September 2012
SERVICE MANUAL
ADDENDUM
series
CONTENTS
REPLACEMENT PAGES . . . . . . . . . . . . . . . . . . . . . . 7-1 to 7-3
PARTS LIST . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
BOARD LAYOUTS . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
VOLTAGE DIAGRAM . . . . . . . . . . . . . . . . . . . . . . . . . 21
[VERSION LIST]
MODEL
VERSION
GPS
F3261DT
USA-01
–
F3261DT
USA-02
F3261DT
USA-03
Yes
F3261DT
USA-04
F3261DT
USA-05
–
F3261DT
USA-06
Yes
F3262DT
EUR-01
F3262DT
DPM-01
–
F3262DT
DPM-02
Yes
F3263DT
EXP-01
–
F3263DT
EXP-02
F3263DT
EXP-03
Yes
F3263DT
AUS-01
F3263DT
CHN-01
–
F3261DS
USA-01
F3261DS
USA-03
F3261DS
USA-04
Yes
F3262DS
EUR-01
F3262DS
DPM-01
–
F3262DS
DPM-02
Yes
F3263DS
EXP-01
–
F3263DS
EXP-02
F3263DS
EXP-03
Yes
F3263DS
AUS-01
MAN
KEY
SELECTOR
DOWN
TYPE
–
16 ch
Rotary
Yes
16 ch
Rotary
–
10-key
Yes
–
Yes
–
16 ch
Yes
–
4-key
Yes
–
Yes
–
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Icom IC-F3260 Series
Summary of Contents for Icom IC-F3260 Series
- Page 1 September 2012 SERVICE MANUAL ADDENDUM series CONTENTS REPLACEMENT PAGES ..... . 7-1 to 7-3 PARTS LIST ....... . 1 BOARD LAYOUTS .
- Page 2 (Replacement page) September 2012 SECTION 7. MECHANICAL PARTS [CHASSIS PARTS] [VERSION LIST] ORDER MODEL VERSION SYMBOL DESCRIPTION QTY. F3261DT USA-01 6910021491 ANT CONNECTOR 106-1 <SSC> 6910015860 IMSA-6277S-02A-G F3261DT USA-02 2510001670 040D01201 F3261DT USA-03 F3261DT USA-04 8900016360 OPC-1190A 8900021220 OPC-2264 (P0.5N14L80) F3261DT USA-05 8900014750 OPC-519A (P0.5N30L55)
- Page 3 (Replacement page) September 2012 [CHASSIS UNIT] [CHASSIS UNIT] ORDER ORDER DESCRIPTION QTY. DESCRIPTION QTY. MP49 8930083700 DOUBLE SIDE TAPE (BM) MP12 8930085090 3401 KEYBOARD <SEP> 8930085090 3401 KEYBOARD <SEP> 8930083700 DOUBLE SIDE TAPE (BM) 8930085090 3401 KEYBOARD <SEP> 8930083700 DOUBLE SIDE TAPE (BM) 8930085090 3401 KEYBOARD <SEP>...
- Page 4 (Replacement page) September 2012 [RF UNIT] [ACCESSORIES] ORDER ORDER DESCRIPTION QTY. DESCRIPTION QTY. J601* 6510024930 20RF-JMCSG1BTF (N) (LF) (SN) (Optional) FA-SC55V-2 <EIK> (Optional) FA-SC55V-2 <EIK> F601* 5210001160 ERBRE3R00V (Optional) FA-SC55V-2 <EIK> (Optional) FA-SC55V-2 <EIK> MP601 8930085750 3401 EARTH SPRING Y1275 (Optional) FA-SC55V-2 <EIK>...
- Page 5 September 2012 SECTION 6. PARTS LIST [VERSION LIST] [MAIN UNIT] PARTS DESCRIPTION MODEL VERSION SYMBOL LOCATION 1110005310 S.IC AN6123MS 29.3/13.3 F3261DT USA-01 1180003670 S.REG BD9141MUV-E2 4.8/10.8 1110005340 S.IC NJM12902V-TE1-#ZZZB 39.5/12.5 F3261DT USA-02 1110008030 S.IC AK2346BP-E2 40.0/29.0 1110003800 S.IC NJM2904V-TE1-#FMZB 40.1/8.3 F3261DT USA-03 1140013200 S.IC...
- Page 6 September 2012 [MAIN UNIT] [MAIN UNIT] PARTS PARTS DESCRIPTION DESCRIPTION LOCATION LOCATION 1520000460 S.TRA 2SB1132 T100 R 54.7/9.5 1590002410 S.TRA UMH2N TN [B] T 2.8/18.9 Eqv. 1520000910 S.TRA 2SB1132L-R-AB3-R <SLVJ> 1590002410 S.TRA UMH2N TN Eqv. 1520000910 S.TRA 2SB1132L-R-AB3-R <SLVJ> 1590002410 S.TRA UMH2N TN Eqv.
- Page 7 September 2012 [MAIN UNIT] [MAIN UNIT] PARTS PARTS DESCRIPTION DESCRIPTION LOCATION LOCATION 1750001070 S.DIO DAN235ETL 69.7/29.3 1790001621 S.DIO 1SV308(TPL3F) 90.7/10.3 Eqv. 1750002470 S.DIO KDS112E-RTK/P 1750000721 S.VAR HVC375BTRF-E 104.3/22.6 Eqv. 1750002470 S.DIO KDS112E-RTK/P 1750002170 S.DIO DB2S31400L 103.4/14.1 Eqv. 1750002470 S.DIO KDS112E-RTK/P 1750002020 S.DIO DA2S10100L 96.4/22.4...
- Page 8 September 2012 [MAIN UNIT] [MAIN UNIT] PARTS PARTS DESCRIPTION DESCRIPTION LOCATION LOCATION 6050013420 S.XTA CR-936 DSX321G 19.6608 MHz 7030005040 S.RES ERJ2GEJ 472 X (4.7K) 48.0/17.8 <KDS> 1.9/28.2 7030005050 S.RES ERJ2GEJ 103 X (10K) 49.6/17.8 7030005240 S.RES ERJ2GEJ 473 X (47K) 45.7/28.0 7030005090 S.RES ERJ2GEJ 104 X (100K) 46.9/32.3...
- Page 9 September 2012 [MAIN UNIT] [MAIN UNIT] PARTS PARTS DESCRIPTION DESCRIPTION LOCATION LOCATION R185 7030007280 S.RES ERJ2GEJ 331 X (330) 82.8/31.9 R313 7030005040 S.RES ERJ2GEJ 472 X (4.7K) 24.8/6.7 R186 7030008370 S.RES ERJ2GEJ 561 X (560) 83.4/32.9 R314 7030005240 S.RES ERJ2GEJ 473 X (47K) 23.6/7.6 R189 7030008300 S.RES ERJ2GEJ 184 X (180K)
- Page 10 September 2012 [MAIN UNIT] [MAIN UNIT] PARTS PARTS DESCRIPTION DESCRIPTION LOCATION LOCATION R426 7030005240 S.RES ERJ2GEJ 473 X (47K) [B] T 3.4/16.3 4550000460 S.TAN TEESVA 1C 105M8R 36.0/26.5 7030005240 S.RES ERJ2GEJ 473 X (47K) Eqv. 4550007670 S.TAN F931C105MAABMA 7030005240 S.RES ERJ2GEJ 473 X (47K) Eqv.
- Page 11 September 2012 [MAIN UNIT] [MAIN UNIT] PARTS PARTS DESCRIPTION DESCRIPTION LOCATION LOCATION 4030017780 S.CER C1005 JB 1H 472K-T 52.8/27.4 C125 4030017460 S.CER C1005 JB 1H 102K-T 96.6/5.1 4030017420 S.CER C1005 CH 1H 470J-T 49.2/15.7 C126 4030017460 S.CER C1005 JB 1H 102K-T 92.8/10.6 4030016930 S.CER C1005 JB 1A 104K-T 35.9/13.5...
- Page 12 September 2012 [MAIN UNIT] [MAIN UNIT] PARTS PARTS DESCRIPTION DESCRIPTION LOCATION LOCATION C194 4550006250 S.TAN TEESVA 1A 106M8R 77.7/23.0 C266 4030016790 S.CER C1005 JB 1E 103K-T 98.0/35.8 Eqv. 4550007520 S.TAN F931A106MAABMA C267 4030017420 S.CER C1005 CH 1H 470J-T 103.3/38.0 Eqv. 4550007520 S.TAN F931A106MAABMA C268...
- Page 13 September 2012 [MAIN UNIT] [MAIN UNIT] PARTS PARTS DESCRIPTION DESCRIPTION LOCATION LOCATION C342 4550007730 S.TAN TEESVJ 0J 106M8R 7.2/12.8 C397 4550008780 S.TAN TCB6301226MR10S0150 27.6/7.9 Eqv. 4550008380 S.TAN TMCJ0J106MTRF Eqv. 4550008120 S.TAN TEPSLP 0G 226M-8R Eqv. 4550008380 S.TAN TMCJ0J106MTRF Eqv. 4550008760 S.TAN TCB1002226MR12S0150 Eqv.
- Page 14 September 2012 [MAIN UNIT] [MAIN UNIT] PARTS PARTS DESCRIPTION DESCRIPTION LOCATION LOCATION C442 4030017420 S.CER C1005 CH 1H 470J-T 21.3/35.3 6510027900 S.CON IMSA-9631S-10Y933 [B] T 105.1/19.1 C443 4030016930 S.CER C1005 JB 1A 104K-T 5.8/15.4 6510027900 S.CON IMSA-9631S-10Y933 C445 4030017420 S.CER C1005 CH 1H 470J-T 44.1/36.3 6510027900 S.CON IMSA-9631S-10Y933 C446...
- Page 15 September 2012 [RF UNIT] [RF UNIT] PARTS PARTS DESCRIPTION DESCRIPTION LOCATION LOCATION IC601 1110002751 S.IC TA75S01F(TE85RF) 23.7/23.3 C641 4030017530 S.CER C1005 CH 1H 0R5B-T 30.2/24.0 C642 4030017460 S.CER C1005 JB 1H 102K-T 26.9/20.7 C643 4030016790 S.CER C1005 JB 1E 103K-T 23.5/20.2 Q601 1530002881 S.TRA...
- Page 16 September 2012 [FRONT UNIT] [FRONT UNIT] PARTS PARTS DESCRIPTION DESCRIPTION LOCATION LOCATION IC701 1140013640 S.IC R5F211A1SP [B] B 34.1/14.7 Q707 1520000460 S.TRA 2SB1132 T100 R 87.8/29.4 1140013640 S.IC R5F211A1SP Eqv. 1520000910 S.TRA 2SB1132L-R-AB3-R <SLVJ> 1140013640 S.IC R5F211A1SP Eqv. 1520000910 S.TRA 2SB1132L-R-AB3-R <SLVJ>...
- Page 17 September 2012 [FRONT UNIT] [FRONT UNIT] PARTS PARTS DESCRIPTION DESCRIPTION LOCATION LOCATION D703 1160000140 S.DIO DAP222 TL 63.6/25.8 R725 7030005120 S.RES ERJ2GEJ 102 X (1K) 87.5/24.0 Eqv. 1750002390 S.DIO KDS120E-RTK/P R726 7030005000 S.RES ERJ2GEJ 471 X (470) 82.7/32.0 Eqv. 1750002390 S.DIO KDS120E-RTK/P R727 7030004980 S.RES ERJ2GEJ 101 X (100)
- Page 18 September 2012 [FRONT UNIT] [FRONT UNIT] PARTS PARTS DESCRIPTION DESCRIPTION LOCATION LOCATION R772 7030005230 S.RES ERJ2GEJ 334 X (330K) [B] B 26.0/8.6 C723 4550000460 S.TAN TEESVA 1C 105M8R 114.7/29.9 7030005230 S.RES ERJ2GEJ 334 X (330K) Eqv. 4550007670 S.TAN F931C105MAABMA 7030005230 S.RES ERJ2GEJ 334 X (330K) Eqv.
- Page 19 September 2012 [FRONT UNIT] [FRONT UNIT] PARTS PARTS DESCRIPTION DESCRIPTION LOCATION LOCATION C740 4030016930 S.CER C1005 JB 1A 104K-T 84.0/38.1 C753 4550006250 S.TAN TEESVA 1A 106M8R 89.5/6.0 C741 4030016930 S.CER C1005 JB 1A 104K-T 93.3/32.3 Eqv. 4550007520 S.TAN F931A106MAABMA C742 4030006860 S.CER C1608 JB 1H 102K-T [A] B 26.3/16.9...
- Page 20 September 2012 [FRONT UNIT] [FRONT UNIT] PARTS PARTS DESCRIPTION DESCRIPTION LOCATION LOCATION C762 4550008340 S.TAN F931A686MBA 99.9/20.3 J701 6510022711 S.CON 30FLZ-SM2-TB(LF)(SN) 24.0/34.1 Eqv. 4550007880 S.TAN TEESVB2 1A 686M8R J702 6510027940 S.CON IMSA-9631S-08Y933 112.9/35.4 Eqv. 4550007880 S.TAN TEESVB2 1A 686M8R J704 6510027930 S.CON IMSA-9631S-14Y933 112.2/12.4 Eqv.
- Page 21 September 2012 [FRONT UNIT] [VR-A UNIT] PARTS PARTS DESCRIPTION DESCRIPTION LOCATION LOCATION EP703 6910013370 S.BEA BLM18BB221SN1D R502 7210003610 VAR F081-0025A <SLVJ> (BLM11B221SB) [B] B 21.0/16.9 6910013370 S.BEA BLM18BB221SN1D (BLM11B221SB) J501 6510027900 S.CON IMSA-9631S-10Y933 7.2/2.9 6910013370 S.BEA BLM18BB221SN1D (BLM11B221SB) 6910013370 S.BEA BLM18BB221SN1D S501 2250000800 ENC...
- Page 22 September 2012 [VR-B UNIT] [JACK UNIT] (For [USA-02], [USA-05], [USA-06] of IC-F3261DT) PARTS PARTS DESCRIPTION DESCRIPTION LOCATION LOCATION R502 7210003610 VAR F081-0025A <SLVJ> D803 1790001810 S.VAR AVR-M1005C080MTABB 11.8/8.1 D804 1790001810 S.VAR AVR-M1005C080MTABB 10.8/8.1 D805 1790001810 S.VAR AVR-M1005C080MTABB 7.6/8.1 J501 6510027900 S.CON IMSA-9631S-10Y933 7.2/2.9 D806 1790001810 S.VAR...
- Page 23 September 2012 The combination of top side and bottom side of this SECTION 8 BOARD LAYOUTS • JACK UNIT (TOP VIEW) EP801 EP802 B7668B EP803 J801 J801 EP804 • RF UNIT J802 (TOP VIEW) J802 D601 EP604 F601 C638 D602 R614 C680 C644...
- Page 24 September 2012 The combination of top side and bottom side of this • JACK UNIT (BOTTOM VIEW) MP801 • RF UNIT (BOTTOM VIEW) C661 C662 C641 C613 C625 C631 C626 C673 R613 C608 R608 C645 C611 C616 • VR-A UNIT L607 L609 C615...
- Page 25 September 2012 SECTION 11. VOLTAGE DIAGRAM • FRONT UNIT *R783 EMER *EP701 *R771 *R777 CIRQM *R774 OPT3 *R749 OPV3 R722 FSDA TLED IC709 ZOUT RLED *IC701 *IC708 MDET P3_5/SSCK/SCL P3_4/SCS/SDA R717 FSCL P3_7/CNTRO/SSO P3_3/TCIN/INT3 RESET P1_0/KI0/AN8 5.00V TC7WBD125AFK *R746 XOUT/P4_7 P1_1/KI1/AN9 *R743 VSS/AVSS...
- Page 26 September 2012 CPU5V CPU5V • MAIN UNIT (1/4) 100k NJM12902V DMG504010 IC12 CDEC DASW DASW 4.7k SDEC2 RSSI RSSI 100k SDEC VIN1 VIN8 VOUT1 VOUT8 NJM12902V 120k TONEA VOUT2 VOUT7 VIN2 VIN7 180k NJM2904V RESET MICA VDAREF CENC0 100k VIN3 VIN6 LDTC144EE R114...
- Page 27 September 2012 • MAIN UNIT (2/4) 5.00V VCO5V 4.09V 2SC4116 ACZ1005Y NJM2904V TEMP C226 C241 1.2U 15.3MHz 2SC4226 730mVp-p C257 4.86V R138 HVC350B 0.5P 100k 2SK880 R129 R141 R130 VCON 1.2U 3401 680k NJM2904V TX 2.00V 15.3MHZ C493 R179 0.001 R165 C228 C242...
- Page 28 September 2012 • MAIN UNIT (3/4) R272 R274 NFM18PC104R1C3 C334 NFM18PC104R1C3 C500 MMZ1005S601CT AGND EMU1 EP15 TRST MMZ1005S601CT EP14 DVDD_3.3V MMZ1005S601CT EP13 EMU0 MMZ1005S601CT EP12 MMZ1005S601CT CP116 DRESET NFM18PC104R1C3 C335 +3.3V_A BDX0 EMU0 EMU1 CP06S BFSR0 DRESET CP115 BFSX0 CP111 CP06S CP112 CP06S...
- Page 29 September 2012 • MAIN UNIT (4/4) +3.3V CPU5V BLM18RK102SN1 EP10 1.35V IC32 VLCF4028T CPU5V 2.2U TPS62200DBVR DASW DASW RSSI RSSI POSW R384 100k SIDE3 R385 100k SIDE2 R386 100k MTCK R387 100k CPU5V MMUT R388 100k R406 ESCL R389 100k TMUT ESDA DASW...
- Page 30 September 2012 TX 5.00V • RF UNIT • VR-A UNIT J501 R601 S501 NFM60R20T152 FI601 CBI0 CBI1 CBI2 CBI3 TP70TF5164S R502 MP501 PWRSW OG-603060 AFVI TX 0.10V F081-0025A C604 J601 • VR-B UNIT L607 L608 L609 D605 L612 L613 L614 C605 C618 C647...
- Page 31 VHF TRANSCEIVERS S-14910XZ-C1 August 2012...
- Page 32 8. READ the instructions of the test equipment thoroughly before connecting it to the transceiver. Icom, Icom Inc. and the Icom logo are registered trademarks of Icom Incorporated (Japan) in Japan, the United States, the United Kingdom, Germany, France, Spain, Russia and/or other countries.
- Page 33 TABLE OF CONTENTS SECTION SPECIFICATIONS SECTION INSIDE VIEWS SECTION DISASSEMBLY INSTRUCTION SECTION CIRCUIT DESCRIPITON RECEIVER CIRCUITS ..................4-1 TRANSMITTER CIRCUITS ................4-2 FREQUENCY SYNTHESIZER CIRCUITS ............4-4 VOLTAGE BLOCK DIAGRAM ................4-4 PORT ALLOCATIONS ..................4-5 SECTION ADJUSTMENT PROCEDURES PREPARATION ....................5-1 FREQUENCY ADJUSTMENT ................
- Page 34 SECTION 1. SPECIFICATIONS GENERAL • Frequency range : 136 to 174 MHz • Number of conventional channels : 512 (128 zones) • Type of emission : Wide 16K0F3E (25.0 kHz) Except [USA] Middle 14K0F3E (20.0 kHz) [EUR], [DPM] Narrow 11K0F3E (15.0kHz) [USA] 8K50F3E (12.5 kHz) Except [USA]...
- Page 35 RECEIVER • Sensitivity : Analog 0.23 µV typical (at 12 dB SINAD) Except [EUR], [DPM] –4.0 dBµV emf typical (at 20 dB SINAD) [EUR], [DPM] Digital –8.0 dBµV emf typical (at 5% BER) • Squelch sensitivity (at threshold) : 0.20 µV typical Except [EUR], [DPM] –8.0 dBµV emf typical [EUR], [DPM] •...
- Page 36 SECTION 2. INSIDE VIEWS • FRONT UNIT (BOTTOM VIEW) DATA LINE BUFFER (IC709) MIC MUTE SW MIC/AF AMP (Q708) (IC705) AF POWER AMP POWER SUPPLY LINE DRIVER (IC706) (For AF POWER AMP) (Q707) EXPANDER (IC702) BACKLIGHT LED DRIVER (Q705) BACKLIGHT LED SW (Q702) EXPANDER (IC703)
- Page 37 • MAIN UNIT AGC AMP (TOP VIEW) (Q41) D/A CONVERTER (IC33) 1ST IF FILTER (For FM wide mode) (FI3) DISCRIMINATOR (X4) 2ND IF FILTER (FI2) 2ND IF FILTER (For FM narrow and digital modes) (FI1) DIGITAL IF AMP (IC13) DIGITAL IF FILTER +5 V REGULATOR (FI5) (IC11)
- Page 38 • MAIN UNIT (BOTTOM VIEW) 1ST IF FILTER (For FM narrow and digital modes) (FI4) VCO SW (Q36) VCO SW (Q35) VCO SW IF IC (Q37) (IC15) RIPPLE FILTER TRIPLER (Q24) (Q21) LOCK VOLTAGE BUFFER LV SW (Q22) (Q25) TONE AMP (Q2) PLL IC (IC14)
- Page 39 5) Disconnect the fl at cable from J5, and then remove panel. the FRONT UNIT from the chassis. Screws Knob Knob Antenna nut Remove with; “ICOM Driver (K)” (8960000110) FRONT UNIT Chassis MAIN UNIT FLAT CABLE 2) Remove 2 screws from the chassis. BE CAREFUL about the locks.
- Page 40 3. REMOVING THE JACK UNIT 4. REMOVING THE RF UNIT 1) Unsolder 8 points at the dial. 1) Unsolder 4 points as shown. DIAL UNSOLDER RF UNIT UNSOLDER Solder remover VR UNIT Solder remover UNSOLDER Chassis Solder remover Chassis 2) Remove 4 screws from the RF UNIT, and then remove the RF UNIT from the chassis.
- Page 41 SECTION 4. CIRCUIT DESCRIPTION 2ND IF CIRCUIT (MAIN UNIT) 4-1 RECEIVE CIRCUITS The 1st IF signal is applied to the IF IC (IC15, pin 16), which RF CIRCUIT (RF UNIT AND MAIN UNIT) contains the 2nd IF mixer, 2nd IF AMP, demodulator and The RX signal from the antenna is passed through the LPF other circuits.
- Page 42 RX AF CIRCUIT (MAIN AND FRONT UNITS) 4-2 TRANSMIT CIRCUITS The AF signal from the demodulator circuit is applied to the TX AF CIRCUIT (MAIN AND FRONT UNITS) baseband IC (MAIN UNIT: IC4, pin 23). The AF signal from the internal or external microphone (MIC signal) is passed through the MIC SW (FRONT UNIT: The applied AF signal is amplified and adjusted in level, Q708), and applied to the MIC AMP (FRONT UNIT: IC705,...
- Page 43 MODULATION CIRCUIT (MAIN UNIT) 4-3 FREQUENCY SYNTHESIZER CIRCUITS The MIC signal from the TX AF circuit is amplified by the (MAIN UNIT) AMP (IC3), and then applied to the D/A converter (IC9, • VCO pin 4) to be adjusted in level. The transceiver has 3 VCOs;...
- Page 44 4-5 PORT ALLOCATIONS Ball Port Description Name • CPU (MAIN UNIT: IC35) Serial data to the PLL IC (IC14) and D/A Ball Port Description converter (IC9). Name DAST Strobe signal to the D/A converter (IC9). Bandwidth switches (Q27–Q29, D8, D16) Outputs mode (Digital/Analog) switching NWC1 control.
- Page 45 SECTION 5. ADJUSTMENT PROCEDURE 5-1 PREPARATION ▄ REQUIRED TEST EQUIPMENTS EQUIPMENT GRADE AND RANGE EQUIPMENT GRADE AND RANGE CS-F3160/5060 ADJ Modifi ed OPC-1862 CLONING CABLE Adjustment software JIG cable CS-F3160/5060 ADJ (dPMR) (for [DPM-01]) (See the illustration on page 5-2) Frequency range : DC–300 MHz Power attenuation...
- Page 46 ¤ JIG CABLE OPC-1862 SPEAKER (1 W/8 Ω) AC MILLIVOLTMETER AUDIO GENERATOR (10 mV to 10 V) (300–3000 Hz/1–500 mV) − + − + − Add a jumper wire here 4.7 µF ¤ ADJUSTMENT CHANNELS CONVENIENT: The same cloning file is available. Right-click below, and select "Save Embeded File to Disk."...
- Page 47 FREQUENCY ADJUSTMENTS 1) Select an adjustment item using [↑]/[↓] on the PC's keyboard. 2) Set or modify the adjustment value as specifi ed using [←]/[→] on the PC's keyboard, and then push [ENTER]. TRANSCEIVER’S ADJUSTMENT ADJUSTMENT OPERATION VALUE CONDITION ITEM PLL LOCK 1) Connect an RF power meter to the an- [LV (RX 1)]...
- Page 48 TRANSMIT ADJUSTMENTS 1) Select an adjustment item using [↑]/[↓] on the PC's keyboard. 2) Set or modify the adjustment value as specifi ed using [←]/[→] on the PC's keyboard, and then push [ENTER]. ADJUST- TRANSCEIVER’S ADJUSTMENT OPERATION MENT VALUE CONDITION ITEM TX OUTPUT 1 •...
- Page 49 RECEIVE ADJUSTMENTS 1) Select an adjustment item using [↑]/[↓] on the PC's keyboard. 2) Set or modify the adjustment value as specifi ed using [←]/[→] on the PC's keyboard, and then push [ENTER]. TRANSCEIVER’S ADJUSTMENT ADJUSTMENT OPERATION VALUE CONDITION ITEM RX SENSITIVITY 1 NOTE: When "RX SENSITIVITY"...
- Page 50 SECTION 6. PARTS LIST [VERSION LIST] [MAIN UNIT] PARTS DESCRIPTION MODEL VERSION SYMBOL LOCATION 1110005310 S.IC AN6123MS 29.3/13.3 F3261DT USA-01 1180003670 S.REG BD9141MUV-E2 4.8/10.8 1110005340 S.IC NJM12902V-TE1-#ZZZB 39.5/12.5 F3261DT USA-03 1110008030 S.IC AK2346BP-E2 40.0/29.0 1110003800 S.IC NJM2904V-TE1-#FMZB 40.1/8.3 F3261DT USA-04 1140013200 S.IC CD4053BPWR 42.0/27.6...
- Page 51 [MAIN UNIT] [MAIN UNIT] PARTS PARTS DESCRIPTION DESCRIPTION LOCATION LOCATION 1160000060 S.DIO DAN202U T106 94.9/11.6 7030005530 S.RES ERJ2GEJ 100 X (10) 28.2/10.9 Eqv. 1750000271 S.DIO 1SS301(TE85LF) 7030005310 S.RES ERJ2GEJ 124 X (120K) 39.5/17.8 Eqv. 1750002340 S.DIO LDAN202UT1G <SLVJ> 7030008300 S.RES ERJ2GEJ 184 X (180K) 35.9/14.4 Eqv.
- Page 52 [MAIN UNIT] [MAIN UNIT] PARTS PARTS DESCRIPTION DESCRIPTION LOCATION LOCATION R116 7030005720 S.RES ERJ2GEJ 563 X (56K) 22.2/19.3 R233 7030009320 S.RES ERJ2GEJ 4R7 X (4.7) 82.3/16.2 R118 7030005090 S.RES ERJ2GEJ 104 X (100K) 27.9/25.0 R234 7030005090 S.RES ERJ2GEJ 104 X (100K) 83.1/14.9 R119 7030005700 S.RES ERJ2GEJ 274 X (270K)
- Page 53 [MAIN UNIT] [MAIN UNIT] PARTS PARTS DESCRIPTION DESCRIPTION LOCATION LOCATION R359 7030005090 S.RES ERJ2GEJ 104 X (100K) 58.1/9.8 4550000460 S.TAN TEESVA 1C 105M8R 36.0/26.5 R360 7030007340 S.RES ERJ2GEJ 153 X (15K) 13.9/20.9 Eqv. 4550007670 S.TAN F931C105MAABMA R361 7030007340 S.RES ERJ2GEJ 153 X (15K) 48.7/32.3 4030017660 S.CER C1005 CH 1H 330J-T 38.2/24.0...
- Page 54 [MAIN UNIT] [MAIN UNIT] PARTS PARTS DESCRIPTION DESCRIPTION LOCATION LOCATION C125 4030017460 S.CER C1005 JB 1H 102K-T 96.6/5.1 C245 4030017660 S.CER C1005 CH 1H 330J-T 72.8/18.9 C126 4030017460 S.CER C1005 JB 1H 102K-T 92.8/10.6 C246 4030017660 S.CER C1005 CH 1H 330J-T 77.3/7.3 C127 4030016930 S.CER C1005 JB 1A 104K-T...
- Page 55 [MAIN UNIT] [MAIN UNIT] PARTS PARTS DESCRIPTION DESCRIPTION LOCATION LOCATION C365 4030016930 S.CER C1005 JB 1A 104K-T 27.9/8.6 C502 4030017460 S.CER C1005 JB 1H 102K-T [C] T 101.6/20.3 C366 4030020000 S.CER C1005 JB 1A 105K-T 10.6/5.8 4030017460 S.CER C1005 JB 1H 102K-T C367 4030016940 S.CER C1005 JB 1A 393K-T 26.4/10.6...
- Page 56 [RF UNIT] [RF UNIT] PARTS PARTS DESCRIPTION DESCRIPTION LOCATION LOCATION IC601 1110002751 S.IC TA75S01F(TE85RF) 23.7/23.3 C641 4030017530 S.CER C1005 CH 1H 0R5B-T 30.2/24.0 C642 4030017460 S.CER C1005 JB 1H 102K-T 26.9/20.7 C643 4030016790 S.CER C1005 JB 1E 103K-T 23.5/20.2 Q601 1530002881 S.TRA 2SC4226-T1 Y24 (R24) 6.1/18.9...
- Page 57 [FRONT UNIT] [FRONT UNIT] PARTS PARTS DESCRIPTION DESCRIPTION LOCATION LOCATION IC701 1140013640 S.IC R5F211A1SP [C] B 34.1/14.7 R723 7030009280 S.RES ERJ2GEJ 391 X [A] B 65.1/16.8 1140013640 S.IC R5F211A1SP 7030009280 S.RES ERJ2GEJ 391 X 1140013640 S.IC R5F211A1SP 7030009280 S.RES ERJ2GEJ 391 X 1140013640 S.IC R5F211A1SP 7030009280 S.RES ERJ2GEJ 391 X...
- Page 58 [FRONT UNIT] [FRONT UNIT] PARTS PARTS DESCRIPTION DESCRIPTION LOCATION LOCATION R769 7030005120 S.RES ERJ2GEJ 102 X (1K) 68.9/4.8 C741 4030016930 S.CER C1005 JB 1A 104K-T 93.3/32.3 R770 7520000270 S.POS PRG21BC4R7MM1RA 105.4/20.2 C742 4030006860 S.CER C1608 JB 1H 102K-T [A] B 26.3/16.9 R771 7030005230 S.RES ERJ2GEJ 334 X (330K)
- Page 59 [FRONT UNIT] [FRONT UNIT] PARTS PARTS DESCRIPTION DESCRIPTION LOCATION LOCATION C775 4030016930 S.CER C1005 JB 1A 104K-T [C] B 21.3/15.1 EP702 6910013370 S.BEA BLM18BB221SN1D 4030016930 S.CER C1005 JB 1A 104K-T (BLM11B221SB) [C] B 28.9/20.7 4030016930 S.CER C1005 JB 1A 104K-T 6910013370 S.BEA BLM18BB221SN1D 4030016930 S.CER C1005 JB 1A 104K-T...
- Page 60 [VR-A UNIT] [JACK UNIT] PARTS PARTS DESCRIPTION DESCRIPTION LOCATION LOCATION R502 7210003390 VAR F081165S-5 A10K L15FCX7 D803 1790001810 S.VAR AVR-M1005C080MTABB 11.8/8.1 <SLVJ> D804 1790001810 S.VAR AVR-M1005C080MTABB 10.8/8.1 D805 1790001810 S.VAR AVR-M1005C080MTABB 7.6/8.1 D806 1790001810 S.VAR AVR-M1005C080MTABB 8.7/8.1 J501 6510027900 S.CON IMSA-9631S-10Y933 7.2/2.9 J801 6510028740 S.CON 14FLH-SM1-TB(LF)(SN)
- Page 61 SECTION 7. MECHANICAL PARTS [VERSION LIST] [CHASSIS PARTS] ORDER MODEL VERSION SYMBOL DESCRIPTION QTY. 6910021491 ANT CONNECTOR 106-1 <SSC> F3261DT USA-01 6910015860 IMSA-6277S-02A-G F3261DT USA-03 2510001670 040D01201 F3261DT USA-04 8900016360 OPC-1190A 8900021220 OPC-2264 (P0.5N14L80) F3262DT EUR-01 8900014750 OPC-519A (P0.5N30L55) F3262DT DPM-01 8900021240 OPC-2283 (P0.5N10L31) 8900021240 OPC-2283 (P0.5N10L31)
- Page 62 [CHASSIS UNIT] [MAIN UNIT] ORDER ORDER DESCRIPTION QTY. DESCRIPTION QTY. MP12 8930085090 3401 KEYBOARD <SEP> 6510028350 20P10.0-JMCS-G-B-TF (N) 8930085090 3401 KEYBOARD <SEP> 6510027900 IMSA-9631S-10Y933 6510027900 IMSA-9631S-10Y933 8930085090 3401 KEYBOARD <SEP> 8930085090 3401 KEYBOARD <SEP> 6510027900 IMSA-9631S-10Y933 8930085090 3401 KEYBOARD <SEP> 6510027900 IMSA-9631S-10Y933 8930085090 3401 KEYBOARD <SEP>...
- Page 63 [FRONT UNIT] [ACCESSORIES] ORDER ORDER DESCRIPTION QTY. DESCRIPTION QTY. J701* 6510022711 30FLZ-SM2-TB (LF) (SN) (Optional) FA-SC55V-2 J702* 6510027940 IMSA-9631S-08Y933 (Optional) FA-SC55V-2 J704* 6510027930 IMSA-9631S-14Y933 (Optional) FA-SC55V-2 (Optional) FA-SC55V-2 DS711 5030003140 M7-0626TIZ <TES> (Optional) FA-SC55V-2 (Optional) FA-SC55V-2 MC701 7700002760 EM6027P-46C33-G-01 <HOR> (Optional) FA-SC55V-2 (Optional)
- Page 64 W1(C) MP10(C) MP8(C) MP802(J) EP1(C) MP46(C) SP1( C) W1( C) MP45(C) MP22(C) MP31(C) MP47(C) J1(C) MP32(C) EP1(C) (Viewing from the bottom) MP26(C) MP45(C) JACK UNIT MP47(C) MP3(C) MP7(C) MP15(C) MP28(C) MP36(C) MP30(C) MP29(C) MP1(C) MP16(C) MP44(C) MP37(C) MP23(C) MP42(C) VR-A UNIT MP21(C) MP12*(C) MP24(C)
- Page 65 The combination of top side and bottom side of this SECTION 8 BOARD LAYOUTS • FRONT UNIT (TOP VIEW) J702 MC701 DS702 J704 C764 INSP- INSP+ C765 EMIC EPTT DS701 C769 C771 MDET C772 DS710...
- Page 66 The combination of top side and bottom side of this MC701 • FRONT UNIT (BOTTOM VIEW) MP710 R713 R750 C728 S717 IC702 MP707 R778 IC709 R779 Q709 J701 J701 C726 C746 R737 D705 C724 C722 REST MCIN C714 C716 C737 R733 AFON D704...
- Page 67 The combination of top side and bottom side of this • MAIN UNIT (TOP VIEW) [Side3] [Side2] [Side1] [PTT] C176 DISC R170 R341 CPU5V C150 R150 R143 R145 C138 R115 R378 R405 R113 R377 C429 C442 R114 IC13 C143 R384 R186 PWRSW AFVI...
- Page 68 The combination of top side and bottom side of this • MAIN UNIT (BOTTOM VIEW) R155 C155 C243 R172 R232 C446 R162 R164 R415 R228 R409 R355 C157 C268 C495 C445 R416 C154 C266 C221 C222 R410 C287 R196 R182 C180 C496 C263...
- Page 69 The combination of top side and bottom side of this • JACK UNIT (TOP VIEW) • RF UNIT (TOP VIEW) EP801 EP802 D601 EP604 B7668B EP803 J801 J801 F601 C638 EP804 D602 R614 J802 C680 C644 C612 R612 IC601 R632 C665 J802 C632...
- Page 70 The combination of top side and bottom side of this • JACK UNIT (BOTTOM VIEW) • RF UNIT (BOTTOM VIEW) MP801 C661 C662 C641 C613 C625 C631 C626 R613 C673 C608 C645 R608 C611 C616 L607 L609 C615 C672 C674 C668 R631 R630...
- Page 71 SECTION 9. GENERAL WIRING CHASSIS CHASSIS OPC-2283 1112 FRONT UNIT RF UNIT CHASSIS EMER OPC-519A EMER J702 CIRQM CIRQM DS711 CHASSIS OPT3 OPT3 OPV3 EMPH LRES TLED TLED ANTENNA FSDA RLED RLED FSCL MDET MDET 1920 1920 1718 1718 LCDV 1516 1516 1314...
- Page 72 SECTION 10. BLOCK DIAGRAM D604/D608 350-400MHz 400-470MHz RF UNIT RIPPLE Q30,D10 450-520MHz D19,D20,D39 Q601 Q602 Q603 D605-D607/D609 LVIN from Battery BUFF TX/RX BUFF BUFF DRIVE DRIVE IC14 Q31,D11 CPU5 15.3MHz LOOP TCXO D603 BATV IC601 Q14,Q15 Q16,Q17 OUT1 RLVA Explanatory notes Q35/Q36 OUT0 Q32,D9...
- Page 73 SECTION 11. VOLTAGE DIAGRAM CPU5V CPU5V • MAIN UNIT (1/4) 100k NJM12902V DMG504010 IC12 CDEC DASW DASW 4.7k SDEC2 RSSI RSSI 100k SDEC VIN1 VIN8 VOUT1 VOUT8 NJM12902V 120k TONEA VOUT2 VOUT7 180k NJM2904V VIN2 VIN7 RESET MICA VDAREF CENC0 100k VIN3 VIN6...
- Page 74 • MAIN UNIT (2/4) 5.00V VCO5V 4.09V 2SC4116 ACZ1005Y NJM2904V TEMP C226 C241 1.2U 15.3MHz 2SC4226 730mVp-p C257 4.86V R138 HVC350B 0.5P 100k 2SK880 R129 R141 R130 VCON 1.2U 3401 680k NJM2904V TX 2.00V 15.3MHZ C493 R179 0.001 R165 C228 C242 C318 TXRF...
- Page 75 • MAIN UNIT (3/4) R272 R274 NFM18PC104R1C3 C334 NFM18PC104R1C3 C500 MMZ1005S601CT AGND EMU1 EP15 TRST MMZ1005S601CT EP14 DVDD_3.3V MMZ1005S601CT EP13 EMU0 MMZ1005S601CT EP12 MMZ1005S601CT CP116 DRESET NFM18PC104R1C3 C335 +3.3V_A BDX0 EMU0 EMU1 CP06S BFSR0 DRESET CP115 BFSX0 CP111 CP06S CP112 CP06S R279 CP113...
- Page 76 • MAIN UNIT (4/4) +3.3V CPU5V BLM18RK102SN1 EP10 1.35V IC32 VLCF4028T CPU5V 2.2U TPS62200DBVR DASW DASW RSSI RSSI POSW R384 100k SIDE3 R385 100k SIDE2 R386 100k MTCK R387 100k CPU5V MMUT R388 100k R406 ESCL R389 100k TMUT ESDA DASW R392 100k...
- Page 77 TX 5.00V • RF UNIT R601 • VR-A UNIT NFM60R20T152 FI601 J501 S501 CBI0 CBI1 CBI2 CBI3 TX 0.10V TP70TF5164S R502 MP501 PWRSW OG-603060 C604 J601 AFVI C605 C618 L607 L608 L609 C647 D605 C651 L612 L613 L614 TMUT RXRF 0.5P F081165S 2.8N...
- Page 78 Highway 17 Delta, B.C., V4K 5B8, Canada : http://www.icomspain.com Phone : +1 (604) 952-4266 Fax : +1 (604) 952-0090 E-mail : icom@icomspain.com : http://www.icomcanada.com E-mail : info@icomcanada.com Blacksole House, Altira Park, Herne Bay, Kent CT6 6GZ, UK Phone : +44 (0) 1227 741741...
- Page 79 S-14910XZ-C1 1-1-32, Kamiminami, Hirano-ku, Osaka 547-0003, Japan © 2012 Icom Inc.
