INSTALLATION INSTRUCTIONS
THRESHER GRIPS FOR VICTORY
THANK YOU FOR CHOOSING KURYAKYN!
Protect yourself and others from possible injury and property damage or loss. Pay close attention to all instructions, warnings, cautions, and notices regarding the installation, use, and care of this product.
THIS INDICATION ALERTS YOU TO THE FACT THAT IGNORING THE CONTENTS DESCRIBED HEREIN CAN RESULT IN POTENTIAL DEATH OR SERIOUS INJURY.
THIS INDICATION ALERTS YOU TO THE FACT THAT IGNORING THE CONTENTS DESCRIBED HEREIN CAN RESULT IN MINOR OR MODERATE POTENTIAL INJURY.
THIS INDICATION ALERTS YOU TO THE FACT THAT IGNORING THE CONTENTS DESCRIBED HEREIN MAY NEGATIVELY AFFECT PRODUCT PERFORMANCE AND FUNCTIONALITY OR
DAMAGE THE PRODUCT ITSELF OR THE PRODUCT TO WHICH IT IS BEING ATTACHED.
ENSURE THAT THE FOLLOWING PARTS HAVE BEEN INCLUDED IN THE KIT:
1 Throttle Side Grip
1 Clutch Side Grip
1 Tube of Adhesive
YOU WILL ALSO NEED:
Phillips Screwdriver, Sharp Utility Knife, Sandpaper or Emery Cloth, Needle Nose Pliers, Safety Glasses, Clean Rag, Tape Measure
THESE INSTALLATION INSTRUCTIONS CONTAIN IMPORTANT INFORMATION. ENSURE THE END USER RECEIVES THIS COPY AND IS AWARE
OF ITS IMPORTANCE FOR FUTURE USE.
STEP 1
Read and understand all steps in the instructions before starting the
installation. Park the motorcycle on a hard, level surface and turn off
the ignition. Let motorcycle cool.
A FACTORY SERVICE MANUAL WILL BE HELPFUL IN PERFORMING THIS
INSTALLATION. DO NOT ATTEMPT TO PERFORM THIS INSTALLATION
IF YOU ARE NOT CONFIDENT IN YOUR ABILITY TO COMPLETE ALL OF
THE STEPS IN THE PROCEDURE; CONSULT A TRAINED TECHNICIAN.
IMPROPER INSTALLATION COULD RESULT IN SERIOUS INJURY
OR DEATH.
INSTALLATION OF THROTTLE SIDE
STEP 2
Remove the fasteners (usually two Phillips screws) that hold the two
halves of the handlebar switch housings together. Some models also
have a throttle cable retainer that must be removed. Separate the
switch housings.
STEP 3
If the bike is equipped with a cable adjusters, adjust them for maximum
cable slack (shorten the cable housing).
STEP 4
Carefully remove the cable ferrules from the throttle twist grip. Careful
use of needle nose pliers can help here — do not damage the cable.
STEP 5
Slide the new grip into place and install the throttle cables and ferrules
into the new throttle sleeve in the same manner as they removed from
the stock grip.
STEP 6
Re-assemble the switch housings. Adjust the throttle cables. Test
for free unrestricted movement in the throttle. It must operate freely,
without any restriction.
PAGE 1
305946
DPF-MRK-003 REV B 1/28/19
, KAWASAKI & YAMAHA
® ®
, CHROME
®
866 277 9598 | INFO@KURYAKYN.COM
454 COUNTY ROAD VV SOMERSET, WI 54025
5946
K U R YA K Y N . C O M
