- Page 1 2CDC 550 002 D0201 │ 06.2014 Technical Manual Binary Input Binary Input BI-F-2.0.1 (6241/2.0U) BI-F-4.0.1 (6241/4.0U) BI-M-4.0.1 (6241/4.0)
- Page 2 Overview of types _____________________________________________________________________ 8 Function overview _____________________________________________________________________ 9 Description of functions ________________________________________________________________ 10 Device overview of 2gang binary input BI-F-2.0.1 ____________________________________________ 15 Device overview of 4gang binary input BI-F-4.0.1 ____________________________________________ 15 Device overview of 4gang binary input BI-M-4.0.1 ___________________________________________ 16 Technical data ____________________________________________________________________ 17 Overview of BI-F-2.0.1 and BI-F-4.0.1 _____________________________________________________ 17...
- Page 3 Please keep this manual in a safe place. If you pass the device on, also include this manual. If you require additional information or have questions about the device, please contact ABB STOTZ-KONTAKT GmbH or visit our Internet site at: www.abb.com/freeathome │3...
- Page 4 However, residual hazards remain. Read and adhere to the safety instructions to pre- vent such hazards. ABB STOTZ-KONTAKT GmbH accepts no liability for failure to observe the safety in- structions. Used symbols The following symbols point to particular dangers involved in the use of the device and provide practical instructions.
- Page 5 The binary inputs serve as interface for operating free@home systems via conven- tional push-buttons or for coupling message contacts. Version BI-F-2.0.1 and BI-F-4.0.1 are intended for flush-mounting. Version BI-M-4.0.1 is a rail mounting device for installing in the distributor. The integrated bus coupler makes possible the connection to the free@home bus.
- Page 6 ® ABB-free@home Environment Environment Always dispose of the packaging material and electric devices and their compo- nents via the authorized collecting depots and disposal companies. The products meet the legal requirements, in particular the laws governing elec- tronic and electrical devices and the REACH ordinance.
- Page 7 The support of floating contacts or 230 V~ Note Basic information about system integration is contained in the system man- ual. It is available for downloading at www.abb.com/freeathome. Scope of supply The scope of supply contains the binary input including bus terminal for coupling to the free@home bus.
- Page 8 ABB-free@home Product description Overview of types Sensor Type Product name Device channels Binary input, flush-mounted, BI-F-2.0.1 floating binary contacts Binary input, flush-mounted, BI-F-4.0.1 floating contacts BI-M-4.0.1 Binary input MDRC, 230 V~ Table 1: Overview of types │8 Technical Manual 2CDC 550 002 D0201...
- Page 9 ® ABB-free@home Product description Function overview The following table provides an overview of the possible functions and applica- tions of the device: Icon of the operating surface Information Name: Sensor (rocker) Control element for the control of free@home functions Name: Movement detector...
- Page 10 ® ABB-free@home Product description Description of functions 4.4.1 Rocker The function rocker is to be used if push-buttons are connected to the binary in- put. Depending on whether single or double push-buttons are used, this must be set in "Device configuration" in the main menu of the System Access Point. There the respective binary input is to be selected, and then in field "Channel selection"...
- Page 11 A (coupling channels A+B for BI-F-2.0.1) or channels A and C (coupling A+B and C+D for BI-F-4.0.1) causes the light to become brighter. A brief press is used to switch the lamp on.
- Page 12 ® ABB-free@home Product description Staircase lighting If a push-button connected to a binary input is to be used for switching staircase lighting, the function "Staircase lighting sensor" is to be selected (compare sec- tion 7.2). In the configuration of the associated switch actuator to which the lamps of the staircase are connected), can be configured in "Switch-off delay".
- Page 13 ® ABB-free@home Product description Fig. 2: Configuration of force-position ON/OFF │13 Technical Manual 2CDC 550 002 D0201...
- Page 14 ® ABB-free@home Product description 4.4.2 Movement detector sensor This function is to be selected if a movement detector is connected to the binary input for light control. If the binary input is connected with a switch actuator, the duration of the light of the lamps connected to the switch actuator can be set via parameter "Switch-off delay"...
- Page 15 ® ABB-free@home Product description Device overview of 2gang binary input BI-F-2.0.1 Fig. 3: Device overview of 2gang, flush-mounted binary input BI-F-2.0.1 Device identification during commissioning Identification LED Bus connection terminal Inputs, 4 wires Device overview of 4gang binary input BI-F-4.0.1 Fig.
- Page 16 ® ABB-free@home Product description Device overview of 4gang binary input BI-M-4.0.1 Fig. 5: Device overview of 4gang, MDRC binary input Device identification during commissioning Identification LED Bus connection terminal Connecting terminal │16 Technical Manual 2CDC 550 002 D0201...
- Page 17 ® ABB-free@home Technical data Technical data Overview of BI-F-2.0.1 and BI-F-4.0.1 Parameters Value Power supply 24 V DC (via the bus) Bus subscribers 1 (12 mA) Connection (free@home) Bus connection terminal: 0.4 - 0.8 mm Line type J-Y(St)Y, 2 x 2 x 0.8 mm Number of BI-F2.0.1...
- Page 18 ® ABB-free@home Technical data Overview of BI-M-4.0.1 Parameters Value Power supply 21 to 23 V DC (via the bus) Bus subscribers 1 (5 mA) Connection Bus connection terminal: 0.4 - 0.8 mm Line type J-Y(St)Y, 2 x 2 x 0.8 mm...
- Page 19 ® ABB-free@home Technical data Dimensions Note All dimensions are in mm. Binary Input BI-F-2.0.1 Fig. 6: Dimensions of BI-F-2.0.1 Binary Input BI-F-4.0.1 Fig. 7: Dimensions of BI-F-4.0.1 BI-M-4.0.1 Fig. 8: Dimensions of BI-M-4.0.1 │19 Technical Manual 2CDC 550 002 D0201...
- Page 20 ® ABB-free@home Technical data Connection diagram Binary Input BI-F-2.0.1 Black Grey Brown Fig. 9: Electrical connection of BI-F-2.0.1 Binary Input BI-F-4.0.1 Black Grey Brown Orange Yellow Fig. 10: Electrical connection of BI-F-4.0.1 │20 Technical Manual 2CDC 550 002 D0201...
- Page 21 ® ABB-free@home Technical data Binary Input BI-M-4.0.1 Fig. 11: Electrical connection of BI-M-4.0.1 │21 Technical Manual 2CDC 550 002 D0201...
- Page 22 ® ABB-free@home Mounting Mounting Safety instructions for mounting Danger Risk of death due to electrical voltage Dangerous currents flow through the body when coming into direct or indi- rect contact with live components. This results in electric shock, burns or even death.
- Page 23 ® ABB-free@home Mounting Danger Risk of death due to short-circuit Risk of death due to electrical voltage of 230 V during short-circuit in the low-voltage line. » During mounting observe the spatial division (> 10 mm) of SELV electric circuits to other electric circuits.
- Page 24 ® ABB-free@home Mounting Installation/mounting BI-F-2.0.1 and BI-F-4.0.1 Installation is carried out flush-mounted in a Ø 60 mm installation box, behind the push-button, for example. BI-M-4.0.1 The device is a rail mounting device for installing in distributors for easy installa- tion on 35 mm mounting rails according to DIN EN 60 715.
- Page 25 ® ABB-free@home Mounting Electrical connection BI-F-2.0.1 and BI-F-4.0.1 » The bus line connection is established by means of the enclosed bus con- nection terminal. » The inputs/outputs are connected according to the circuit diagram via six plug-in connecting cables that are approx. 30 cm long.
- Page 26 ® ABB-free@home Commissioning Commissioning Commissioning is always carried out via the Web-based surface of the System Access Point. The System Access Point establishes the connection between the free@home participants and the smartphone, tablet or PC. It is used to identify and program the participants during commissioning.
- Page 27 ® ABB-free@home Commissioning Allocation of devices and specifying channels The devices connected to the system must be identified, i.e. they are allocated to a room according to their function and are given a descriptive name. The allocation is made via the allocation function of the Web- based user interface of the System Access Point.
- Page 28 ® ABB-free@home Commissioning Fig. 13: Allocation A pop-up window opens automatically which lists all the devices suitable for the application selected. The desired device can now be identified. │28 Technical Manual 2CDC 550 002 D0201...
- Page 29 ® ABB-free@home Commissioning Identification via serial number Fig. 14 Identification via serial number » Compare the short 3-digit number of the identification label with the numbers in the list and in this way identify the device you are searching for and, if necessary, also the channel.
- Page 30 ® ABB-free@home Commissioning Assigning a name Fig. 15: Assigning a name » Enter a name that is easy to understand and under which the application is to be displayed later (e.g. "Living room light switch"). » Press the tick at the bottom right to take over the entry.
- Page 31 ® ABB-free@home Commissioning Setting options per channel General settings and parameter settings can be made for each channel. The settings are made via the allocation function of the Web- based user interface of the System Access Point. Device selection Fig. 16: Device selection »...
- Page 32 ® ABB-free@home Commissioning 7.2.1 Binary input settings Changing the name Deleting the channel via "X" Switching of the linked actuator via the button Selection of function (see sec- tion 4.3) Selecting the contact type of the switch (NC contact is closed in the rest position, a NO contact is open) Fig.
- Page 33 ® ABB-free@home Commissioning Linking The binary inputs created via the allocation function can now be linked with a second device (e.g. switch actuator). This allows simple ON/OFF circuits or two- way circuits to be implemented. The linking in the list view is then made via the linking function of the Web-based user interface of the System Access Point.
- Page 34 ® ABB-free@home Commissioning Light scenes and light groups A light scene means calling up a preset light situation (e.g. preset dimming value) via a single push-button. For a light group, a group of lamps is switched simulta- neously by means of a single push-button. This function, for example, replaces two-way circuits or intermediate switches of conventional electrical installations.
- Page 35 ® ABB-free@home Updating options Updating options A firmware update is carried out via the Web-based user interface of the System Access Point. For this, visit the free@home website www.abb.com/freeathome. │35 Technical Manual 2CDC 550 002 D0201...
- Page 36 ® ABB-free@home Maintenance Maintenance The devices are maintenance-free. In case of damage (e.g., during transport or storage), do not perform repairs. Once the device is opened, the warranty is void! Access to the device must be guaranteed for operation, testing, inspection, maintenance and repairs (according to DIN VDE 0100-520).
- Page 37 69123 Heidelberg, Germany content of this document without prior notice. Telephone: +49 2351 956-1600 The respective agreed-upon conditions apply to orders. ABB accepts no responsibility for E-mail: knx.helpline@de.abb.com possible errors or incompleteness in this www.abb.com/freeathome document.
