F I T T I N G I N S T R U C T I O N S F O R
Light Cargo Barrier
S K U
KS0781
Included contents
Q T Y
C O M P O N E N T
1
Light Cargo Barrier
2
Head Rest Bracket
2
Mounting Bracket (LHS & RHS)
2
Barrier Bracket (LHS & RHS)
6
M6 x 16 Flanged Hex Bolt G8.8
For further information contact KAON on 07 3180 1470 or info@kaon.com.au
C O M P A T I B I L I T Y
Toyota LandCruiser LC76
Q T Y
C O M P O N E N T
2
M6 X 18 X 1.6 DIN Flat Washer
2
M10 x 20 Black Plastic Knob
2
M10 x 30 x 2.5 DIN Flat Washer
2
M10 x 20 Button Head Socket Screw
Time
30 minutes / Half a beer
Advertisement
Related Manuals for Kaon KS0781
Summary of Contents for Kaon KS0781
- Page 1 M10 x 30 x 2.5 DIN Flat Washer Barrier Bracket (LHS & RHS) M10 x 20 Button Head Socket Screw M6 x 16 Flanged Hex Bolt G8.8 Time 30 minutes / Half a beer For further information contact KAON on 07 3180 1470 or info@kaon.com.au...
- Page 2 Complete any additional accessories the Shelf & Molle install. to the Molle as well. Are you installing other Are you installing other KAON Storage Products? KAON Storage Products? Complete the Molle Panel That’s it, you’re done! as per it’s instructions.
- Page 3 Light Cargo Barrier fitting guide. Are you installing other KAON Storage Products? With the foundation in place, it’s time to mount any other accessories, such as a Cargo Divider, Travel Buddy, etc. Have That’s it, you’re done!
-
Page 4: Preparing The Vehicle
This barrier has not been tested to Australian Standards, N O T I C E and is intended as a pet barrier or for use when off-road. Let’s get to work. Preparing the Vehicle Our mounting brackets affix to two points, the first of which is under the plastic cap, above the third window, just behind the C pillar. -
Page 5: Bracket Installation
Bracket Installation If you’re installing the Light Cargo Barrier on it’s own: Following on from step 3, slip an M6 bolt through the hole made in the lining and tighten to hold the bracket in place. Repeat on the other side. If you’re installing with Side Molle Panels: this rear interior storage product will need to be installed... - Page 6 Assembling the Barrier Attach the barrier brackets to the barrier using the supplied M6 bolts and washers.
- Page 7 Installing the Barrier Remove the head rests and slide on the head rest brackets. Re-install the head rests with brackets in place. Position the main barrier against the head rests. The flanged edge on the barrier should be directed forwards, and the warning stickers should be visible from the rear of the vehicle.
- Page 8 For further information call 07 3180 1470 or email info@kaon.com.au Disclaimer: The products sold by KAON should not be modified, and are for use only on the vehicles specifically stated. KAON will not be liable for any damages arising out of the use or misuse of it’s products. It is the customers responsibility to ensure the products are safely...
