PRO6000H & PRO6000HCH
SaltDogg
Hydraulic Drive Poly
®
Hopper Spreaders
4.0 cubic yards
Table of Contents
General Information ....................................................................1
Safety Precautions ......................................................................1
Installation Instructions ........................................................... 2-4
Spreader Operation ................................................................ 3-4
Spreader Maintenance ................................................................4
Repair Parts & Drawings ......................................................... 5-8
Warranty Information ..................................................................8
General Information
Overall Length: 136.3 inches
Overall Width: 77 inches
Overall Height: 57 inches
Empty Weight: 1675 lbs
Capacity Struck: 6.0 cu. yd.
Vehicle Requirements
Trucks with GVWR 25,999 lbs min.
150 AMP or higher alternator is recommended.
Average Material Weights
Materials to use
Fine Salt-Dry
Coarse Salt-Dry
Sand Coarse-Dry
Note: To calculate the total spreader weight (including ice
control material), add the empty spreader weight plus the ice
control material and spreader accessories.
WARNING
Improper installation and operation could cause
personal injury, and/or property damage. Observe
the following Safety Precautions before, during and
after operating this spreader. By following these
precautions and common sense, possible injury to
persons and potential damage to this machine may
be avoided.
Installation Instructions
Weight (pounds per cubic yard)
2,250
1,431
2,565
Do not overload vehicle beyond the vehicle's GVWR
or GAWR. Check vehicle's load rating certification
sticker for maximum vehicle capacity.
Safety Precautions
1. Read this entire Owners Manual before operating this
spreader.
2. Read all safety decals on the spreader before operating.
3. Check to make sure all safety guards are securely mounted
into place before operating this spreader.
4. Verify that all personnel are clear of the spreader spray area
before starting or operating this spreader.
5. Do not over-load your vehicle beyond payload limits. If there
are any questions, contact the vehicle manufacturer.
6. Do not adjust, clean, lubricate or unclog material jambs
without first turning off the spreader.
7. Do not climb on or in the spreader during operation. Do not
ride on the spreader while the vehicle is in motion.
8. Make sure the spreader is securely fastened to the vehicle in
accordance with this manual.
9. Do not operate a spreader that is in need of maintenance or
repairs.
10. Batteries normally produce explosive gases which can
cause personal injury. Always disconnect the battery before
removing or replacing electrical components.
11. Do not leave unused material in hopper. Material can freeze
or solidify, causing spreader to not work properly, and/ or
damage the unit. Empty and clean after each use.
1
www.buyersproducts.com
Phone (440) 974-8888
Fax 800-841-8003
CAUTION
—continued inside

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SaltDogg PRO6000H and is the answer not in the manual?

Questions and answers

Summary of Contents for Buyers SaltDogg PRO6000H

  • Page 1 www.buyersproducts.com Phone (440) 974-8888 Fax 800-841-8003 Installation Instructions PRO6000H & PRO6000HCH SaltDogg Hydraulic Drive Poly ® Hopper Spreaders 4.0 cubic yards Table of Contents General Information ..............1 Safety Precautions ..............1 Installation Instructions ............2-4 Spreader Operation ..............3-4 Spreader Maintenance ..............4 Repair Parts &...
  • Page 2: Installation Instructions

    www.buyersproducts.com Phone (440) 974-8888 Fax 800-841-8003 INSTALLATION INSTRUCTIONS CAUTION MOUNTING THE SPREADER ONTO THE VEHICLE: A. Remove the tailgate from the vehicle (if equipped) as well as Inspect straps and hardware after each time spreader any other object which will interfere with the spreader. is loaded.
  • Page 3: Operating The Spreader

    www.buyersproducts.com Phone (440) 974-8888 Fax 800-841-8003 Spreader Start-up Main Components 1. Set feed gate opening and baffle positions for desired ITEM PART NO. QTY. DESCRIPTION HV715 Dual Flow Regulator Valve material flow and spread pattern. – Reservoir 25 Gal Min 2.
  • Page 4: Spreader Maintenance

    www.buyersproducts.com Phone (440) 974-8888 Fax 800-841-8003 4. SPINNER/CHUTE ASSEMBLY OPERATION B. If the material in the hopper freezes, move the spreader into a warm area to thaw. C. To prevent the feed chain from freezing, do not store material in the spreader. D.
  • Page 5: Bill Of Material

    www.buyersproducts.com Phone (440) 974-8888 Fax 800-841-8003 Repair Parts - Chute Assembly Part # 3052106 Bill of Material ITEM PART NO. QTY. DESCRIPTION ITEM PART NO. QTY. DESCRIPTION 3052038 CHUTE LOWER WELDM FNE031018034SS NUT, NYLOCK, 5/16-18, GR A, SST 3056844 GHUTE UPPER, PRO 3018701 SCREW, HHC 5/16-18 X 1.0 SST FULL THD CM004P...
  • Page 6: Bill Of Materials

    www.buyersproducts.com Phone (440) 974-8888 Fax 800-841-8003 PRO6000H Hopper Assembly Bill of Materials ITEM PART NO. QTY. DESCRIPTION ITEM PART NO. QTY. DESCRIPTION 3018430 HOPPER POLY 6 CU YA 3017356 WASHER, EXTERNAL TOOTH LOCK 3/8 SS 3052789 TROUGH WELDMENT PRO6000 3053487 CHUTE ATTACHMENT, 4000/6000 3017858 40 WASHER FLAT .5 ID 1.5 OD SST...
  • Page 7 www.buyersproducts.com Phone (440) 974-8888 Fax 800-841-8003 PRO6000HCH Hopper Assembly Bill of Materials ITEM PART NO. QTY. DESCRIPTION FCS050013100SS SCREW, HHC-1/2-13 X 1 SST ITEM PART NO. QTY. DESCRIPTION 3009215 COUPLING, SHAFT 1 X 1 3036849 TROUGH WELDMENT SHPE6000CH CM004P MOTOR, HYD 4 BOLT 3036857 HOPPER POLY 6 CU YA FWL038069009SS...
  • Page 8 This warranty replaces all previous warranties and no employee of this company is authorized to extend additional warranties, or agreements, or implications not explicitly covered herein. Buyers Products Company warrants all parts of the product to be free from defects in material and workmanship for a period of two (2) years. Parts must be properly installed and used under normal conditions.
