- Page 1 | 866-412-6278 | info@coastipc.com Neousys Technology Inc. POC-751VTC Series User Manual Revision 1.0 Rev080624...
-
Page 2: Table Of Contents
Reserved Panel View ..................14 1.2.3 COM Port Panel View ..................14 1.2.4 Bottom View ...................... 15 System Overview Unpacking the System ..................... 16 POC-751VTC Series Front Panel ................17 2.2.1 System Status LED ................... 18 2.2.2 HDMI ......................... 19 2.2.3 DisplayPort......................20 2.2.4... - Page 3 Table of Content 3.4.2 Vertical Wall Mount Bracket (optional) .............. 64 Powering On the System ..................65 3.5.1 Powering On Using the Power Button ............... 65 3.5.2 Powering On Using An External Non-Latched Switch ........66 3.5.3 Powering On Using Wake-on-LAN ..............67 BIOS Settings COM1 Port Configuration ..................
-
Page 4: Legal Information
For questions in regards to hardware/ software compatibility, customers should contact Neousys Technology Inc. sales representative or technical support. To the extent permitted by applicable laws, Neousys Technology Inc. shall NOT be responsible for any interoperability or compatibility issues that may arise when (1) products, software, or options not certified and supported;... -
Page 5: Contact Information
3384 Commercial Avenue, Northbrook, IL 60062, USA (Illinois, USA) Tel: +1-847-656-3298 Email, Website China Neousys Technology China Co., Ltd. Room 612, Building 32, Guiping Road 680, Shanghai Tel: +86-2161155366 Email, Website Declaration of Conformity This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. -
Page 6: Copyright Notice
This manual is intended to be used as an informative guide only and is subject to change without prior notice. It does not represent commitment from Neousys Technology Inc. Neousys Technology Inc. shall not be liable for any direct, indirect, special, incidental, or consequential damages arising from the use of the product or documentation, nor for any infringement on third party rights. -
Page 7: Safety Precautions
Safety Precautions Safety Precautions ⚫ Read these instructions carefully before you install, operate, or transport the system. ⚫ Install the system or DIN rail associated with, at a sturdy location ⚫ Install the power socket outlet near the system where it is easily accessible ⚫... -
Page 8: Service And Maintenance
Service and Maintenance/ ESD Precautions Service and Maintenance ⚫ ONLY qualified personnel should service the system ⚫ Shutdown the system, disconnect the power cord and all other connections before servicing the system ⚫ When replacing/ installing additional components (expansion card, memory module, etc.), insert them as gently as possible while assuring proper connector engagement ESD Precautions... -
Page 9: About This Manual
POC-751VTC About This Manual This manual introduces and demonstrates installation procedures of Neousys POC-751VTC series systems featuring an Intel® Core™ i3-N305 processor. The manual also demonstrates the system’s general installation procedures. Revision History Version Date Description Jul. 2024 Initial release... -
Page 10: Introduction
POC-751VTC Introduction POC-751VTC is Neousys' next-generation ultra-compact in-vehicle computer with E-Mark certification for in-vehicle applications such as a mobile gateway, mobile surveillance, and passenger information system. POC-751VTC utilizes the latest Intel® Alder Lake i3-N305 with eight CPU cores and supports up to 16GB of DDR5-4800 memory, capable of delivering up to 1.3x the CPU performance when compared to... -
Page 11: Specification Of Poc-751Vtc
POC-751VTC Specification of POC-751VTC System Core Intel® Alder Lake Core i3-N305 processor (8C/8T, 1.8/3.8 GHz, 15W Processor TDP) Graphics Integrated Intel® HD Graphics with 32EUs Memory Up to 16 GB DDR5-4800 SDRAM (one SODIMM socket) Supports TPM 2.0 (fTPM/ dTPM) Panel I/O Interface Ethernet 4x Gb Ethernet ports by Intel®... - Page 12 POC-751VTC Vertical-type wall-mount (optional) Fan kit Optional external-accessible fan kit 80mm x 80mm Environmental Operating -40°C to 70°C* temperature Storage -40°C to 85°C temperature Humidity 10% to 90% , non-condensing Vibration EN 50155:2017/ IEC 61373, Category I, Class B - Body mounted Shock EN 50155:2017/ IEC 61373, Category I, Class B - Body mounted E-Mark, EN 50121 (EN 50155 EMC)
-
Page 13: Dimension Of Poc-751Vtc
POC-751VTC Dimension of POC-751VTC NOTE All measurements are in millimeters (mm). 1.2.1 Front Panel View... -
Page 14: Reserved Panel View
POC-751VTC 1.2.2 Reserved Panel View 1.2.3 COM Port Panel View... -
Page 15: Bottom View
POC-751VTC 1.2.4 Bottom View... -
Page 16: System Overview
POC-751VTC System Overview Upon receiving and unpacking your POC-751VTC systems, please check immediately if the package contains all the items listed in the following table. If any item(s) are missing or damaged, please contact your local dealer or Neousys Technology. Unpacking the System Item Description... -
Page 17: Poc-751Vtc Series Front Panel
POC-751VTC POC-751VTC Series Front Panel The front panel of POC-751VTC series features four PoE+ Gigabit Ethernet ports, four USB 3.2 Gen1 ports, one HDMI, one DisplayPort, remote control and 3-pin terminal block with ignition control for DC input. Item Description... -
Page 18: System Status Led
POC-751VTC 2.2.1 System Status LED There are three LED indicators on the front panel: HDD, WDT and IGN. The descriptions of these LEDs are listed in the following table. Indicator Color Description Green Power indictor, lit when system is on. Hard drive indicator, flashing when SATA HDD is active Yellow Watchdog timer indicator, flashing when watchdog timer has started... -
Page 19: Hdmi
POC-751VTC 2.2.2 HDMI The High-Definition Multimedia Interface (HDMI) port provides uncompressed high-quality digital video and audio transmission between the system and a multimedia display device on a single cable. You can connect to other digital inputs by using a HDMI-to-DVI or HDMI-to-DP cable. HDMI-to-DP The system supports dual independent display outputs by connecting display devices to HDMI and DisplayPort connection. -
Page 20: Displayport
POC-751VTC 2.2.3 DisplayPort The system has a DisplayPort (DP) output which is a digital display interface that mainly connect video source and carry audio to a display device. When connecting a DP, it can deliver up to 4K UHD (4096 x 2160 @ 60Hz) in resolution. The system is designed to support passive DP adapter/ cable. -
Page 21: Reset Button
POC-751VTC 2.2.4 Reset Button The reset button is used to manually reset the system in case of system halt or malfunction. To avoid unexpected reset, the button is purposely placed behind the panel. To reset, please use a pin-like object (eg. tip of a pen) to access the reset button 2.2.5 USB3.2 Gen2x1 Port... -
Page 22: Ieee 802.3At Power Over Ethernet Port
POC-751VTC 2.2.6 IEEE 802.3at Power over Ethernet Port The system offers four Gb Ethernet ports via Intel® I350-AM4 and is backward compatible with 100/ 10Mb connection speeds. The Gigabit Power over Ethernet (PoE) port can supply power and data on a standard CAT-5/CAT-6 Ethernet cable. -
Page 23: 3-Pin Terminal Block For Dc Input With Ignition Power Control
POC-751VTC 2.2.7 3-pin Terminal Block for DC Input with Ignition Power Control The system accepts a wide range of DC power input from 8V to 35V via a 3-pin pluggable terminal block, which is fit for field usage where DC power is usually provided. -
Page 24: 3-Pin Remote On/ Off
POC-751VTC 2.2.8 3-pin Remote On/ Off The “Remote On/ Off” 3-pin connection allows for external switch extension. It is useful when the system is placed in a cabinet or a not easily accessed location. You may connect an external remote with an external status LED indicator (15mA) by connecting to PWR LED and GND. -
Page 25: Dio/ Com Port Panel
POC-751VTC DIO/ COM Port Panel The COM port panel of POC-751VTC series features additional I/O functions, such as digital input/ output, COM ports, and reserved antenna openings for SMA antenna installation. In addition, the power button can also be located on this panel. -
Page 26: Digital Input/ Output
POC-751VTC 2.3.1 Digital Input/ Output The system provides 4x isolated digital input channels and 4x isolated digital output channels. The DIO functions support polling mode I/O access and DI change-of-state interrupt. Please refer to Watchdog Timer & Isolated DIO information on wiring and programming the isolated DIO channels. Pin# Pin Definition Pin#... - Page 27 POC-751VTC Wiring for DIO The digital input function is implemented using a photo-coupler with an internally series-connected 1kΩ resistor. You need to provide a voltage to specify the logic high/low state. The input voltage for logic high is 5~24V, and the input voltage for logic low is 0~1.5V.
-
Page 28: Com 1 Port
POC-751VTC 2.3.2 COM 1 Port Implemented using industrial-grade ITE8786 Super IO chip (-40 to 85°C) and provide up to 921600 bps baud rate, COM1 is a software-configurable RS-232/422/485 port via 9-pin D-Sub male connector. The operation mode, slew rate and termination of COM1 can be set in BIOS setup utility. -
Page 29: Com Port (Com2/ Com3/ Com4)
POC-751VTC 2.3.3 COM Port (COM2/ COM3/ COM4) Implemented using industrial-grade ITE8786 Super IO chip (-40 to 85°C) and provide up to 921600 bps baud rate, the D-Sub male connector (COM2/ 3/ 4) can be configured in the BIOS as single RS-422/ 485 port (COM2) or three 3-wire RS-232 ports (COM2/COM3/COM4). -
Page 30: Power Button
POC-751VTC 2.3.4 Power Button The power button is a non-latched switch for ATX mode on/off operation. Press to turn on the system, PWR LED should light up and to turn off, you can either issue a shutdown command in the OS, or just press the power button. In case of system halts, you can press and hold the power button for 5 seconds to force-shutdown the system. -
Page 31: Sma Antenna Opening
POC-751VTC 2.3.5 SMA Antenna Opening The system offers SMA antenna openings reserved for SMA antenna installations. Users can take advantage of the openings when installing mini-PCIe module for wireless communication reception such as 5G, 4G, GNSS or WiFi. -
Page 32: Can Bus And Dio Port Panel
POC-751VTC CAN bus and DIO Port Panel The CAN bus/ DIO panel features a CAN bus port that supports CAN2.0A/ CAN2.0B up to 1Mbps and 4x isolated digital input channels/ 4x isolated digital output channels. Item Description CAN bus port The CAN bus port allows the system to communicate with other in-vehicle CAN device(s). -
Page 33: Can Bus Port
POC-751VTC 2.4.1 CAN bus Port CAN bus is a robust industrial bus with a pair of differential signals and is commonly used in various industrial and in-vehicles applications. The system is equipped with a CAN bus DB9 port that is compatible with both industrial and in-vehicle applications. The CAN bus port supports CAN2.0A and CAN2.0B up to 1Mbps. -
Page 34: Digital Input/ Output
POC-751VTC 2.4.2 Digital Input/ Output The system provides 4x isolated digital input channels and 4x isolated digital output channels. The DIO functions support polling mode I/O access and DI change-of-state interrupt. Please refer to Watchdog Timer & Isolated DIO information on wiring and programming the isolated DIO channels. Pin# Pin Definition Pin#... -
Page 35: Cmos Reset Button
POC-751VTC CMOS Reset Button Positioned on the rear panel (opposite the IO panel), indicated by the blue arrow, the CMOS Reset button is used to manually reset the motherboard BIOS in case of system halt or malfunction. To avoid unexpected operation, it is purposely placed behind the panel. -
Page 36: Internal I/O
POC-751VTC Internal I/O The system’s internal I/O connectors consist of n mini-PCIe slot with SIM slot, an M.2 slot for NVMe SSD, SO-DIMM socket, slot and a MezIO port for application-oriented expansion purposes. 2.6.1 Full-size mini-PCIe Slot and SIM Socket The system provides two full-size mini-PCIe socket each with a dedicated SIM card slot (in corresponding colors). - Page 37 POC-751VTC mini-PCIe Pin Definition Pin # Signal Pin # Signal WAKE# +3.3Vaux COEX1 COEX2 +1.5V CLKREQ# UIM_PWR UIM_DATA REFCLK- UIM_CLK REFCLK+ UIM_RESET UIM_VPP Mechanical Key Reserved* (UIM_C8) Reserved* (UIM_C4) W_DISABLE# PERST# PERn0 +3.3Vaux PERp0 +1.5V SMB_CLK PETn0 SMB_DATA PETp0 USB_D- USB_D+ +3.3Vaux +3.3Vaux...
-
Page 38: 2280 (M Key) Slot For Ssd
POC-751VTC 2.6.2 M.2 2280 (M Key) Slot for SSD The system has an M key M.2 2280 slot supporting SATA signal only SSD storage. Users can install an SSD for improved disk read/ write performance over mechanical hard drives or 2.5” SSDs. NOTE The M.2 slot is only compatible with SATA signal M.2 SSD only. - Page 39 POC-751VTC M.2 (M Key) Slot Pin Definition Pin # Signal Pin # Signal +3V3 +3V3 +3V3 +3V3 +3V3 +3V3 SATA-B+ SATA-B- SATA-A- SATA-A+ Mechanical Key SUSCLK PEDET +3V3 +3V3 +3V3...
-
Page 40: So-Dimm Socket
POC-751VTC 2.6.3 SO-DIMM Socket The system supports one SO-DIMM socket for installing DDR5-4800 memory module up to 16GB in capacity. -
Page 41: Ignition Power Control Switch
POC-751VTC 2.6.4 Ignition Power Control Switch The ignition power control module for in-vehicle applications is an MCU-based implementation that monitors the ignition signal and reacts to turn on/off the system according to predefined on/off delay. For details, please refer to the section “Ignition Power Control”... -
Page 42: System Installation
POC-751VTC System Installation Before disassembling the system enclosure and installing components and modules, please make sure you have done the following: ⚫ It is recommended that only qualified service personnel should install and service this product to avoid injury or damage to the system. ⚫... -
Page 43: Disassembling The System Enclosure
POC-751VTC Disassembling the System Enclosure To install internal components such as M.2 SSD, memory module, or mini-PCIe module, you need to disassemble the system enclosure. Please refer to the following procedures: Remove the screws indicated on the front I/O panel. Remove the three (3) screws at the bottom. - Page 44 POC-751VTC Remove the two (2) screws on the rear panel. Remove the four (4) hex bolt screws on the DIO/ COM port panel. Separate the bottom panel from the system.
- Page 45 POC-751VTC Remove the screw indicated. Separate the DIO/ CAN bus port panel from the system. Remove the screw indicated and remove the I/O panel. Remove the screw Remove the I/O panel...
- Page 46 POC-751VTC Remove the screws securing the MezIO module, and gently lift and separate the MezIO module from the system. Remove screws securing MezIO module Separate MezIO module from system 10. Unscrew the two (2) screws to remove the DRAM/ M.2 heat spreader. Remove the screws securing heat spreader Separate the heat spreader from system 11.
-
Page 47: Installing Internal Components
POC-751VTC Installing Internal Components 3.2.1 DDR5 SO-DIMM Installation There is one SO-DIMM memory slot on the motherboard. Please follow the procedures below to install the memory module. Disassemble the system enclosure. 2. Locate the SO-DIMM slot on the motherboard shown once the enclosure and heat spreader have been removed. - Page 48 POC-751VTC 4. Remove the protection film on the thermal pad. 5. Secure the DRAM/ M.2 heatsink spreader onto the side of the system heatsink. Reinstall the enclosure when done.
-
Page 49: 2880 M Key Ssd Installation
POC-751VTC 3.2.2 M.2 2880 M Key SSD Installation There is one M.2 2280 M Key slot for you to install an SSD. Please follow the procedures below to install the M.2 SSD module. Disassemble the system enclosure. 2. Located the M.2 2280 M Key slot once the system enclosure and heat spreader have been removed. - Page 50 POC-751VTC 4. Gently push it towards the motherboard and secure the SSD with the supplied screw. 5. Once you have installed the SSD, you need to reinstall the heat spreader but before you do so, please make sure the protective film on the thermal pad has been removed.
-
Page 51: Mini-Pcie Module, Sim Card And Antenna Installation
POC-751VTC 3.2.3 mini-PCIe Module, SIM Card and Antenna Installation The mini-PCIe and SIM slots are on the MezIO module. Please follow the procedures below to install the mini-PCIe module and SIM card, as well as the antenna for wireless communication. Disassemble the system enclosure. - Page 52 POC-751VTC 4. Flip the holder back onto the SIM card and push in the direction shown to lock-in the SIM card into the slot. 5. To install the mini-PCIe module, insert the module’s gold fingers on a 45 degree angle into the socket, gently press the module down and secure it with a screw. 6.
- Page 53 POC-751VTC 7. Remove the protective film from the thermal pad. 8. Remove one of the antenna covers from the enclosure.
- Page 54 POC-751VTC 9. Secure the SMA antenna connector, reinstall the enclosure and attach the external SMA antenna. Securing antenna connection Attach external antenna 10. Repeat steps 3 to 8 if you wish to install another mini-PCIe module. Reinstall the enclosure when done.
-
Page 55: Mini-Pcie To M.2 Adapter Card Installation (Optional)
POC-751VTC 3.2.4 mini-PCIe to M.2 Adapter Card Installation (Optional) Neousys Technology has optional mini-PCIe to M.2 expansion adapter cards. Please consult your sales representative for details should you have the need to install M.2 modules. mPCIe-M2B mPCIe-M2E mPCIe-M2M Form Factor M.2 2242 M key... - Page 56 POC-751VTC If you are installing a 5G/ 4G M.2 module, please install the SIM card onto the adapter first before securing the module onto the adapter. Insert the SIM card into the slot. You may use open-source freeware that communicates with Serial ports, such as PuTTY, to designate the SIM card you would like to use.
- Page 57 POC-751VTC Please refer to the module’s user manual on antenna cable connection. Remove the protection film on the thermal pad. Reinstall the enclosure when done.
-
Page 58: Installing The System Enclosure
POC-751VTC Installing the System Enclosure Install the DRAM/ SSD heatsink and secure with screws indicated. Install heatsink Secure heatsink with screws Align and lower the MezIO module onto the motherboard while matching the three copper stands, and secure with screws indicated. Lower MezIO module onto copper stands Secure MezIO module with screws Install the front I/O panel and secure with screw indicated. - Page 59 POC-751VTC Install the bottom/ COM port panel. Secure the hex bolt screws on the DIO/ COM port panel. Secure the two screws on the rear.
- Page 60 POC-751VTC Secure the screws at the bottom of the enclosure. Secure the screws on the front I/O panel to complete the enclosure installation process.
-
Page 61: Wall Mount Installation
POC-751VTC Wall Mount Installation 3.4.1 Horizontal Wall Mount Installation The horizontal wall mount bracket allows the system to be mounted horizontally. Please refer to the following installation procedure: Remove the rubber stands to access the M4 tapping (indicated in green). To install, secure the wall mount bracket (indicated in red) to the bottom of the system enclosure using the M4 screws (indicated in blue) provided. - Page 62 POC-751VTC Dimension illustration of the installed horizontal wall mount bracket for your reference.
- Page 63 POC-751VTC...
-
Page 64: Vertical Wall Mount Bracket (Optional)
POC-751VTC 3.4.2 Vertical Wall Mount Bracket (optional) To install, secure the vertical wall mount bracket (indicated in red) to the rear panel of the system using the M4 screws provided (indicated in blue). Dimension illustration of the install vertical wall mount bracket for you reference. -
Page 65: Powering On The System
POC-751VTC Powering On the System There are several methods to power on the system ⚫ Pressing the power button ⚫ Via an external non-latched switch ⚫ Sending a LAN packet via Ethernet (Wake-on-LAN) ⚫ Via Power Ignition Control 3.5.1 Powering On Using the Power Button This is the simplest way to turn on your system. -
Page 66: Powering On Using An External Non-Latched Switch
POC-751VTC 3.5.2 Powering On Using An External Non-Latched Switch If your application demands the system to be placed inside a cabinet, you may use an external non-latched switch to power on/ off the system. The system provides a 3-pin “Remote On/ Off” plug for connecting a non-latched switch and acts as the ATX-mode power on/off control switch. -
Page 67: Powering On Using Wake-On-Lan
POC-751VTC 3.5.3 Powering On Using Wake-on-LAN Wake-on-LAN (WOL) is a mechanism to wake up a computer system from a S3 (standby), S4 (Hibernate) or S5 (system off with standby power) state via issuing Subnet Directed Broadcasts (SDB) or a magic packet. The system implements the Wake-on-LAN function for the GbE ports highlighted in blue, shown below. - Page 68 POC-751VTC Click the Power Management tag, and check the following two options accordingly ⚫ Wake on Magic Packet The system can wake from S3 or S4 state when receiving a magic packet. The magic packet is a broadcast frame containing anywhere within its payload 6 bytes of all 255 (FF FF FF FF FF FF in hexadecimal), followed by sixteen repetitions of the target computer's 48-bit MAC address.
- Page 69 POC-751VTC 78 D0 04 0A 0B 0C 78 D0 04 0A 0B 0C 78 D0 04 0A 0B 0C 78 D0 04 0A 0B 0C 78 D0 04 0A 0B 0C 78 D0 04 0A 0B 0C 78 D0 04 0A 0B 0C 78 D0 04 0A 0B 0C MISC There are some free tools available on Internet that can be used to send a magic packet.
-
Page 70: Bios Settings
POC-751VTC BIOS Settings The system is shipped with factory-default BIOS settings optimized for best performance and compatibility. In this section, we’ll illustrate some BIOS settings you may need to set or change prior to operating system installation. Please always make sure you understand the effect of change before you proceed with any changes. -
Page 71: Com1 Port Configuration
POC-751VTC COM1 Port Configuration The system’s COM1 port support RS-232 (full-duplex), RS-422 (full-duplex) and RS-485 (half-duplex) mode. You can set the COM1 operating mode via BIOS settings. The option in the BIOS setting called “Slew Rate” defines how sharp the rising/falling edge is for the output signal of COM1. -
Page 72: Com 2/ 3/ 4 Port Configuration
POC-751VTC COM 2/ 3/ 4 Port Configuration The system’s COM 2/ 3/ 4 ports support RS-232 (full-duplex). When set to RS-422/485 mode, it will only act as COM2 port only. To enable COM/ 3/ 4 operating mode: Press F2 when the system boots up to enter the BIOS setup utility. Go to [Advanced] →... -
Page 73: Com Port High Speed Mode
POC-751VTC COM Port High Speed Mode The high speed mode of each COM port effectively allows for the port's baud rate generator to operate at 8x the speed with an effective baud rate of 921,600 bps (115,200 x 8). Please refer to the following instructions on how to enable the high speed mode for your COM port (COM1 used as an example). -
Page 74: Tpm Availability
POC-751VTC TPM Availability Trusted Platform Module (TPM) is a hardware-based cryptoprocessor to secure hardware by integrating cryptographic keys into devices. The system is designed with on-board TPM 2.0 module. It is enabled in the BIOS by default. To enable TMP availability: When system boots up, press F2 to enter BIOS setup utility. -
Page 75: Power Over Ethernet (Poe)
POC-751VTC Power over Ethernet (PoE) The Power over Ethernet (PoE) setting in the BIOS allows you to enable/ disable the PoE function of the designated port upon system boot up. To enable/ disable Power over Ethernet settings: Press F2 when the system boots up to enter the BIOS setup utility. Go to [Power] →... -
Page 76: Wake-On-Lan
POC-751VTC Wake-on-LAN Wake-on-LAN (WOL) is a mechanism which allows you to turn on your system via Ethernet connection. To utilize Wake-on-LAN function, you have to enable this option first in BIOS settings. Please refer to Powering on via Wake-on-LAN function. To enable/ disable “Wake on LAN”... -
Page 77: C-States
POC-751VTC C-States Intel processors utilize C-States to regulate the power-draw and operating frequency of each core. By enabling this function, it allows BIOS to reduce the operating frequency, power-draw, or both of the idle processor core for the system to operate more efficiently. - Page 78 POC-751VTC Highlight “C states” and press ENTER, set to “Enabled” and press ENTER. Press F10 to “Save and Exit”.
-
Page 79: Auto Wake On S5
POC-751VTC Auto Wake on S5 When the system is set to operate in S5 state, the user can specify a time to turn on the system, daily or monthly. Value Option Description Auto Wake on S5 Disabled The system does not turn on when operating in state S5. -
Page 80: Ignition Power Control
POC-751VTC Ignition Power Control NOTE The ignition power control’s MCU is not a part of the BIOS and therefore its settings will NOT be affected when your press the CMOS button of your system. Should you clear the CMOS and you wish to reconfigure the IGN power-on delay setting also, please do the refer to the following steps: 1. - Page 81 POC-751VTC To set IGN settings: Press F2 when the system boots up to enter the BIOS setup utility. Go to [Power] > [Ignition Power Control] and press ENTER. Highlight [IGN Operation Mode] and select the setting you desire Setting Description [ATX] The power button turns on/ off the system without delay.
- Page 82 POC-751VTC The ignition power off delay has the following predefined settings. You can also set the battery supplied voltage to suit your vehicle type.
- Page 83 POC-751VTC A low battery threshold can also be set.
-
Page 84: 4.10 Boot Menu
POC-751VTC 4.10 Boot Menu The Boot menu in BIOS allows you to specify the system’s boot characteristics by setting bootable device components (boot media) and method. Or, you may press F12 upon system start up and select a device you wish boot from. Value Option Description... - Page 85 POC-751VTC Newly detected boot media are placed at the top Add Boot Options First of the boot order. Newly detected boot media are placed at the Last bottom of the boot order. Newly detected boot media order will be Auto automatically detected and placed in boot order.
-
Page 86: 4.11 Position New Boot Device
POC-751VTC 4.11 Position New Boot Device The “Add Boot Options” allow you to determine whether a newly added device (eg. USB flash disk) is to boot as the first device to boot or the last in the boot sequence. To set the newly-installed boot device as the first or last boot device: Press F2 when the system boots up to enter the BIOS setup utility. -
Page 87: 4.12 Watchdog Timer
POC-751VTC 4.12 Watchdog Timer The watchdog timer secures the boot process by means of a timer. Once the timer expires, a reset command is issued to initiate another booting process. There are two options in BIOS menu, “Automatically after POST” and “Manually after Entering OS”. -
Page 88: Os Support And Driver Installation
Operating System Compatibility The system supports most operating system developed for Intel® x86 architecture. The following list contains the operating systems which have been tested by Neousys Technology. ⚫ Microsoft Window 10 LTSC 2021 (x64) Microsoft Windows 11 IoT Enterprise 22H2 64-bit ⚫... -
Page 89: Driver Installation
POC-751VTC Driver Installation The system drivers are available online, please click on this link to download the drivers. Driver Installation for Watchdog Time Control Neousys provides a driver package which contain function APIs for Watchdog Timer control function. You should install the driver package (WDT_DIO_Setup.exe) in prior to use these functions. -
Page 90: Appendix A Using Wdt & Dio
In this section, we’ll illustrate how to use the function library provided by Neousys to program the WDT functions. Currently, WDT driver library supports Windows 10 x64 and WOW64 platform. For other OS support, please contact Neousys Technology for further information. -
Page 91: Wdt And Dio Library Installation
POC-751VTC WDT and DIO Library Installation WDT_DIO_Setup.2.4.0.0.exe will be used as an example to demonstrate WDT & DIO Library installation setup process. Please refer to the instructions below. 1. Execute WDT_DIO_Setup.2.4.0.0.exe. 2. Click “Next >” and specify the directory of installing related files. The default directory is C:\Neousys\WDT_DIO. - Page 92 POC-751VTC 3. Once the installation has finished, a dialog will appear to prompt you to reboot the system. The WDT & DIO library will take effect after the system has rebooted. 4. When programming your WDT or DIO program, the related files are located in Header File: \Include Library File:...
-
Page 93: Wdt Function Reference
POC-751VTC WDT Function Reference InitWDT Syntax BOOL InitWDT(void); Description: Initialize the WDT function. You should always invoke InitWDT() before set or start watchdog timer. Parameter None Return Value TRUE: Successfully initialized FALSE: Failed to initialize Usage BOOL bRet = InitWDT() SetWDT Syntax BOOL SetWDT(WORD tick, BYTE unit);... -
Page 94: Startwdt
POC-751VTC StartWDT Syntax BOOL StartWDT(void); Description Starts WDT countdown. Once started, the WDT LED indicator will begin blinking. If ResetWDT() or StopWDT is not invoked before WDT countdowns to 0, the WDT expires and the system resets. Parameter None Return Value f the timeout value is given in correct format (WDT started), this function returns TRUE, otherwise FALSE Usage... -
Page 95: Dio Functions
POC-751VTC DIO Functions InitDIO Syntax BOOL InitDIO(void); Initialize the DIO function. You should always invoke InitDIO() Description before write/read any DIO port/channel. Parameter None Return Value Returns TRUE if initialization successes, FALSE if initialization failed. Usage BOOL bRet = InitWDT() DIReadLine Syntax BOOL DIReadLine(BYTE ch);... -
Page 96: Dowriteline
POC-751VTC DOWriteLine Syntax void DOWriteLine(BYTE ch, BOOL value); Write a single channel of isolated digital output. Description Parameter BYTE value specifies the DO channel to be written. Ch should be a value of 0 ~ 7. value BOOL value (TRUE or FALSE) specifies the status of DO channel. -
Page 97: Appendix B Poe On/ Off Control
POC-751VTC Appendix B PoE On/ Off Control The system offers four 802.3at PoE+ ports with a unique feature to allow users manually turn on or off the power supply of each PoE port. This can be function can be useful in power device (PD) fault-recovery or power reset. The function APIs are encapsulated in Neousys WDT_DIO driver package. -
Page 98: Enablepoeport
POC-751VTC EnablePoEPort Syntax BOOL EnablePoEPort (BYTE port); Description Turn on PoE power of designated PoE port. Parameter port BYTE value specifies the index of PoE port. Please refer to the following illustration, port should be a value of 1 ~ 4 Return Value TRUE if enabled success FALSE if fail to enable. -
Page 99: Disablepoeport
POC-751VTC DisablePoEPort Syntax BOOL DisablePoEPort (BYTE port); Description Turn off PoE power of designated PoE port Parameter port BYTE value specifies the index of PoE port. Please refer to the following illustration, port should be a value of 1 ~ 4 Return Value TRUE if disabled success FALSE if fail to disable...
