Zamel SDL-01 Manual

One-colour DALI-PWM
LED controller
SDL-01
Mounting in a Ø60 Mounting
junction box indoor only
The SDL-01 controller is a one-channel LED dimmer designed to operate in lighting
installations by means of DALI protocol (Digital Addressable Lighting Interface). The
controller operates as a SLAVE device in a lighting installation and requires control by
a MASTER controller. SDL-01 is designed to be mounted in a Ø60 junction box. The
device is equipped with one transistor output with a maximum current load of 6A
operating with the PWM modulation. Wide range of nominal supply voltage 10÷48
V DC allows to control the majority of available LED lighting sources (LED tapes,
LED modules and voltage controlled LED lighting fi ttings). Address programming
in SDL-01 is possible only in the automatic mode (by means of the DALI controller).
The device enables in addition to a fl uent adjustable brightening/dimming and ON/
OFF control, a parameterization of time, rate and a maximum / minimum level of
brightening/dimming, etc.
Device is compatible with DALI standard.
tel: +48 32 449 15 00, fax: +48 32 449 15 02
10÷48 V DC / 0,3 W; IP20
weight: 27 g
The symbol means selective
collecting of electrical and electronic
equipment. It is forbidden to put
the used equipment together with
other waste.
Declaration of Conformity is at www.ledix.pl
Made in Poland
SCAN
technical
data
Zamel Sp. z o.o.
43-200 Pszczyna, ul. Zielona 27
e-mail: ledix@ledix.pl, www.ledix.pl
One-colour DALI LED
controller
SDL-01 EN Ver. 01
One-colour DALI-PWM
LED controller
SDL-01
10 ÷ 48 V DC
