This User Manual does not address the end user� It is intended as a source of information for the equipment or system manufacturer only, and it will tell you how to install, use and maintain your LINAK electronics� The manufacturer of the end product has the responsibility to provide a User Manual, where relevant safety information from this manual is passed on to the end user�...
Page 5
LINAK, LINAK subsidiaries, or LINAK affiliates� All sales are subject to the ‘Standard Terms of Sale and Delivery for LINAK A/S’ available on LINAK websites� LINAK and the LINAK logotype are registered trademarks of LINAK A/S� All rights reserved�...
Page 6
LA14IO User Manual | Safety Instructions Please read this safety information carefully� Be aware of the following three symbols throughout the user manual: Warning! Failing to follow these instructions can cause accidents resulting in serious personal injury� Recommendations Failing to follow these instructions can result in the actuator suffering damage or being ruined�...
Page 7
Prevent impact, blows, and any other form of stress to the housing� • Ensure that the cable cover is mounted correctly� Use 1�5 Nm torque� Ensure that the duty cycle and the usage temperatures for LA14IO actuators are respected� • •...
Page 8
• The production of IECEx/ATEX actuators require quality management systems and auditing� Therefore, only LINAK A/S is allowed to produce, modify, or repair actuators in order to sustain the approval� This manual is part of the equipment� The manufacturer keeps the right to modify specifications without advanced notice�...
Page 9
• Safety devices are installed, and recommended maintenance is performed� • National regulations for disposal of electrical equipment are obeyed� Maintenance and repair: • Repairs on the device must be carried out by persons authorised by LINAK only� ® • Only perform mounting described in this manual�...
Page 10
Please pay special attention to the area around the housing, where parts can be trapped and cause damage to the application and actuator� In applications with high dynamic forces, LINAK recommends not using the fully extended or retracted position over a longer period of time, as this can damage the endstop system permanently�...
Page 11
LA14IO User Manual | 11 Mounting Guidelines • The mounting pins must have the correct dimension� • The bolts and nuts must be made of a high quality steel grade (e�g� 10�8)� • No thread on the bolt inside the back fixture or the piston rod eye�...
Page 12
4� Screw the cover back onto the actuator� The torque 5� Use a screwdriver to pull up the cable of the cover screw is approximately 1�5 Nm • When changing the cables on a LINAK actuator, it is important that this is done carefully, in order ®...
Page 13
LA14IO User Manual | 13 Electrical Installation • To ensure maximum self-locking ability, please make sure that the motor is shorted when stopped� Actuators with an Integrated Controller provide this feature, so long as the actuator is powered� • When using soft stop on a DC-motor, a short peak of higher voltage will be sent back towards the power supply�...
Page 14
LA14IO User Manual | 14 Current Limits Platform Movement 12 V 24 V 48 V Temperature Outwards Above Inwards B, C, F Reference temperature 0°C Outwards 16 A 10 A Below Inwards 16 A 10 A If the actuator's current consumption rises above the set limit, the actuator regulates and tries to keep it below the set current limit by reducing the PWM and therefore also the speed accordingly�...
Page 15
LA14IO User Manual | 15 Without Feedback Connection diagram Platform 0 Deutsch BROWN BLUE I/O specifications Input/Output Specification Comments Description Permanent magnetic DC motor� 12 or 24 V DC (+/-) To extend actuator: Brown Connect Brown to positive 12 V ± 20% Connect Blue to negative 24 V ±...
Page 16
LA14IO User Manual | 16 Endstop Reached Connection diagram Platform 0 Deutsch BROWN BLUE Supply for feedback + RED Digital output YELLOW Digital output GREEN Supply for feedback - BLACK If you wish to use Endstop reached, you will have to keep power on the Brown, Blue, Red and...
Page 17
LA14IO User Manual | 17 Endstop Reached I/O specifications Input/Output Specification Comments The actuator can be equipped with electronically Description controlled Endstop reached out� 12 or 24 V DC (+/-) To extend actuator: Brown Connect Brown to positive 12 V ± 20% Connect Blue to negative 24 V ±...
Page 18
LA14IO User Manual | 18 Relative Positioning - Single Hall Connection diagram Platform 0 Deutsch BROWN BLUE Supply for feedback + RED Single Hall Digital output VIOLET Supply for feedback - BLACK...
Page 19
LA14IO User Manual | 19 Relative Positioning - Single Hall I/O specifications Input/Output Specification Comments Single Hall The actuator can be equipped with Single Hall that Description gives a relative positioning feedback signal when the actuator moves� 12 or 24 V DC (+/-)
Page 20
LA14IO User Manual | 20 Relative Positioning - Single Hall and Endstop Reached Connection diagram Platform 0 Deutsch BROWN BLUE Supply for feedback + RED Single Hall Digital output VIOLET Digital output YELLOW Digital output GREEN Supply for feedback - BLACK If you wish to use Endstop reached, you will have to keep power on the Brown, Blue, Red and Black wires, otherwise the signal will be lost�...
Page 21
LA14IO User Manual | 21 Relative Positioning - Single Hall and Endstop Reached I/O specifications Input/Output Specification Comments Single Hall The actuator can be equipped with Single Hall that gives a relative positioning feedback signal when the Description actuator moves�...
Page 22
LA14IO User Manual | 22 Absolute Positioning - Analogue Feedback Connection diagram Platform 0 Deutsch BROWN BLUE Supply for feedback + RED Analogue output VIOLET Supply for feedback - BLACK The signal power must be turned on at all times when the actuator is running, and minimum one...
Page 23
LA14IO User Manual | 23 Absolute Positioning - Analogue Feedback I/O specifications Input/Output Specification Comments The actuator can be equipped with an electronic circuit that gives an analogue feedback signal Description when the actuator moves� 12 or 24 V DC (+/-)
Page 24
LA14IO User Manual | 24 Absolute Positioning - Analogue Feedback and Endstop Reached Connection diagram Platform 0 Deutsch BROWN BLUE Supply for feedback + RED Analogue output VIOLET Digital output YELLOW Digital output GREEN Supply for feedback - BLACK If you wish to use the endstop signals, you will have to keep power on the Brown, Blue, Red and Black wires, otherwise the signal will be lost�...
Page 25
LA14IO User Manual | 25 Absolute Positioning - Analogue Feedback and Endstop Reached I/O specifications Input/Output Specification Comments The actuator can be equipped with an electronic Description circuit that gives an analogue feedback signal when the actuator moves� 12 or 24 V DC (+/-)
Page 26
LA14IO User Manual | 26 Absolute Positioning - PWM Connection diagram Platform 0 Deutsch BROWN BLUE Supply for feedback + RED Digital feedback VIOLET 50% 50% Supply for feedback - BLACK The signal power must be turned on at all times when the actuator is running, and minimum...
Page 27
LA14IO User Manual | 27 Absolute Positioning - PWM I/O specifications Input/Output Specification Comments The actuator can be equipped with an electronic 50% 50% Description circuit that gives a digital feedback signal when the actuator moves� 12 or 24 V DC (+/-)
Page 28
LA14IO User Manual | 28 Absolute Positioning - PWM and Endstop Reached Connection diagram Platform 0 Deutsch BROWN BLUE Supply for feedback + RED Digital feedback VIOLET 50% 50% Digital output YELLOW Digital output GREEN Supply for feedback - BLACK If you wish to use the endstop signals, you will have to keep power on the Brown, Blue, Red and Black wires, otherwise the signal will be lost�...
Page 29
LA14IO User Manual | 29 Absolute Positioning - PWM and Endstop Reached I/O specifications Input/Output Specification Comments The actuator can be equipped with an electronic 50% 50% Description circuit that gives a digital feedback signal when the actuator moves� 12 or 24 V DC (+/-)
Page 30
LA14IO User Manual | 30 Absolute Positioning - Mechanical Potentiometer Connection diagram Platform 0 BROWN BLUE Supply for feedback + RED +10 V or other value VIOLET Analogue feedback Supply for feedback - BLACK...
Page 31
LA14IO User Manual | 31 Absolute Positioning - Mechanical Potentiometer I/O specifications Input/Output Specification Comments The actuator can be equipped with a mechanical potentiometer, 10 k ohm, providing an analogue feedback signal when the actuator moves� Description Bourns 0-10 kohm, 5%,...
Page 32
LA14IO User Manual | 32 IC Basic Connection diagram Platform 3 Deutsch 12/24 V DC + BROWN GND - BLUE Digital input Digital input BLACK Digital output YELLOW Digital output GREEN Please be aware that if the power supply is not properly connected, you might damage the actuator!
Page 33
LA14IO User Manual | 33 IC Basic I/O specifications Input/Output Specification Comments Easy-to-use interface with integrated power electronics (H-bridge)� Description The version with “IC option” cannot be operated with a PWM power supply� Connect Brown to positive 12-24 V DC + (VCC) Typical values at max�...
