ProSun RenuvaSkin 32J-R Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Model 32J-R
15 MINUTES
RenuvaSkin
L32
USER
MANUAL
MARK76B0003 Rev 7 Approved on 12/02/24 by JCH

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RenuvaSkin 32J-R and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for ProSun RenuvaSkin 32J-R

Summary of Contents for ProSun RenuvaSkin 32J-R

  • Page 1 Model 32J-R 15 MINUTES RenuvaSkin USER MANUAL MARK76B0003 Rev 7 Approved on 12/02/24 by JCH...
  • Page 2 C O N G R A T U L A T I O N S on your ProSun purchase! ® Please make sure you read this manual carefully before using this equipment and specifically the maintenance schedule. Keep this manual available for future reference.

  • Page 3: Table Of Contents

    Table of Contents Important Customer Information ....................... Who Should Use, Read, & Understand this Manual ............Warning Signs & Symbols …..........................Preparing the Product For Use ........................Export …................................Transportation …............................Delivery …................................ Ventilation …..............................Installation & Set-up …........................... Environmental Conditions for Transport & Storage ............Enviromental Conditions for Operation..................
  • Page 4 How to Operate the Equipment ……………………………............…… Equipment Operation ………..........…………………........…… Operating Modes ……………………………………………………………...........…... Standby Mode ………………………………………………………............. In Use Mode ………………………..……………………………….............. Cool Down Mode ………………………………………………………..........……….. Service Mode ……………………………………………………………..........……… Starting the Session…………………………..………………..........……… Operation during Session…………………….....……..........……… Stopping the Session…………..………….....……..........……… To Program your Unit Display......................Storing the Equipment.........................

  • Page 5: Important Customer Information

    A copy of the user manual should be readily available.This manual may include features that are not included for your bed. Any service work outside of the preventative care table in this manual should be done by a ProSun authorized technician. Warning signs and symbols Danger and Safety Symbols: Danger Hazard exists for human health.
  • Page 6 Symbols found on equipment and packaging: Follow and read instructions thoroughly prior to using equipment. Keep equipment dry. Fragile. This way up. Use only long forks on the fork lift and only lift on the correct openings. Do not double stack. This symbol indicates that the items shall not be vertically stacked, either because of the nature of the transport packaging or because of the nature of the items themselves.
  • Page 7 Protective earth connections. Recyclable Material Polystyrene Cardboard Mixed Paper Wood Waste of electrical and electronic equipment must not be disposed as unsorted municipal waste. It must be collected separately, and must be disposed as per local regulations. Alternating Current. Single Phase 26 7...

  • Page 8: Preparing The Product For Use

    ProSun does not assume any liability if there is non- compliance outside of the intended sale territories of the United States or Canada. The exporter assumes their own risk by removing this equipment outside of the United States or Canada.

  • Page 9: Delivery

    Coordinate with ProSun installation department to set up delivery and installation details. In a commercial setting an external timer is required. ProSun recommends to use this accesory (T-Max Flushmount G2). Ventillation: The equipment must always have proper ventilation.
  • Page 10 Each should be inspected to ensure that no wires have been grounded or are left open. ProSun certified technicians are not responsible for the final installation of the electrical system, the electrical contractor or his designee should be present to make the final electrical connection upon completion of the installation of the equipment.

  • Page 11: Comissioning Of The Equipment

    Commissioning of the equipment The equipment is initially commissioned by a certified ProSun technician. The equipment will be properly assembled and handed over ready for us. In order to properly commission the equipment, the business owner must ensure that the location is ready prior to the equipment being installed.

  • Page 12: Equipment Components & Description

    Equipment Description RenuvaSkin Ballasts - your unit may have different ballasts than shown in image 2. Canopy cover plate 3. Canopy Acrylic 4. Not available for this model 5. Shocks 6. Bench Acrylic Bench 8. Side Legs 9. Front Skirt...

  • Page 13: Lamp Configuration

    Lamp configuration- The use of non approved Lamps voids the warranty! RenuvaSkin L32 Quantity Name Length Watts Part Number RenuvaSkin 110W 75" inches 110W LAMP8070030 RenuvaSkin 100W 71" inches 100W LAMP8070020 RenuvaSkin L32 - Spare parts Acrylic Canopy ACRY-SHIP6012165 Acrylic Bench ACRY-SHIP6013539 Shocks GASP6014349...

  • Page 14: Dimensions

    Dimensions 47" Side view 14" L = 83" 35" Technical Data Electrical Specifications RenuvaSkin L32 Power consumption rating: 17 Amp Rated Voltage: 120V ~ 17A 60Hz Rated Fuses: 20 amp 2-pole Continuous Operation: Continuous operation for a maximum of 15 minutes.
  • Page 15 Please insure that your electrician and/or installer, reads this user’s manual carefully prior to the installation of your ProSun unit. Service personnel should be authorized by ProSun to perform work on equipment and should have knowledge of equipment and read the full manual.
  • Page 16 Electrical Connections Live Components Risk of fatal injury due to electrical shock when touching live parts. DANGER! Risk of electrical Shock To avoid the risk of electrical shock, this equipment must only be connected to a supply mains with protective earth. WARNING! Both the power supply and the related connection work must comply with national standards.

  • Page 17: Before Your Session

    Before your Red Light Session Check for any conditions mentioned in the manual that may prevent you from using the equipment. Make-up and cosmetics Do not wear make-up when using the equipment. Remove all make-up prior to session. Make-up clogs the pores in your face. Jewelery Remove all jewelery prior to use, including piercings.

  • Page 18: After The Session

    After the Red Light Session Cleaning All parts of the equipmnent that come in contact with the user must be cleaned and disinfected after each session. Cleaning is part of basic care that can be performed by qualified staff or service personnel.

  • Page 19: Operation Of The Equipment

    Operation of Equipment Obligations of the business operator • All danger and safety labels should be attached to the equipment and clearly visible to the user. You should not remove these labels at any time! • No safety equipment ( i.e. temperature sensors) may be removed, deactivated or otherwise bypassed from the equipment, as it can cause safety issues and impair the proper functioning of the equipment.

  • Page 20: Equipment Operation

    Equipment Operation Before turning on the equipment make sure you have proper warning signs at your location. We recommend permanently placing a Warning sign on the wall close to the bed such as the one below: Operating Modes: There are 4 different operating modes for this equipment. Standby Mode The bed is in an idle state, it is connected to the power but is currently not in use.

  • Page 21: Starting The Session

    Starting the session Press start once on the START button on the display. You will see the maximum minute time, here you will use the minus button to select the desired minutes for your session. Then press START again to turn on your session. If you do not push a button quickly enough the display will go blank and you will need to start this process again.

  • Page 22: Stopping The Session

    Stopping the Session If the time in the session runs out naturally then the unit will go into a 3 minute cool-down. However if you need to stop the session prior to end of the sesion you can do so by hitting the START/STOP Button.

  • Page 23: To Program Your Unit Display

    Service Mode When the unit is in standby mode, you can enter into the service or maintenance parameters. To Program your Unit Display Note: Start with a Blank Display Step 1: Enter into Program mode by Pushing B and D simultaneously for 10-30 seconds or until the display shows a 01.

  • Page 24: Storing The Equipment

    Waste of electrical and electronic equipment must be disposed as unsorted municipal waste. It must be collected separately, and must be disposed as per local regulations. Contact ProSun International or an authorized representative for information concerning the decommissioning of your equipment.

  • Page 25: Control Functions

    Control Functions Function Description Additional Information Start Use this button to start the session. Stop Use this button to stop or pause the session. Minus Decrease time Decrease cooling fan speed Plus Increase time Increase body cooling fan speed Face Lamp Not applicable for this bed Use this button to use the fan...

  • Page 26: Operations

    Operation Note: Typically Stand-alone mode is for residential use and Remote mode is for commercial use All units come standard in remote-mode Start Stand-alone mode: By depressing start once the “+ and –“ buttons can be used to set the time. Pressing for a second time will start the unit.
  • Page 27 Stand-alone mode: Face a. Reduce Session time Not Used in this bed b. Reduce body cooler speed Coin mode: a. Reduce body cooler speed Switch the body cooler on and off Stand-alone mode: a. Increase Session time b. Increase body cooler speed Coin mode: a.

  • Page 28: Error Messages

    Error messages Display messages: Overrule error (Main print and/or display print defective) Unit is overheating Communication error (No communication between switch print and display print) NOTE - When you receive one of the above error messages on your LCD display, you should stop using the unit and unplug it.

  • Page 29: Care & Maintenance

    Accidental reactivation can result in serious accidents. Immediately after deenergizing the equipment, secure all switches or fuses used for deenergizing against being switched on again. For more maintenance information please visit our website at: www.prosun.com/customer-service...

  • Page 30: Maintenance Schedule

    The table below is a preventative care table that can be done by any unskilled person, if any service outside of this table is needed please contact ProSun immediately and this should only be done by a certified technician.
  • Page 31 Lucasol 4-Step Cleaning Process wipe. bed is now sanitized. spray & wait 60 seconds. STEP 1 STEP 2 After use, spray the bed with Lucasol Wipe the bed surface to remove disinfeectant and sit for 60 seconds to Lucasol and any lotion residue. The kill 99.99% of bacteria, fungus, and virus.

  • Page 32: Cleaning Plastic Surfaces

    Maintenance by skilled persons: ProSun recommends having an annual inspection by a certified technician to review connections, check for lose wiring, check the power cords and review all other high voltage components. At this...

  • Page 33: Troubleshooting Guide

    Damage to equipment by user or Contact ProSun for replacement. cleaning Non-skilled person can replace acrylic. Any troubleshooting outside of the above mentioned guide should be done by a certified technician. Contact ProSun to schedule service with a certified technician.

  • Page 34: Replacement Of Components

    Unauthorized modifications and changes to the equipment and its controls are prohibited. ONLY USE ORIGINAL PARTS! Use of any other parts voids the warranty and ProSun will not be liable in any cases of damage or injury due to the use of these parts.

  • Page 35: Replacing The Acrylics

    Replacing the Acrylics Bend back the plastic grey strip Acrylic tool At the end of the bench or canopy you will find an acrylic tool. Remove it from the unit and use this to slide under the acrylic and lift it up gently. Pull back the acrylic sheet by hand first, then use the acrylic tool to remove the rest of the sheet.

  • Page 36: Replacing The Lamps

    Replacing the Lamps Once you have removed the acrlic you will want to unscrew and remove the metal lamp covers/ strips. Then with gloves on to protect the lamps from oils, twist the lamp and remove. When replacing the lamp twist the lamp back into position. Listen for 2 clicks to ensure the lamp is securely fastened.

  • Page 37: Assembly Introduction

    Assembly Introduction Required for assembly (not included): • 1 wrenches to tighten bolts *Make sure you write the Serial Number (located on the back of the canopy) down on the previous page and store the manual somewhere you can easily access. The Serial Number is MANDATORY to order parts for your unit, as well as, any customer service calls.

  • Page 38: Included Parts

    Included Parts Make sure all parts are included before you begin. 1X Plastic Front Skirt white - CVPL 6525156 2X Combi Arms 2X Gas Shocks FAMS6012171 GASP6012273 6X Combi Arm Screws T-Max Integrated Decoshield FASN1508828 SUBT1003012 2X Deco Shield Screws 2X Security Plates (optional) black FAMS6012236...

  • Page 39: Assembly

    Assembly bench Carefully remove the bench from box and keep it face down. *Optional Front Skirt (if you do not have a plastic front skirt go to step 3) Retrieve 1 Plastic front skirt (located in canopy box) Remove the screw from the leg. Insert plastic front skirt and screw in place.
  • Page 40 bench end cap filler Flip bench over. Retrieve 2 Combi Arms 6 Combi Arm Screws Remove the end cap filler. combi arm Insert combi arm into bench and secure with screws. Repeat these steps on other side.
  • Page 41 end cap filler canopy combi arm bench Remove the canopy from the box. Remove the end cap filler as done previously with the bench. While holding the canopy on each end attach it to the bench by sliding it onto the combi arms...
  • Page 42 Retrieve 2 security plates 4 security plate screws Once the canopy is attached to the bench, secure the security plate into place with security plate screws. Repeat these steps on other side.
  • Page 43 If the canopy rises spontaneously move gas shock to hole 2 security clip If the canopy lowers spontaneously move gas shock to hole 4 gas shock pivot Retrieve 2 Gas shocks 4 Gas shock pivots 4 security clips While the canopy is in an open position, insert gas shock into the bench and into third hole on the canopy.
  • Page 44 end cap filler end cap filler The four end cap fillers that were removed need to be inserted back into the bench and canopy.
  • Page 45 Installing the Deco Shield Retrieve 1 Deco shield 2 deco shield screws 2 deco shield washers 2 deco shield nuts Insert the deco shield in between the canopy and bench. screw washer nut Secure by attaching the decor shield to combi arm.
  • Page 46 A B C used for T-Max connection, see page 17 for directions 120 volt 20 Amp plug for L32 On the back of the canopy you will see three chords: Plug "A" into your wall outlet (or into optional buck booster) Plug "B"...

  • Page 47: T-Max Decoshield Connection

    T-Max Decoshield Connection Back of canopy Male Female Unscrew and remove top. Pin 3 live Pin 1 neutral...
  • Page 48 Power 9-12 V Pin 3 live J3 Contact Tighten screws Pin 1 once cables are neutral inserted Wireless adaption connection Daisy Chain You will need an 18/2 speaker cable. Insert one end of the 18/2 cable into the J3 Contact on the back of the T-Max. Insert the other end into Pins 1 and 3 on the male part.
  • Page 49 After all the appropriate cables connected, screw the top back on. Back of canopy Male Female...

  • Page 50: Warranty

    What is covered: During the Limited Warranty period as specified below, PROSUN will be repair or replace any defective system or components found to be defective, at PROSUN’s sole discretion. Prior to making any repairs, the owner must provide PROSUN with information requested and perform basic troubleshooting.
  • Page 51 • Any damage caused by the failure of any supporting hardware not supplied by PROSUN. • Acrylic sheets, starters (igniters), lamps, blue and clear filter glass. • Tanning units, parts or components damaged in transit where PROSUN’S damaged goods policy is not followed by purchaser or purchaser’s designee.
  • Page 52 ProSun representative. 2. A return shipping label will be provided. You will need to return the original or any unused parts to PROSUN unless otherwise advised in writing. If the original defective parts are not returned within 30 days, you will be responsible for the purchase charges for the parts.
  • Page 53 Limitation of Liability: PROSUN shall not be liable for any loss, damages, or penalty resulting from failure to perform any of its obligations under this Agreement due to major force or any cause beyond its reasonable control. PROSUN’S LIABILITY UNDER OR FOR BREACH OF THIS AGREEMENT SHALL NOT EXCEED THE REFUND OF THE PURCHASE PRICE LESS REASONABLE RENTAL FOR PAST USE.
  • Page 54 ProSun International 2442 23rd Street North St Petersburg, FL 33713 www.ProSun.com 727.825.0400 Contraindication: This Product Is Contraindicated For Use On Persons Under The Age Of 18 Years. “Contraindication: This Product Must Not Be Used If Skin Lesions Or Open Wounds Are Present.” “Warning: This Product Should Not Be Used On Individuals Who Have Had Skin Cancer Or Have A Family History Of Skin Cancer.”...
