ATX Motherboard for 22nm LGA 1155 Intel® Xeon® E3/
Intel® Core™ i3 CPU with Intel® C216, DDR3, VGA, Dual
Intel® PCIe GbE, USB 3.0, SATA 6Gb/s, HD Audio and RoHS
Quick Installation Guide
Package List
IMBA-C2160 package includes the following items:
1 x IMBA-C2160 Single Board Computer
4 x SATA Cable (P/N: 32801-000703-200-RS)
1 x I/O Shielding (P/N: 45014-0034C0-00-RS)
1 x Mini Jumper Pack
1 x Utility CD (within manual)
1 x QIG (Quick Installation Guide)
1 x One Key Recovery CD
IMBA-C2160
Version 1.0
Aug. 17, 2012
©2011 Copyright by IEI Technology corp.
All rights reserved.
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the IMBA-C2160 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for IEI Technology IMBA-C2160

Summary of Contents for IEI Technology IMBA-C2160

  • Page 1 Intel® PCIe GbE, USB 3.0, SATA 6Gb/s, HD Audio and RoHS IMBA-C2160 Quick Installation Guide Version 1.0 Aug. 17, 2012 Package List IMBA-C2160 package includes the following items:  1 x IMBA-C2160 Single Board Computer  4 x SATA Cable (P/N: 32801-000703-200-RS) ...
  • Page 2 Specifications  CPU: LGA1155 socket supports Intel® Xeon® E3 and Intel® Core™ i3 quad/dual core processors  System Chipset: Intel® C216  Memory: Four 240-pin 1600/1333MHz dual-channel DDR3 SDRAM ECC and non-ECC unbuffered DIMMs supported (system max. 32GB)  BIOS: UEFI BIOS ...
  • Page 3  Expansion: 1 x PCIe x16 slot 1 x PCIe x16 slot (with x8 signal) 2 x PCIe x4 slot 1 x PCIe x1 slot 2 x PCI slot  Watchdog Timer: Software programmable supports 1~255 sec. system reset  Digital I/O: 24-bit Digital I/O (24-bit GPIO is for programming I/O) ...
  • Page 4 Ordering Information  IMBA-C2160-R10： ATX motherboard supports 22nm LGA1155 Intel® Xeon® E3/ Intel® Core™ i3 CPU with Intel® C216, DDR3, VGA, Dual Intel® PCIe GbE, USB 3.0, SATA 6Gb/s, HD Audio and RoHS  19800-003100-200-RS：Dual ports USB cable with bracket ...
  • Page 5 Jumpers setting and Connectors LABEL FUNCTION J_CMOS1 CMOS State Setting JATX_AT1 AT mode or ATX mode Selection WOL_SEL1 Wake On Lan Selection J_FLASH Flash Descriptor Security Override/ ME Debug Mode CNUSB_PWR1 Select +5v or +5v_dual USB_PWR1-3 Select +5v or +5v_dual K/M_USB1_PWR1 Select +5v or +5v_dual SATA1~2 &...
  • Page 6 J_COMS1 : Clear CMOS Setup PIN NO. DESCRIPTION Short 1-2 Keep CMOS Setup (default) Short 2-3 Clear CMOS Setup JATX_AT1: ATX mode or AT mode Selection PIN NO. DESCRIPTION OPEN AT Mode SHORT ATX Mode WOL_SEL1: WOL Mode select PIN NO. DESCRIPTION Short 1-2 WOL Mode Enable (default)
  • Page 7 SATA1~2: SATA 3Gb/s connector PIN NO. DESCRIPTION PIN NO. DESCRIPTION SATA3~6 : Serial ATA 3Gb/s Connector PIN NO. DESCRIPTION PIN NO. DESCRIPTION RXN_A TXP_A RXP_A TXN_A TXP_B TXN_B RXN_B RXP_B F_PANEL1 : PWR & RST Buttons and Indicators panel PIN DESCRIPTION PIN DESCRIPTION ACPILED BEEP_PWR PWR_LED...
  • Page 8 TPM1 : TPM Connector PIN NO. DESCRIPTION PIN NO. DESCRIPTION Clock Frame# NC(KEY) Reset# LAD3 LAD2 +3.3V LAD1 LAD0 SMB CLK SMB DATA +3.3V Standby Serial IRQ Clock Run# Power Down# DREQ# COM2,3,5,6 : Internal Serial Port Connector PIN NO. DESCRIPTION PIN NO.
  • Page 9 DIO1 : Digital Input / Output Connector PIN NO. DESCRIPTION PIN NO. DESCRIPTION Output 3 Output 2 Output 1 Output 0 Input 3 Input 2 Input 1 Input 0 SYS_FAN1 、 SYS_FAN2 : System Fan Connector PIN NO. DESCRIPTION FANIO +12V (PWM) FP_AUDIO1 : Audio Source Connector PIN NO.
  • Page 10 CPU12V1 : +12V MAIN POWER Connector PIN NO. DESCRIPTION +12V CPU_FAN1 : CPU Fan Connector PIN NO. DESCRIPTION +12V FANIO1 I2C_1 PIN NO. DESCRIPTION +5V_DUAL PCH_GP38_PU PCH_GP39_PU SMBus_1 : PIN NO. DESCRIPTION +5V_DUAL SMBCLK SMBDATA USB1~3: Internal USB Connectors PIN NO. DESCRIPTION PIN NO.
  • Page 11 K/B_USB1 : PS/2 MOUSE & KEYBOARD Connector & USB2.0 Connector PIN NO. DESCRIPTION PIN NO. DESCRIPTION USB20_D1+ USB20_D1- USB20_D2+ USB20_D2- KBDATA MSDATA VCC5 MBCLK MSCLK AUDIO_CV1: Audio input and output connector PIN NO. DESCRIPTION Line-in CD/DVD or other audio source input port Line_ot Connect this port to headphone or speaker Microphone...
  • Page 12 COM1: External Serial Port Connector PIN NO. DESCRIPTION DATA CARRIER DETECT (DCD1) RECEIVE DATA (RXD1) TRANSMIT DATA (TXD1) DATA TERMINAL READY (DTR1) (GND1) DATA SET READY (DSR1) REQUEST TO SEND (RTS1) CLEAR TO SEND (CTS1) RING INDICATOR (RI1) LAN1_USB01, LAN2_USB23: RJ-45 LAN and USB3.0 Connectors PIN NO.
  • Page 13 Board Layout: Jumper and Connector Locations （Unit:mm）...
