—— Instruction Manual ——
BM10
Set-up Instructions Competition Badminton System
Item
Qty
Description
A
2
Badminton Post (BM10U)
B
1
Badminton Net (BM10N)
¨ Inspect all contents prior to installation. Report any missing parts to dealer immediately.
¨ Read all instructions before proceeding.
1. If applicable install BM21 Sockets and Floor Plate (C) in accordance with the instructions provided with
BM21.
2. Insert the Badminton Posts (A) into the BM21 Floor Sockets and Floor Plates (C).
3. Measure from the playing floor to the groove in the top of the posts. This measurement should be 61".
See Figure 1.
4. To adjust the height of the post to 61" adjust the foot pad on the bottom of each post.
5. When both posts are at the correct height, position the top net rope over the grooves on the top of the
Badminton Posts (A) and into the rope tensioning cleat on the outside of each Badminton Post (A).
See Figure 2
6. Tension the top rope until the net is 60" high in the center of the court. See Figure 2.
7. Tie the top corner laces around the top of the Badminton Posts (A) to center the net between the
Badminton Posts (A) and hold the net tight against the posts.
8. Tie the bottom corner laces around the Badminton Posts (A) using the black rubber bumper on the outside
of the posts to stretch the net downward. See Figure 2.
9. To use BM10 for pickleball follow instructions #1 - #4 above, then move to #10.
10. Run the Badminton Net (B) top rope through the top loop on the inside of the posts, then over the top of
the posts, and then attach to the rope cleats. The top of the net should be 36" from the floor. See Figure 3.
11. Tie the top and bottom net laces to the loop near the bottom of the posts.
Implementation Date: 3/10/23
/
P A R T S L I S T
Rev: 2
N.J.C
Item
Qty
Description
C
1
BM21 Floor Socket and Floor Plates
(ordered Separately)
File: I:\Publisher\Instructions\Badminton
1
Customer Service
(800) 247-7668
Ref#: 960825
L.M.
