ATX motherboard supports 22nm LGA1150 Intel® Xeon E3/Core™ i3/
Pentium® and Celeron® per Intel® C226, DDR3, VGA, Dual Intel® PCIe
GbE, Four USB 3.0, Six SATA 6Gb/s, HD Audio, iRIS-2400 and RoHS
Quick Installation Guide
Package List
IMBA-C2260-i2 package includes the following items:
1 x IMBA-C2260-i2 single board computer
1 x I/O shielding (P/N: 45014-0034C0-00-RS)
2 x SATA cable (P/N: 32000-062800-RS)
1 x Utility CD
1 x QIG (Quick Installation Guide)
IMBA-C2260-i2
Version 1.0
Dec18, 2013.
©2006 Copyright by IEI Integration corp.
All rights reserved.
1
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for IEI Technology IMBA-C2260-i2
Summary of Contents for IEI Technology IMBA-C2260-i2
-
Page 1: Quick Installation Guide
IMBA-C2260-i2 Quick Installation Guide Version 1.0 Dec18, 2013. Package List IMBA-C2260-i2 package includes the following items: 1 x IMBA-C2260-i2 single board computer 1 x I/O shielding (P/N: 45014-0034C0-00-RS) 2 x SATA cable (P/N: 32000-062800-RS) 1 x Utility CD 1 x QIG (Quick Installation Guide) ©2006 Copyright by IEI Integration corp. -
Page 2: Specifications
Specifications CPU: LGA1150 Intel® Xeon® E3/Core™ i3/Pentium® or Celeron® processor supported System Chipset: Intel® C226 Memory: Four 240-pin 1600/1333MHz dual-channel DDR3 SDRAM ECC and non-ECC unbuffered DIMMs supported (system max. 32GB) BIOS: UEFI BIOS Graphic Engine: Intel® HD Graphics Gen 7.5 support for DX11.1 and OpenCL 1.2, OpenGL 3.2 Full MPEG2, VC1, AVC Decode Display Output: VGA (Up to 1920x1200 @ 60 Hz) - Page 3 1 x mSATA (colay SATA port) 1 x 6-pin wafer for PS/2 KB/MS Watchdog Timer: Software programmable support 1~255 sec. system reset FAN: 1 x 4-pin CPU fan connector 2 x 3-pin system fan connectors Front Audio: 1 x 10-pin (2x5) header Front Panel: 1 x Front Panel (Power LED, HDD LED, Speaker, Power Button, Reset Button)
-
Page 4: Ordering Information
Ordering Information IMBA-C2260-i2-R10: ATX motherboard supports 22nm LGA1150 Intel® Xeon E3/ Core™ i3/Pentium® and Celeron® per Intel® C226, DDR3, VGA, Dual Intel® PCIe GbE, four USB 3.0, six SATA 6Gb/s, HD Audio, iRIS-2400 and RoHS 19800-003100-200-RS: Dual ports USB cable with bracket 19800-010500-100-RS: USB 3.0 cable with bracket... -
Page 5: Jumpers Setting And Connectors
Jumpers setting and connectors LABEL FUNCTION J_ATX_AT1 AT/ATX mode select switch J_CMOS1 Clear CMOS button PCIE x16 Power PCIEX16 channel mode setting USB SW1, USB SW2 USB power setting J_FLASH1 Flash descriptor security override BAT1 Battery connector CHASSIS1 Chassis status connector CPU_FAN1 CPU fan connector CPU12V1... - Page 6 Internal USB 3.0 connector AUDIO_CV1 HD audio connector LAN1_USB1 RJ45 LAN and USB 3.0 connectors LAN2_USB2 RJ45 LAN and USB 3.0 connectors K/M_USB1 Keyboard & Mouse and USB 2.0 connectors CNUSB1 USB 2.0 connectors VGACOM1 VGA and RS-232 serial port connectors J_ATX_AT1: AT/ATX mode select switch PIN NO.
- Page 7 USB SW1, USB SW2: USB power setting PCIE x16 DESCRIPTION +5V DUAL (default) +5V DUAL Aptio Setup Utility – Copyright (C) 2012 American Megatrends, Inc. Chipset Auto Power Button Status [Disabled(ATX)] Restore AC Power Loss [Last State] ------------------ > PCI Express Configuration >...
- Page 8 CPU12V1: +12V power source connector PIN NO. DESCRIPTION PIN NO. DESCRIPTION +12V +12V ATX1: 24-pin ATX power source connector PIN NO. DESCRIPTION PIN NO. DESCRIPTION +3.3V +3.3V +3.3V -12V PS_ON Power good 5VSB +12V +12V +3.3V DIO1: Digital I/O connector PIN NO.
- Page 9 DP1: Display port connector PIN NO. DESCRIPTION PIN NO. DESCRIPTION LANE1N LANE1P LANE3N LANE3P AUX_CTRL_DET_D AUXP AUXN LANE2P LANE2N LANE0P LANE0N +3.3V FRONT_PANEL1: Front audio connector PIN NO. DESCRIPTION PIN NO. DESCRIPTION MIC2-L MIC2-R Presence# LINE2-R MIC2-JD FRONT-IO LINE2-JD LINE2-L F_PANEL1: Front panel connector DESCRIPTION DESCRIPTION...
- Page 10 CN5: I2C connector PIN NO. DESCRIPTION PIN NO. DESCRIPTION PCH_GP38 PCH_GP39 KB_MS1: Keyboard and mouse connector PIN NO. DESCRIPTION PIN NO. DESCRIPTION MSDATA MSCLK KBDATA KBCLK LED_LAN1: LAN1 link LED connector PIN NO. DESCRIPTION PIN NO. DESCRIPTION +3.3V LAN1_LED_LNK#_ACT LED_LAN2: LAN2 link LED connector PIN NO.
- Page 11 CN2: M-SATA card connector PIN NO. DESCRIPTION PIN NO. DESCRIPTION PCIE_WAKE# +3.3V 1.5V MSATA_CLK# MSATA _CLK PLTRST_N +3.3V PLTRST_N SATA_RX+ +3.3V SATA_RX- 1.5V SMB_CLK SATA_TX- SMB_DATA SATA_TX+ USB_DATA- USB_DATA+ +3.3V +3.3V +3.3V CLINK_CLK CLINK_DATA 1.5V CLINK_RST# MSATA_DET +3.3V...
- Page 12 COM2, COM3, COM5, COM6: Internal RS-232 serial port connectors Function DESCRIPTION DESCRIPTION COM2 COM3 COM5 COM6 COM4: RS-422/485 serial port connector PIN NO. DESCRIPTION PIN NO. DESCRIPTION RXD485# RXD485+ TXD485+ TXD485#...
- Page 13 SATA1, SATA2, SATA3, SATA4, SATA5, SATA6: Serial ATA 3.0 connectors PIN NO. DESCRIPTION PIN NO. DESCRIPTION SATA_TX+ SATA_TX- SATA_RX- SATA RX+ CN1: SMBUS connector PIN NO. DESCRIPTION PIN NO. DESCRIPTION SMB_DATA SMB_CLK SPDIF1: SPDIF connector PIN NO. DESCRIPTION PIN NO. DESCRIPTION SPDIFOUT SPDIFIN...
- Page 14 USB1, USB2: Internal USB 2.0 connectors PIN NO. DESCRIPTION PIN NO. DESCRIPTION USB_DATA- USB_DATA+ USB_DATA+ USB_DATA- CN4: Internal USB 3.0 connector PIN NO. DESCRIPTION PIN NO. DESCRIPTION USB3_RX- USB3_RX+ USB3_TX- USB3_TX+ USB_DATA- USB_DATA+ USB_DATA+ USB_DATA- USB3_TX+ USB3_TX- USB3_RX+ USB3_RX-...
- Page 15 LAN1_USB1, LAN2_USB2: Ethernet and USB 3.0 connectors USB1: External USB 3.0 connectors PIN NO. DESCRIPTION PIN NO. DESCRIPTION USB_DATA- USB_DATA- USB_DATA+ USB_ DATA+ USB3_RX- USB3_RX- USB3_RX+ USB3_ RX+ USB3_TX- USB3_TX- USB3_TX+ USB3_TX+ LAN1: RJ45 LAN connector PIN NO. DESCRIPTION PIN NO. DESCRIPTION LAN1_MDI0P LAN1_MDI2P...
- Page 16 CNUSB1: USB 2.0 connectors PIN NO. DESCRIPTION PIN NO. DESCRIPTION USB_DATA- USB_DATA- USB_DATA+ USB_DATA+ VGACOM1: VGA and RS-232 serial port connectors VGA: VGA connector PIN NO. DESCRIPTION PIN NO. DESCRIPTION GREEN BLUE DDCDA HSYNC VSYNC DDCCLK COM1: External RS-232 serial port connector DCD1 RXD1 TXD1...
- Page 17 Board Layout: Jumper and Connector Locations (Unit: mm)
