- Page 1 A233 Horn Speaker Quick Installation Guide...
- Page 2 � Package Contents Screw and tool A233 horn speaker A��� Horn Speaker Quick Installation Quick Installation Guide Guide � Physical specification Size Description 285mm *285mm*205mm 1) Horn Speaker 3*Φ10 50 50 Φ10 U-shaped bracket Wiring harness...
- Page 3 2) Wiring harness ③ ① ④ ② Serial Wiring port description Description number Ethernet interface: standard RJ�� interface, ��/���M adaptive, support PoE powered, it is recommended to use CAT� or CAT�E ① network cable. Power interface: DC ��V/�A input. ② �...
- Page 4 Fanvil Technology Co., Ltd Website: www.fanvil.com EMail: sales@fanvil.com support@fanvil.com Tel: +86-755-2640-2199 Fax: +86-755-2640-2618 Add: 10/F Block A, Dualshine Global Science Innovation Center, Honglang North 2nd Road, Bao'an District, Shenzhen, China...
- Page 5 � Installation Diagram Installation of U-shaped bracket 1) U-shaped bracket installation A. Drill three mounting holes suitable for M10 expansion bolts on the wall first, and the distance between the holes is 50mm. Then install the M10 expansion bolts. 50 50 B.
- Page 6 � Searching IP address The default WAN mode is DHCP, Querying the IP address with the Device Manager： Wall Mounted Speaker setting � Step 1: Log in the web setting page of ceiling speaker Input IP address of indoor station (e.g. http:// 172.18.26.3) into the address bar of PC’s web browser.
- Page 7 Step 2：Add the SIP account Set SIP server address, port, user name, password and SIP user with assigned SIP account parameters. Select “Activate”, and then click Apply to save this setting. A233 Step 3：Feature Setting A233...
- Page 8 Step 4：Security Settings If you need to connect other input and output devices, please set the Input and Output setting in the Security Settings： A233 A233...
