Magliner MAG220 Assembly Instructions

Trayless four bottle water hand truck

*NOTE: Load and unload in the horizontal position only - Do

not stand the truck in the upright position when loaded with

water bottles.

Magline, Inc., 1205 West Cedar Street, Standish, MI 48658 • (800) 624-5463 • (989) 512-1000

Assembly Instructions

Trayless Four Bottle

Water Hand Truck

www.magliner.com

Table of Contents:

Nose, Wheel Brackets, Axle

Assembly .................................... 2-3

Handle, Rear Brace, Support Loop

Brace Assembly ............................. 4

Wheel Assembly ........................... 5

Table of Contents

Need help?

Do you have a question about the MAG220 and is the answer not in the manual?

Page 1 *NOTE: Load and unload in the horizontal position only - Do not stand the truck in the upright position when loaded with water bottles. www.magliner.com Magline, Inc., 1205 West Cedar Street, Standish, MI 48658 • (800) 624-5463 • (989) 512-1000...
Page 2 ASSEMBLE THE NOSE, WHEEL BRACKETS AND AXLE TO THE FRAME - 8" WHEELS ONLY Item Description Qty. Part No. Nose plate assembly 301482 TOOLS REQUIRED • 1/2” DEEP WELL SOCKET Frame 3014680 AND RATCHET Roll pin for axle 190104 • 7/16” DEEP WELL SOCKET Axle - 18"...
Page 3 ASSEMBLE THE NOSE, WHEEL BRACKETS AND AXLE TO THE FRAME - 10" WHEELS ONLY Item Description Qty. Part No. Nose plate assembly 301482 TOOLS REQUIRED Frame 3014680 • 1/2” DEEP WELL SOCKET Roll pin for axle 190104 AND RATCHET Axle - 18" long 22101 •...
Page 4 ASSEMBLING THE HANDLE, REAR BRACE AND SUPPORT LOOP BRACE (ALL MODELS) Item Description Qty. Part No. Handle with black grip 301469 Pan head machine screw - 1/4"-20 x 3/4" long 80256 Pan head machine screw - 1/4"-20 x 1-1/4" long 80104 Hex lock nut - 1/4"-20 80675...
Page 5 5. Repeat steps 1-4 for the second wheel. Figure 6 YOU ARE NOW READY TO PUT YOUR MAGLINER HAND TRUCK TO WORK.* *NOTE: Load and unload in the horizontal position only - Do not stand the truck in the upright position when loaded with water bottles.
