Page 1 Model 42V3-R 15 MINUTES RenuvaSkin S420 USER MANUAL E350-005 Rev 1 Approved on 12/02/24 by JCH...
Page 2 S420 C O N G R A T U L A T I O N S on your ProSun purchase! ® Please make sure you read this manual carefully before using this equipment and specifically the maintenance schedule. Keep this manual available for future reference.
Page 3: Table Of Contents
S420 Table of Contents Important Customer Information ....................... Who Should Use, Read, & Understand this Manual ............Warning Signs & Symbols …..........................Preparing the Product For Use ........................Export …................................Transportation …............................Delivery …................................ Ventilation …..............................Installation & Set-up …........................... Environmental Conditions for Transport &...
Page 4 S420 How to Operate the Equipment ……………………………................…… Session Times ………......……………………………………………………..........…... Equipment Operation and Software..…………………........…… Operating Modes ……………………………………………………………...........…... Standby Mode ………………………………………………………............. In Session Mode ………………………..……………………………….............. Cool Down Mode ………………………………………………………..........……….. Service Mode ……………………………………………………………..........……… Starting the Session…………………………..………………..........……… Operation during Session…………………….....……..........……… Stopping the Session…………..………….....……..........……… To Program your Unit Display...........................
Page 5: Important Customer Information
A copy of the user manual should be readily available.This manual may include features that are not included for your bed. Any service work outside of the preventative care table in this manual should be done by a ProSun authorized technician. Warning signs and symbols Danger and Safety Symbols: Danger Hazard exists for human health.
Page 6 S420 High Voltage exists and is dangerous for human contact. UV Radiation hazard for Human Health Caution Symbol means to proceed with caution and follow instructions carefully. ESD-Sensitive equipment, do not touch without using necessary proper precautions. Type B Applied Parts Symbols found on equipment and packaging: Follow and read instructions thoroughly prior to using equipment.
Page 7 S420 Atmospheric pressure limitation. This symbol is accompanied by the upper and lower limits of atmospheric pressure for storage and transportation. Humidity limitation indicates the acceptable upper and lower limits of relative humidity for transport and storage. Protective earth connections. Recyclable Material Polystyrene Cardboard...
Page 8: Preparing The Product For Use
ProSun does not assume any liability if there is non- compliance outside of the intended sale territories of the United States or Canada. The exporter assumes their own risk by removing this equipment outside of the United States or Canada.
Page 9: Delivery
Coordinate with ProSun installation department to set up delivery and installation details. In a commercial setting an external timer is required. ProSun recommends to use this accesory (T-Max Flushmount G2). Ventillation: The equipment must always have proper ventilation.
Page 10 Each should be inspected to ensure that no wires have been grounded or are left open. ProSun certified technicians are not responsible for the final installation of the electrical system, the electrical contractor or his designee should be present to make the final electrical connection upon completion of the installation of the equipment.
Page 11: Comissioning Of The Equipment
S420 Commissioning of the equipment The equipment is initially commissioned by a certified ProSun technician. The equipment will be properly assembled and handed over ready for us. In order to properly commission the equipment, the business owner must ensure that the location is ready prior to the equipment being installed.
Page 12: Equipment Components & Description
S420 Option for Equipment RenuvaSkin S420 Digital Display timer 2. Body cooling fan 3. Sturdy base 4. Easy swing door...
Page 13: Lamp Configuration
S420 Lamp configuration- The use of non approved Lamps voids the warranty! RenuvaSkin S420 Quantity Name Length Watts Part Number RenuvaSkin 110W 75" 110W LAMP8070030 RenuvaSkin 110W 75" 110W LAMP8070030 RenuvaSkin 110W 75" 110W LAMP8070030 RenuvaSkin S420- Spare parts Acrylic ACRY-SHIP6012165 Goggles ACCE2501629...
Page 14: Dimensions
S420 Dimensions Top view door closed 60" 48" Technical Data Electrical Specifications RenuvaSkin S420 Power consumption rating: 20 Amp Electrical Rating 230V ~ 20A 60Hz Rated Fuses: 25 amp 2-pole Continuous Operation: Continuous operation for a maximum of 15 minutes. Load on the base plate: Max 250lbs or 113 Kg Equipment Weight:...
Page 15 Please insure that your electrician and/or installer, reads this user’s manual carefully prior to the installation of your ProSun unit. You will need a buck booster if voltage requirements are not met. Service personnel should be authorized by ProSun to perform work on equipment and should have knowledge of equipment and read the full manual.
Page 16 S420 Electrical Connections Live Components Risk of fatal injury due to electrical shock when touching live parts. DANGER! Risk of electrical Shock To avoid the risk of electrical shock, this equipment must only be connected to a supply mains with protective earth. WARNING! Both the power supply and the related connection work must comply with national standards.
Page 17: Before Your Red Light Session
S420 Before your Red Light Session Check for any conditions mentioned in the manual that may prevent you from using the equipment. Make-up and cosmetics Do not wear make-up when using the equipment. Remove all make-up prior to the session. Make-up clogs the pores in your face.
Page 18: After The Session
S420 After the Red Light Session Cleaning and Disinfection All parts of the equipmnent that come in contact with the user must be cleaned and disinfected after each session. Infections can be transferred through skin contact. The following items should be cleaned after each session: •...
Page 19: Operation Of The Equipment
S420 Operation of the Equipment Obligations of the business operator • All danger and safety labels should be attached to the equipment and clearly visible to the user. You should not remove these labels at any time! • No safety devices( i.e. temperature sensors) may be removed, deactivated or otherwise bypassed from the equipment, as it can cause safety issues and impair the proper functioning of the equipment.
Page 20: Session Times
S420 Session Times • For optimum results use this product for a minimum period of 10-15 weeks. (Results may vary) • Sessions should be conducted every other day for no longer than the recommended 15 minute session time. • To maintain results, continue using this product 1 time a week for the recommended 15 minute session.
Page 21: Starting The Session
S420 Starting the Red Light session The session will automaticall begin after the external timer delay time has expired. During the preset delay time the session can be started by manually pressing the START button on the external timer, thereby overriding the delay time. If you are using the unit in stand-alone mode press START on the display, the maximum session time will show in the display.
Page 22: Stopping The Session
S420 Stopping the Red Light Session If the time in the session runs out naturally then the unit will go into a 3 minute cool-down. However if you need to stop the session prior to end of the sesion time you can do so by hitting the START/STOP Button.
Page 23: To Program Your Unit Display
S420 Service Mode When the unit is in standby mode, you can enter into the service or maintenance parameters. To Program your Unit Display Note: Start with a Blank Display 1. To enter program mode: Push B and D simultaneously for 10 seconds. Display starts blinking 01 15 2.
Page 24: Storing The Equipment
Waste of electrical and electronic equipment must be disposed as unsorted municipal waste. It must be collected separately, and must be disposed as per local regulations. Contact ProSun International or an authorized representative for information concerning the decommissioning of your equipment.
Page 25: Control Functions
S420 Control Functions Function Description Additional Information Start Use this button to start the session. Stop Use this button to stop or pause the session. Minus Decrease time Decrease cooling fan speed Plus Increase time Increase body cooling fan speed Face Lamp Not applicable for this bed Use this button to use the fan...
Page 26: Operations
S420 Operation Note: Typically Stand-alone mode is for residential use and Remote mode is for commercial use All units come standard in remote-mode Start Stand-alone mode: By depressing start once the “+ and –“ buttons can be used to set the time. Pressing for a second time will start the unit.
Page 27 S420 Stand-alone mode: Face: a. Reduce session time b. Reduce body cooler speed Switch the face tanner on and off. Not applicable for this unit. Coin mode: a. Reduce body cooler speed Fan: Switch the body cooler on and off Stand-alone mode: a.
Page 28: Optional T-Max Integrated
S420 Optional T-Max Integrated If your S420 has an integrated T-Max timer follow the steps below. *For commercial use only On the back of the control panel near the top of the unit you will find 3 data ports. Connect the corresponding cables.
Page 29: Optional T-Max
S420 Optional T-Max Your unit comes with a T-Max Timer to add in the room with your unit, this can be programmed with the T-Max system in your business. If you do not have a T-Max system then skip these steps. To connect the T-Max timer follow these steps: *For commercial use only Remove the male end of part from the unit.
Page 30 S420 You will need an 18/2 speaker cable. Insert one end of the 18/2 cable into the J3 Contact on the back of the T-Max. Insert the other end into Pins 1 and 3 on the male part. Tighten screws to hold cables in place. **Make sure that the 18-2 cable is long enough to reach from bottom of the bed to the location of the T-Max timing display.
Page 31 S420 After all the appropriate cables connected, screw the top back on. Plug male part back into the bottom of the S420 unit, and tighten screws.
Page 32: Error Messages
S420 Error messages Display messages: Overrule error (Switch print and/or display print defective) Overheating error. Unit is not cooling properly. Communication error (No communication between switch print and display print) NOTE: When you receive one of the above error messages on your LCD display, you should stop using the unit and unplug it.
Page 33: Care & Maintenance
Accidental reactivation can result in serious accidents. Immediately after deenergizing the equipment, secure all switches or fuses used for deenergizing against being switched on again. For more maintenance information please visit our website at: www.prosun.com/customer-service...
Page 34: Maintenance Schedule
The table below is a preventative care table that can be done by any unskilled person, if any service outside of this table is needed please contact ProSun immediately and this should only be done by a certified technician.
Page 35 S420 Lucasol 4-Step Cleaning Process wipe. bed is now sanitized. spray & wait 60 seconds. STEP 1 STEP 2 After use, spray the bed with Lucasol Wipe the bed surface to remove disinfeectant and sit for 60 seconds to Lucasol and any lotion residue.
Page 36: Cleaning Plastic Surfaces
Maintenance by skilled persons: ProSun recommends having an annual inspection by a certified technician to review connections, check for lose wiring, check the power cords and review all other high voltage components. At this...
Page 37: Troubleshooting Guide
Damage to equipment by user or Contact ProSun for replacement. cleaning Non-skilled person can replace acrylic. Any troubleshooting outside of the above mentioned guide should be done by a certified technician. Contact ProSun to schedule service with a certified technician.
Page 38: Replacement Of Components
Unauthorized modifications and changes to the equipment and its controls are prohibited. ONLY USE ORIGINAL PARTS! Use of any other parts voids the warranty and ProSun will not be liable in any cases of damage or injury due to the use of these parts.
Page 39: Replacing The Acrylics
S420 Replacing the Acrylics Bend back the plastic grey strip Acrylic tool At the end of the bench or canopy you will find an acrylic tool. Remove it from the unit and use this to slide under the acrylic and lift it up gently. Pull back the acrylic sheet by hand first, then use the acrylic tool to remove the rest of the sheet.
Page 40: Replacing The Lamps
S420 Replacing the Lamps Once you have removed the acrlic you will want to unscrew and remove the metal lamp covers/ strips. Then with gloves on to protect the lamps from oils, twist the lamp and remove. When replacing the lamp twist the lamp back into position. Listen for 2 clicks to ensure the lamp is securely fastened.
Page 41: Assembly Introduction
S420 Assembly Introduction Required for assembly (not included): • Preferably 2 wrenches to tighten bolts and nuts • Short ladder or step stool • Power adapter kit (230V for commercial use, for warranty to apply voltage must be between 215-230 V) *Make sure you write the Serial Number (located on the Control Panel) down on the previous page and store the manual somewhere you can easily access.
Page 42: Included Parts
S420 Included Parts Make sure all parts are included before you begin. 1 Allen Wrench ACCE1009552 1 Security Plate (extra) FAMS6012236 2 Security Screws (extra) FASN1513151 8 Frame Nuts 1 Front floor frame FASN3001134 FAM2205090 16 Frame Washers FASN60001402 8 Frame Bolts FASN61003045 4 Floor Screws (larger than security screws)
Page 43: Assembly
S420 Assembly Remove the Control and Door Panels. Remove security plates and screws using Allen wrench. *It is important to keep the panels in an upright position. Laying on ground may damage the exterior, as well as, interior components. Insert the Control Panel into the Door Panel (you will notice hooks on the top and bottom of the control panel).
Page 44 S420 Once the door is connected, retrieve: Step stool *Make sure at least 1 person is holding the panels to ensure they stand upright. Use a step stool to easily see where the security plate attaches. Screw the security plate in the top where the Door Panel hooks into the Control Panel.
Page 45 S420 Once the Door Panel is secure, you will need to tilt the two panels at an angle in order to screw the bottom security plate in place. The bottom security plate needs to be assembled in the same manner as step 2. Bottom view Security Plate Security Srews...
Page 46 S420 Retrieve: Rear floor frame Front floor frame 4 Bolts 8 Washers 8 Nuts Attach the components to the Control Panel. Do NOT tighten the nuts yet. Control Panel Rear floor frame Front floor frame Bolt Washer Washer ATTACH LOOSELY...
Page 47 S420 Remove the Fan Panel from it’s box. Remove security plates and screws at the top of the panel using an Alan wrench. Retrieve the step stool. Hook the Fan Panel to the Control Panel at the top of the unit. Screw the security plate back in place, as previously done in steps 2 and 3.
Page 48 S420 Next retrieve: 4 Frame bolts 4 Frame nuts 8 Frame washers Insert all bolts into their positions BEFORE tightening. Control Panel Fan Panel Bolt Washer Washer ATTACH LOOSELY...
Page 49 S420 Retrieve: 2 wrenches Use the wrenches to tighten each nut and bolt. At this time ALL bolts and nuts can be tightened.
Page 50 S420 Retrieve: 4 Floor Screws 4 Floor Washers MDF Floor Board Plastic Floor Cover A. Place the MDF floor board onto the frame and screw into place. B. Peel protective paper off, and stick the plastic floor cover into place (wide lip on the font).
Page 51 S420 Connect all male and female connection cords. (2 on top and 1 on bottom). The power chord needs to be wired by a certified electrician (230V for commercial use). *Unit color may vary Power Chord 230 V AC Voltage White-Live Black-Live Green-Ground...
Page 52: Warranty
What is covered: During the Limited Warranty period as specified below, PROSUN will be repair or replace any defective system or components found to be defective, at PROSUN’s sole discretion. Prior to making any repairs, the owner must provide PROSUN with information requested and perform basic troubleshooting.
Page 53 • Any damage caused by the failure of any supporting hardware not supplied by PROSUN. • Acrylic sheets, starters (igniters), lamps, blue and clear filter glass. • Tanning units, parts or components damaged in transit where PROSUN’S damaged goods policy is not followed by purchaser or purchaser’s designee.
Page 54 ProSun representative. 2. A return shipping label will be provided. You will need to return the original or any unused parts to PROSUN unless otherwise advised in writing. If the original defective parts are not returned within 30 days, you will be responsible for the purchase charges for the parts.
Page 55 S420 Limitation of Liability: PROSUN shall not be liable for any loss, damages, or penalty resulting from failure to perform any of its obligations under this Agreement due to major force or any cause beyond its reasonable control. PROSUN’S LIABILITY UNDER OR FOR BREACH OF THIS AGREEMENT SHALL NOT EXCEED THE REFUND OF THE PURCHASE PRICE LESS REASONABLE RENTAL FOR PAST USE.
Page 56 S420 ProSun International 2442 23rd Street North St Petersburg, FL 33713 www.ProSun.com 727.825.0400 Contraindication: This Product Is Contraindicated For Use On Persons Under The Age Of 18 Years. “Contraindication: This Product Must Not Be Used If Skin Lesions Or Open Wounds Are Present.” “Warning: This Product Should Not Be Used On Individuals Who Have Had Skin Cancer Or Have A Family History Of Skin Cancer.”...
