ProSun V3 User Manual

High intensive 230v
Hide thumbs
Table of Contents

Advertisement

Quick Links

User Manual
Model 42V3
Prosun V3 42 High Intensive 230V
MARK76V3002 Rev 3

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the V3 and is the answer not in the manual?

Questions and answers

Related Manuals for ProSun V3

Summary of Contents for ProSun V3

  • Page 1 User Manual Model 42V3 Prosun V3 42 High Intensive 230V MARK76V3002 Rev 3...
  • Page 2 Contact Information ® C O N G R A T U L A T I O N S on your ProSun purchase! Please make sure you read this manual carefully before using this equipment and specifically the maintenance schedule. If you have any questions please contact ProSun directly.

  • Page 3: Table Of Contents

    Table of Contents Important Customer Information ................5 Who Should Use, Read, & Understand this Manual ........5 Indications For Use …………..…............5 Intended Use ....................5 Warning Signs & Symbols …..................5 Preparing the Product ..................8 Export …....................... 8 Transportation …..................
  • Page 4 How to Operate the Equipment ................. 36 Choosing the Correct Exposure Time …………………………………………… 36 Normal Equipment Operation & Software …………………………………………… 37 Operating Modes ………………………………………………………………..37 Standby Mode ………………………………………………………...... 37 Tanning Mode ………………………………………………………...... 37 Cool Down Mode ………………………………………………………………..37 Service Mode ………………………………………………………………………… 37 Starting the Tanning Session ……………………………………………………..

  • Page 5: Important Customer Information

    ON and OFF. Try to correct the interference using on or more of the following: • Reorient or relocate the receiving device. • Increase the separation between the equipment. • Connect the equipment to an outlet on a different circuit from that to which the other device(s) are connected and consult ProSun International LLC for help. MARK76V3002 Rev 3...
  • Page 6 High Voltage exists and is dangerous for human contact. UV Radiation hazard for Human Health Caution Symbol means to proceed with caution and follow instructions careful ESD-Sensitive devices, do not touch without using necessary proper precautions. Type B Applied Parts Symbols found on equipment and packaging: Follow and read instructions thoroughly prior to using equipment.
  • Page 7 Protective earth connections. Recyclable Material Polystyrene Cardboard Mixed Paper Wood Waste of electrical and electronic equipment must not be disposed as unsorted municipal waste. It must be collected separately, and must be disposed as per local regulations. Alternating Current. Single Phase MARK76V3002 Rev 3...

  • Page 8: Preparing The Product

    ProSun does not assume any liability if there is non-compliance outside of the intended sale territories of the United States or Canada. The exporter assumes their own risk by removing this equipment outside of the United States or Canada.

  • Page 9: Delivery

    Coordinate with ProSun installation department to set up delivery and installation details. In a commercial setting an external timer is required. ProSun recommends to use this accesory (T-Max Flushmount G2).
  • Page 10 The customer is responsible for all costs associated with the preparation of the installation of the equipment. This includes but is not limited to room preparation, costs, fees, permits, and inspections unless specified otherwise in the sales order for the equipment purchased. ProSun and all authorized parties shall reserve the right to refuse to install equipment into any room which has not been properly prepared in accordance with the electrical specification and room requirements.

  • Page 11: Commissioning Of The Tanning Equipment

    Commissioning of the tanning equipment The equipment is initially commissioned by a certified ProSun technician. The device will be properly assembled and handed over ready for us. In order to properly commission the tanning equipment, the business owner must ensure that the location is ready prior to the equipment being installed. This included having correct power requirements and having the room in which the unit will be located ready.

  • Page 12: General Safety Information

    General Safety Information General Safety Notes: Any adult with any of the below issues should not use this tanning equipment. If you are unsure consult your doctor prior to use. Contraindication: This sunlamp product is contraindicated for use on persons under the age of 18 years.
  • Page 13 Allow at least 48 hours to pass between each tanning session. Tan based on the exposure sticker on the unit or in this manual. Skin Type I should not tan. As an owner you must properly instruct all users on using the exposure table located on the front of the bed and only tanning for the minutes based on their skin type. If any negative effect occurs, stop using the equipment and consult a physician.
  • Page 14 This tanning bed is an over the counter tanning device that emits ultra violet light in the UVB and UVA region of the spectrum intended for the cosmetic tanning of the human skin in adults. Only one user should tan in the unit at a time. Wear protective eyewear during the duration of the sesion to protect the eyes against UV radiation.

  • Page 15: The Tanning Process

    The Tanning process: The tanning unit you have purchased is designed to concentrate optimal levels of UVA, in conjunction with very low percentages of UVB, on the outermost layers of the skin, so as to stimulate the production of Melanic pigment, which is slightly pink in its dormant state, these causes it to turn brown after excretion.

  • Page 16: Tanning Sensitivity

    Tanning Sensitivity Before using a tanning device always check with your doctor first. *The following may increase skin sensitivity: • Perfumes and colognes containing furocoumarins. • Compounds from natural products such as plants and fruits (their natural oils can sensitize the skin to sunlight.

  • Page 17: Equipment Components & Description

    Components PROSUN V3 FEAT. DEMO Easy Access Timer Turbo Cooling System The timer devices on ProSun beds Turbo cooling is designed to allow are designed to be reachable and as much airflow as possible while operated from within the beds still remaining energy efficient, themselves.

  • Page 18: Device Description

    Device Description 1. Ballasts - your unit may have different ballasts than shown in image 2. Canopy cover plate 3. Acrylic MARK76V3002 Rev 3...

  • Page 19: Options For Device

    Options for Device The below items are options for this device and may not be included in your unit. These options do not affect the normal functioning of your device. 1. Digital Display timer 2. Body cooling fan 3. Sturdy base 4. Easy swing door MARK76V3002 Rev 3...

  • Page 20: Lamp Configuration

    ProTech II High Intensive 75" inches 160W LAMP7670101 R-UVA 160w XL or 1.9M ProTech II High Intensive 75" inches 160W LAMP7670101 R-UVA 160w XL or 1.9M ProSun V3 42 Xlc - Spare parts Acrylic ACRY6012165 Goggles ACCE2501629 MARK76V3002 Rev 3...

  • Page 21: Dimensions

    Dimensions 60" 48" Top view door closed Recommended Room Size The below room size is a recommendation for optimal tanning output. MARK76V3002 Rev 3...

  • Page 22: Signs And Labels On Equipment

    Each label is listed in the following pages for clear description of what is written on each label. 1. ProSun Label The ProSun label is attached to the front left panel on the outside of the unit. This label is vertically placed on the unit, not as shown below.
  • Page 23 2. V3 Label The V3 label is on the door panel cover plate on the outside of the unit. 3. 18 and Older Label Age warning label stating no one under the age of 18 should use this product. This label is located on the front of the unit visible to the user.
  • Page 24 6. Danger Label 5. Warning Label This label is located on the front of the This label is located on the front of the unit unit on the door panel, visible to the on the door panel, visible to the user. user.
  • Page 25 8. Serial Label The serial label is located on the back of the unit and is the identifier for the unit. This includes the serial number and conformity marking. 9. Read information Carefully This label is located on the back of the unit to ensure people read the manually and information carefully. MARK76V3002 Rev 3...

  • Page 26: Technical Data

    Technical Data Electrical Specifications ProSun V3 42 Xlc Power consumption rating: 32 Amp Electrical Rating 230V ~ 32A 60Hz Rated Fuses: 40 amp 2-pole Continuous Operation: Continuous operation for a maximum of 10 minutes. Classification: Type B Applied Parts Ingress protection classification:...

  • Page 27: Electrical Requirements

    Please insure that your electrician and/or installer, reads this user’s manual carefully prior to the installation of your ProSun unit. You will need a buck booster if voltage requirements are not met. Service personnel should be authorized by ProSun to perform work on equipment and should have knowledge of equipment and read the full manual.

  • Page 28: Electrical Connections

    Electrical Connections Live Components Risk of fatal injury due to electrical shock when touching live parts. DANGER! Risk of electrical Shock To avoid the risk of electrical shock, this equipment must only be connected to a supply mains with protective earth. WARNING! Both the power supply and the related connection work must comply with national standards.

  • Page 29: Tanning Bed Standards

    (EMC): IEC 60601-1-2 (2014) Guidance and Manufacturer’s Declaration - Electromagnetic Emissions The ProSun V3 Model 42V3 is intended for use in the electromagnetic environment specified below. The customer or the user of the ProSun V3 Model 42V3 should assure that it is used in such an environment Emmission tests Compliance...
  • Page 30 Guidance and Manufacturer’s Declaration - Electromagnetic Immunity The ProSun V3 Model 42V3 is intended for use in the electromagnetic environment specified below. The customer or the user of the ProSun V3 Model 42V3 should assure that it is used in such an environment. Immunity Test IEC 60601 Test Level...
  • Page 31 Guidance and Manufacturer’s Declaration – Electromagnetic Immunity Non life supporting ME Equipment The ProSun V3 Model 42V3 is intended for use in the electromagnetic environment specified below. The customer or the user of the ProSun V3 Model 42V3 should assure that it is used in such an environment. Immunity Test...
  • Page 32 ProSun V3 Model 42V3 Non life supporting ME Equipment The ProSun V3 Model 42V3 is intended for use in an electromagnetic environment in which radiated RF disturbances are controlled. The customer or the user of the ProSun V3 Model 42V3 can...

  • Page 33: Before Your Tanning Session

    Before your tanning session Check for any conditions mentioned in the manual that may prevent you from using the tanning equipment. Make-up and cosmetics Do not wear make-up when tanning. Clean skin absorbs the UV Light properly. Remove all make-up prior to tanning. Make-up clogs the pores in your face. The UV light from a tanning device re-opens these clogged pores.

  • Page 34: After The Tanning Session

    After the tanning session Cleaning and Disinfection All parts of the equipmnent that come in contact with the user must be cleaned and disinfected after each session. Infections can be transferred through skin contact. The following items should be cleaned after each session: •...

  • Page 35: Operation Of Equipment

    Operation of Equipment Obligations of the business operator • As the business operator you are responsible for informing the user of the risks of tanning. • All danger and safety labels should be attached to the equipment and clearly visible to the user.

  • Page 36: How To Operate The Equipment

    How to operate the equipment Prior to operating the equipment check that the unit has been cleaned/disinfected and check for any damage to the acrylics. No other people should be in the vicinity of the equipment when in use, especially no children under the age of 18.

  • Page 37: Normal Equipment Operation & Software

    Equipment Operation & Software Before turning on the equipment make sure you have proper warning signs at your location. We recommend permanently placing a Warning sign on the wall close to the tanning bed such as the one below: WARNING •...

  • Page 38: Starting The Tanning Session

    Tanning Mode The following description is for a unit that has all possible features, some of these features may not be available for your unit or market. DANGER! Excessive dose of UV radiation Excessively prolonged tanning sessions may cause severe damage to skin and eyes.

  • Page 39: Stopping The Tanning Session

    Stopping the Tanning Session If the time in the session runs out naturally then the unit will go into a 3 minute cool-down. However if you need to stop the tanning session prior to end of the sesion you can do so by hitting the START/STOP Button.
  • Page 40 To Program your Onyx display Service Mode When the unit is in standby mode, you can enter into the service or maintenance parameters. NOTE: Start with a blank display. 1 To enter program mode: Push B and D simultaneously for 10 seconds. Display starts blinking 01 20 2 To put in remote: Push button C and bring time down to 00 push button A to enter.

  • Page 41: Customer Concerns

    Customer Concerns Failure to use protective eyewear may result in severe burns or other eye injury. If discomfort develops, stop using the tanning equipment immediately and seek medical advice from your physician. • Do not continue to use the tanning device if unexpected effects, such as itching, occur within 48 hours after the first tanning session. Seek medical advice immediately! • The tanning unit must never be used if a facial filter is damaged or missing, or if the timer on the unit is defective. •...

  • Page 42: Storing The Device

    Waste of electrical and electronic equipment must be disposed as unsorted municipal waste. It must be collected separately, and must be disposed as per local regulations. Contact ProSun International LLC or an authorized representative for information concerning the decommissioning of your equipment.

  • Page 43: Control Functions

    Control Functions Function Description Additional Information Start Use this button to start the tanning session. Stop Use this button to stop or pause the tanning session. Minus Decrease tanning time Decrease cooling fan speed Plus Increase tanning time Increase body cooling fan speed Face Tanner Use this button will turn off the lamps in your door panel.
  • Page 44 Operation Note: Typically Stand-alone mode is for residential use and Remote mode is for commercial use All units come standard in remote-mode Start Stand-alone mode: By depressing start once the “+ and –“ buttons can be used to set the tanning time. Pressing for a second time will start the unit.

  • Page 45: General Operation

    Stand-alone mode: a. Reduce tanning time b. Reduce body cooler speed Coin mode: a. Reduce body cooler speed Stand-alone mode: a. Increase tanning time b. Increase body cooler speed Coin mode: a. Increase body cooler speed Face Switch the face tanner on and off Switch the body cooler on and off General: The unit is generally set for use with external timer.

  • Page 46: Optional T-Max

    Optional T-Max If you are adding a T-Max timer to your V3 follow the steps below. *For commercial use only Remove the male end of part from tanning unit. Male Female Power Chord Pin 3 live Pin 1 neutral Unscrew and remove top.
  • Page 47 You will need an 18/2 speaker cable. Insert one end of the 18/2 cable into the J3 Contact on the back of the T-Max. Insert the other end into Pins 1 and 3 on the male part. Tighten screws to hold cables in place. **Make sure that the 18-2 cable is long enough to reach from bottom of the tanning bed to the location of the T-Max timing display.
  • Page 48 After all the appropriate cables connected, screw the top back on. Plug male part back into the bottom of the V3 unit, and tighten screws. MARK76V3002 Rev 3...

  • Page 49: Optional T-Max Integrated

    Optional T-Max Integrated If your V3 has an integrated T-Max timer follow the steps below. *For commercial use only On the back of the control panel near the top of the unit you will find 3 data ports. Connect the corresponding cables. Daisy Chain Connection for wireless adaption MARK76V3002 Rev 3...

  • Page 50: Error Messages

    Error messages Display messages: Overrule error (Switch print and/or display print defective) Filter glass defect (Filter glass of the face tanner is broken or glass protection is defective) or unit is overheated Communication error (No communication between switch print and display print) Note: When you receive one of the above error messages on your LCD display, you should stop using the unit and unplug it.

  • Page 51: Care & Maintenance

    Accidental reactivation can result in serious accidents. Immediately after deenergizing the equipment, secure all switches or fuses used for deenergizing against being switched on again. For more maintenance information please visit our website at: www.prosun.com/customer-service MARK76V3002 Rev 3...

  • Page 52: Basic Care Maintenance

    Compliance at the intervals specified for your unit are absolutely necessary to ensure the proper operation of the equipment. The table below is a preventative care table that can be done by any unskilled person, if any service outside of this table is needed please contact ProSun immediately and this would should only be done by a certified technician. The equipment should be routinely serviced and maintenanced by a ProSun certified technician.

  • Page 53: Cleaning & Disinfecting Acrylics

    NOTE: For thorough cleaning and disinfection, the product you are using has to remain in contact with the surface that is being cleaned and disinfected for a specific amount of time, as mentioned on the instructions of the product. The specifc amount of time will depened on the type of cleaner/disinfectant that you are using. Follow the directions on the product. After the specified application time remove remaining cleaner/disinfectant from the surface of the equipment.

  • Page 54: Cleaning Plastic Surfaces

    Maintenance by skilled persons: ProSun recommends having an annual inspection by a certified technician to review connections, check for lose wiring, check the power cords and review all other high voltage components. At this time the certified technician can dust all electronic components.

  • Page 55: Troubleshooting Guide

    Remote timers do not work. • Restart timer and try again. • Incorrect voltage • Check that it is plugged in and contact ProSun customer service for replacement parts. • Get voltage reading from certified technician. Unit appears to be too hot • Fans are obstructed Ensure all fans are clear of obstructions •...

  • Page 56: Replacement Components

    This unit has been manufactured in accordance with current safety regulations. The illustrations and specifications are subject to changes in order to improve the device. Unauthorized modifications and changes to the device and its controls are prohibited. ONLY USE ORIGINAL PARTS! Use of any other parts voids the warranty and ProSun will not be liable in any cases of damage or injury due to the use of these parts. MARK76V3002 Rev 3...

  • Page 57: Removing Acrylics

    Replacing the Acrylics Bend back the plastic grey strip Acrylic tool At the end of the bench or canopy you will find an acrylic tool. Remove it from the unit and use this to slide under the acrylic and lift it up gently. Pull back the acrylic sheet by hand first, then use the acrylic tool to remove the rest of the sheet.

  • Page 58: Replacing The Lamps

    Replacing the Lamps Once you have removed the acrlic you will want to unscrew and remove the metal lamp cov- covers/ strips. Then with gloves on to protect the lamps from oils, twist the lamp and remove. When replacing the lamp twist the lamp back into position. Listen for 2 clicks to ensure the lamp is securely fastened.

  • Page 59: Assembly Introduction

    Assembly Introduction Required for assembly (not included): • Preferably 2 wrenches to tighten bolts and nuts • Short ladder or step stool • Power adapter kit (230V for commercial use, for warranty to apply voltage must be between 215-230 V) *Make sure you write the Serial Number (located on the Control Panel) down on the previous page and store the manual somewhere you can easily access.

  • Page 60: Included Parts

    Included Parts Make sure all parts are included before you begin. 1 Alan Wrench 1 Rear floor frame FAM2205100 ACCE1009552 1 Security Plate 1 Front floor frame (extra) FAM2205090 FAMS6012236 2 Security Screws (extra) FASN1513151 8 Frame Nuts FASN3001134 16 Frame Washers FASN60001402 8 Frame Bolts FASN61003045 1 MDF Floor Board FAM2205120...

  • Page 61: Assembly

    Assembly Remove the Control and Door Panels. Remove security plates and screws using Alan wrench. *It is important to keep the panels in an upright position. Laying on ground may damage the exterior, as well as, interior components. Insert the Control Panel into the Door Panel (you will notice hooks on the top and bottom of the control panel).
  • Page 62 Once the door is connected, retrieve: Step stool *Make sure at least 1 person is holding the panels to ensure they stand upright. Use a step stool to easily see where the security plate attaches. Screw the security plate in the top where the Door Panel hooks into the Control Panel. Top view Door Panel Control Panel...
  • Page 63 Once the Door Panel is secure, you will need to tilt the two panels at an angle in order to screw the bottom security plate in place. The bottom security plate needs to be assembled in the same manner as step 2. Bottom View Security Plate Security Srews...
  • Page 64 Retrieve: Rear floor frame Front floor frame 4 Bolts 8 Washers 8 Nuts Attach the components to the Control Panel. Do NOT tighten the nuts yet. Control Panel ATTACH LOOSELY Rear floor frame Front floor frame Bolt Washer Washer MARK76V3002 Rev 3...
  • Page 65 Remove the Fan Panel from it's box. Remove security plates and screws at the top of the panel using an Alan wrench. Retrieve the step stool. Hook the Fan Panel to the Control Panel at the top of the unit. Screw the security plate back in place, as previously done in steps 2 and 3.
  • Page 66 Next retrieve: 4 Frame bolts 4 Frame nuts 8 Frame washers Insert all bolts into their positions BEFORE tightening. Control Panel Fan Panel ATTACH LOOSELY Bolt Washer Washer MARK76V3002 Rev 3...
  • Page 67 Retrieve: 2 wrenches Use the wrenches to tighten each nut and bolt. At this time ALL bolts and nuts can be tightened. MARK76V3002 Rev 3...
  • Page 68 Retrieve: 4 Floor Screws 4 Floor Washers MDF Floor Board Plastic Floor Cover A. Place the MDF floor board onto the frame and screw into place. B. Peel protective paper off, and stick the plastic floor cover into place (wide lip on the font).
  • Page 69 Connect all male and female connection cords. (2 on top and 1 on bottom). The power chord needs to be wired by a certified electrician (230V for commercial use). Power Chord 230 V AC Voltage White-Live Black-Live Green-Ground T-Max connection MARK76V3002 Rev 3...

  • Page 70: Warranty

    PROSUN’s sole discretion. Prior to making any repairs PROSUN will advise the Purchaser of the nature of the problem and the cost to the Purchaser based on the proration of the defective system or component.
  • Page 71 6. Exclusivity of Warranty: This warranty is the only warranty made by PROSUN and may only be modified or amended by a written instrument signed by a duly authorized officer of PROSUN. PROSUN’s sole and exclusive liability and Purchaser’s sole and exclusive remedy under this warranty shall be, at PROSUN’s option, to repair or replace, to the extent available on a prorated basis, any such defective Products.
  • Page 72 ProSun International, LLC 2442 23rd Street North St Petersburg, FL 33713 www.ProSun.com 800-874-2776 Contraindication: This Product Is Contraindicated For Use On Persons Under The Age Of 18 Years. “Contraindication: This Product Must Not Be Used If Skin Lesions Or Open Wounds Are Present.” “Warning: This Product Should Not Be Used On Individuals Who Have Had Skin Cancer Or Have A Family History.
