pack
If the powered product is going to be stored and/or not in regular use, the batteries must go through a full charge cycle every 2 weeks to ensure battery life and duty cycle. 1-800-MAGLINE (624-5463) www.magliner.com... -
Page 18: Charger Unit
6�1�1 TECHNICAL DATA Mains voltage supply (50/60 Hz, 1.8 A (max)): 100-240 V AC Nominal rating (input): 24 W Charging voltage: 24 V DC Theoretical charging current: 2.0 A Safety approval: cUL, CE 1-800-MAGLINE (624-5463) www.magliner.com... - Page 19 • The device may only charge batteries that comply with EN directives (and show a CE or GS mark). 6�1�3 USE ONLY FOR THE PURPOSE INTENDED The charger is designed exclusively for charging the original lithium ion rechargeable batteries� 1-800-MAGLINE (624-5463) www.magliner.com...
-
Page 20: 7� Accessories And Options
• Repairs, installation or other work have been carried out by unauthorized persons. • The instructions in this manual are not complied with. • Non-Sano components are fitted or linked to the hand truck. • Original components are removed. 1-800-MAGLINE (624-5463) www.magliner.com... -
Page 21: 10� Ce Declaration Of Conformity
EU directive for machines 2006/42/EG, appendix IIA. Any changes made to the product without our prior consent render this declaration void. Ing. Jochum Bierma, Managing Director 1-800-MAGLINE (624-5463) www.magliner.com...
