- Page 1 Model 32X-R 12 MINUTES RenuvaSkin L3200 USER MANUAL MARK76B0008 Rev 2 Approved on 12/2/24 by JCH...
- Page 2 L3200 C O N G R A T U L A T I O N S on your ProSun ® purchase! Please make sure you read this manual carefully before using this equipment and specifically the maintenance schedule. Keep this manual available for future reference.
-
Page 3: Table Of Contents
L3200 Table of Contents Important Customer Information ....................... Who Should Use, Read, & Understand this Manual ............Warning Signs & Symbols …..........................Preparing the Product For Use ........................Export …................................Transportation …............................Delivery …................................ Ventilation …..............................Installation & Set-up …........................... Environmental Conditions for Transport &... - Page 4 L3200 Normal Equipment Operation & Software …………………………........…… Operating Modes ……………………………………………………………...........….. Standby Mode ………………………………………………………............. In Session Mode…………..…………………………………….............. Cool Down Mode ………………………………………………………..........……….. Service Mode....…..……………………………………..........……… Storing the Equipment........................Decommissioning Your Unit ..................... Storage .............................. Disposal ............................Control Functions ............................ Reading the Hour Counters and Software..............……… Error Messages ………………………………………………………………….............………...
-
Page 5: Important Customer Information
A copy of the user manual should be readily available.This manual may include features that are not included for your bed. Any service work outside of the preventative care table in this manual should be done by a ProSun authorized technician. Warning signs and symbols Danger and Safety Symbols: Danger Hazard exists for human health. - Page 6 L3200 Symbols found on equipment and packaging: Follow and read instructions thoroughly prior to using equipment. Keep equipment dry. Fragile. This way up. Use only long forks on the fork lift and only lift on the correct openings. Do not double stack. This symbol indicates that the items shall not be vertically stacked, either because of the nature of the transport packaging or because of the nature of the items themselves.
- Page 7 L3200 Protective earth connections. Recyclable Material Polystyrene Cardboard Mixed Paper Wood Waste of electrical and electronic equipment must not be disposed as unsorted municipal waste. It must be collected separately, and must be disposed as per local regulations. Alternating Current. Single Phase Three phase alternating current.
-
Page 8: Preparing The Product For Use
ProSun does not assume any liability if there is non- compliance outside of the intended sale territories of the United States or Canada. The exporter assumes their own risk by removing this equipment outside of the United States or Canada. -
Page 9: Delivery
Coordinate with ProSun installation department to set up delivery and installation details. In a commercial setting an external timer is required. ProSun recommends to use this accesory (T-Max Flushmount G2). Ventillation: The equipment must always have proper ventilation. - Page 10 Each should be inspected to ensure that no wires have been grounded or are left open. ProSun certified technicians are not responsible for the final installation of the electrical system, the electrical contractor or his designee should be present to make the final electrical connection upon completion of the installation of the equipment.
-
Page 11: Comissioning Of The Equipment
L3200 Commissioning of the equipment The equipment is initially commissioned by a certified ProSun technician. The equipment will be properly assembled and handed over ready for us. In order to properly commission the equipment, the business owner must ensure that the location is ready prior to the equipment being installed. -
Page 12: Equipment Components & Description
L3200 Equipment Description RenuvaSkin L3200 Canopy Head end of Unit 2. Cover plate 3. Deco (optional) 4. Ballasts 5. Side Bars 6. Endcaps Canopy Acrylic Bench Lamps 2. Cover plate 3. Side Bar 4. End Cap 5. Bench Acrylic 6. Hinges Sound system (optional) 8. -
Page 13: Lamp Configuration
L3200 Lamp configuration- The use of non approved Lamps voids the warranty! RenuvaSkin S4200 Quantity Name Length Watts Part Number RenuvaSkin 120W 79" inches 120W LAMP8070060 2 Meters RenuvaSkin 120W 79" inches 120W LAMP8070060 2 Meters RenuvaSkin L3200 - Spare parts Acrylic Bench ACRY7821786 Acrylic Canopy... -
Page 14: Dimensions
L3200 33.5 in Dimensions 92.5 inch 45.0 in 92.5 inch 45.2 in 53.7in 90.1 inch 20.0 in 47.2 in 92.5 inch 49.2 in 90.1 inch 61.0 in 47.6 in A = 92.5 inches B = 45.2 inches A1 = 90.1 inches B1 = 20 inches B2 = 47.2 inches B3 = 47.6 inches... -
Page 15: Technical Data
L3200 Technical Data Electrical Specifications RenuvaSkin L3200 Power consumption rating: 12 Amp Electrical Rating: 230V 3~ 12A 60Hz Rated Fuses: 25 amp 3-pole Continuous Operation: Continuous operation for a maximum of 15 minutes. Load on the base plate: Max 250lbs or 113 Kg Equipment Weight: Approx 550 lb or 249 kg Operating Humidity:... - Page 16 Please insure that your electrician and/or installer, reads this user’s manual carefully prior to the installation of your ProSun unit. You will need a buck booster if voltage requirements are not met. Service personnel should be authorized by ProSun to perform work on equipment and should have knowledge of equipment and read the full manual.
- Page 17 L3200 Electrical Connections Live Components Risk of fatal injury due to electrical shock when touching live parts. DANGER! Risk of electrical Shock To avoid the risk of electrical shock, this equipment must only be connected to a supply mains with protective earth. WARNING! Both the power supply and the related connection work must comply with national standards.
-
Page 18: Connecting Equipment To External Timer
L3200 Connecting Equipment to External Timer (T-Max Timers are sold Separated) OPTION 1 Connecting T-Max system to the unit using the Wall Mount Enclosure In the Case that you have to install the T-max systems using the wall mount enclosure follow these steps. - Page 19 L3200 2. Attach the T-max 3W Flush mount to the Wall mount enclosure using the screw that comes with your T-max. 2.1. Remove the POWER cable, using a small flat head screw driver 2.2. Separate the T-max Face plate from the internal frame.
- Page 20 L3200 2.3. Using the screws coming with the T-max attach the plastic enclosure 3. Trace cables on the back of the mount enclosure 3.1. Using the two holes on the back of the T-max enclosure past these cables. 3.1.1. J3 Contact – Coming from the unit 3.1.2.
- Page 21 L3200 4. Connect all the Cables and wires to the correspond position in the T-Max. 4.1. See Bellow diagram and Pictures POWER: Connect 9-12V, power supply Front View of T-Max Rear View of T-Max to this terminal. EXT START POWER RJ-11: Connects to G2 Access Point for Wireless Communications.
- Page 22 L3200 4.2. After All Wires are connects to the t-max mare sure to properly secure with zip ties 4.3. Finally close the face plate lip and install T-max box on the wall.
-
Page 23: Is Already Connected
L3200 OPTION 2 Cables for T-max had been run trough the wall and the T-max is already connected. 5. In the Case that all the Cables (RJ-2, J3 Contact and EXT Start), had been previously run inside the walls and the T-max is already install you will need to follow this steps. 5.1.1. -
Page 24: Before Your Session
L3200 Before your Session Check for any conditions mentioned in the manual that may prevent you from using the equipment. Make-up and cosmetics Do not wear make-up when using the equipment. Remove all make-up prior to session. Make-up clogs the pores in your face. Jewelery Remove all jewelery prior to use, including piercings. -
Page 25: After The Session
Non-approved cleaning agents should not be used, especially products including lysoform, ethyl alcohol or other liquids containing alcohol. If used the warranty will be voided! ProSun® recommends the use of Lucasol One Step when cleaning acrylic sheets. Acrylics in equipment are extremely porous and should not be cleaned/disinfected with non-approved products. -
Page 26: Operation Of The Equipment
L3200 Operation of Equipment Obligations of the business operator • All danger and safety labels should be attached to the equipment and clearly visible to the user. You should not remove these labels at any time! • No safety equipment ( i.e. temperature sensors) may be removed, deactivated or otherwise bypassed from the equipment, as it can cause safety issues and impair the proper functioning of the equipment. -
Page 27: Normal Equipment Operation & Software
L3200 Normal Equipment Operation and software Operating Modes: There are 4 different operating modes for this equipment. Standby Mode: The bed is in an idle state, it is connected to the power but is currently not in use. The lamps in the unit are not turned on at this time. - Page 28 L3200 In Session Mode The following description is for a unit that has all possible features, some of these features may not be available for your unit or market. Starting the session The session will automatically begin after the external timer delay time has expired. During the preset delay time the session can be started by manually pressing the START button (2)on the control panel, thereby overriding the delay time.
-
Page 29: Storing The Equipment
Waste of electrical and electronic equipment must be disposed as unsorted municipal waste. It must be collected separately, and must be disposed as per local regulations. Contact ProSun International or an authorized representative for information concerning the decommissioning of your equipment. -
Page 30: Control Functions
L3200 Control Functions Not all options shown below are applicable on this equipment and in the US Market. General Controls: Function Description Additional Information Start Switches the lamps on Stop Switches the lamps off Hit stop once to pause the session and hit stop twice to end session. - Page 31 L3200 Indicator Lights: All indicator lights will be on the display of the unit and will show green when ready to use or for selection purposes. The machine is set up for standard use with an external timer or a coinbox. If the machine must function without the external timer or coinbox, i.e.
- Page 32 L3200 Controls in combination with an external timer or for coin-operated use: The bed will be started automatically when the external timer or coin-operated equipment switches on. The equipment will pause when the “stop” button is pressed once. If stop is pressed more than once, the equipment will remain paused.
-
Page 33: Reading The Hour Counters And Software
L3200 Reading the hour counters and software To be able to read teh hour counter for the lamp hours, press the HIDDEN button and DECREASE body cooling button at the same time. The number that shows up multiplied by 10 is the total hours on your lamps. Press the HIDDEN button to exit. -
Page 34: Error Messages
To be able to read the hour counter for the lights, press the “hidden button” and “decrease body cooling” button simultaneously. WARNING: If one of these error messages appears on your display, you must stop using the unit immediately and contact ProSun. WARNING! -
Page 35: Care & Maintenance
Accidental reactivation can result in serious accidents. Immediately after deenergizing the equipment, secure all switches or fuses used for deenergizing against being switched on again. For more maintenance information please visit our website at: www.prosun.com/customer-service... -
Page 36: Basic Care Maintenance
The table below is a preventative care table that can be done by any unskilled person, if any service outside of this table is needed please contact ProSun immediately and this should only be done by a certified technician. -
Page 37: Cleaning & Disinfecting Acrylics
L3200 Lucasol 4-Step Cleaning Process wipe. bed is now sanitized. spray & wait 60 seconds. STEP 1 STEP 2 After use, spray the bed with Lucasol TM Wipe the bed surface to remove Lucasol TM and any lotion residue. The disinfeectant and sit for 60 seconds to kill 99.99% of bacteria, fungus, and virus. -
Page 38: Cleaning Plastic Surfaces
Maintenance by skilled persons: ProSun recommends having an annual inspection by a certified technician to review connections, check for lose wiring, check the power cords and review all other high voltage components. At this... -
Page 39: Troubleshooting Guide
Damage to equipment by user or Contact ProSun for replacement. cleaning Non-skilled person can replace acrylic. Any troubleshooting outside of the above mentioned guide should be done by a certified technician. Contact ProSun to schedule service with a certified technician. -
Page 40: Replacement Of Components
L3200 Replacement of Components WARNING: Before doing any work on this machine, whether it be an unskilled person or a certified technician, ALWAYS disconnect the power at the main circuit breaker(or, if the main power cable has a wall plug, pull it out). WARNING! IMPORTANT: Only use manufacturer-authorized replacement components. -
Page 41: Removing Acrylics
L3200 Replacing Acrylics WARNING: Before obtaining access to terminals, all power supply circuits must be unplugged. -
Page 42: Replacing The Lamps
L3200 Replacing the Lamps Remove acrylics before replacing lamps. Lamp replacement: Holding the lamp at both ends, turn it counter-clockwise until the bi-pins can slide easily out of the lamp holder socket, and slowly take it out of the unit. Clicks will be heard as the socket incrementally rotates. -
Page 43: Assembly Introduction
L3200 Assembly Introduction Required for assembly (not included): • Preferably 2 wrenches to tighten bolts and nuts • Power adapter kit (230V for commercial use, for warranty to apply voltage must be between 215-230 V) *Make sure you write the Serial Number (located on the Control Panel) down on the previous page and store the manual somewhere you can easily access. -
Page 44: Symbols
L3200 Symbols Warning symbol: People with long hair should wear a hairnet! Warning symbol: Wear the protective goggles provided Warning symbol: Attention please! Warning symbol: Sunbed should be disconnected from power source Warning symbol: Remove plug from socket Warning symbol: Not for household use Symbol: Facial tanner... -
Page 45: Assembly
L3200 Assembly... - Page 46 L3200 Assembly...
- Page 47 L3200...
- Page 48 L3200...
- Page 49 L3200...
- Page 50 L3200...
- Page 51 L3200...
- Page 52 L3200...
- Page 53 L3200...
-
Page 54: Warranty
What is covered: During the Limited Warranty period as specified below, PROSUN will be repair or replace any defective system or components found to be defective, at PROSUN’s sole discretion. Prior to making any repairs, the owner must provide PROSUN with information requested and perform basic troubleshooting. - Page 55 • Any damage caused by the failure of any supporting hardware not supplied by PROSUN. • Acrylic sheets, starters (igniters), lamps, blue and clear filter glass. • Tanning units, parts or components damaged in transit where PROSUN’S damaged goods policy is not followed by purchaser or purchaser’s designee.
- Page 56 ProSun representative. 2. A return shipping label will be provided. You will need to return the original or any unused parts to PROSUN unless otherwise advised in writing. If the original defective parts are not returned within 30 days, you will be responsible for the purchase charges for the parts.
- Page 57 L3200 Limitation of Liability: PROSUN shall not be liable for any loss, damages, or penalty resulting from failure to perform any of its obligations under this Agreement due to major force or any cause beyond its reasonable control. PROSUN’S LIABILITY UNDER OR FOR BREACH OF THIS AGREEMENT SHALL NOT EXCEED THE REFUND OF THE PURCHASE PRICE LESS REASONABLE RENTAL FOR PAST USE.
- Page 58 L3200 ProSun International 2442 23rd Street North St Petersburg, FL 33713 www.ProSun.com 727.825.0400 Contraindication: This Product Is Contraindicated For Use On Persons Under The Age Of 18 Years. “Contraindication: This Product Must Not Be Used If Skin Lesions Or Open Wounds Are Present.” “Warning: This Product Should Not Be Used On Individuals Who Have Had Skin Cancer Or Have A Family History Of Skin Cancer.”...
