DECK OVENS
OV401N
OV400N
OV401W
OV400W
Model Number:
Serial Number:
Date of Installation:
Baxter Mfg, a Division of ITW FEG, LLC • 19220 State Route 162 East • Orting, WA 98360-9236
Operator & Installation
___________
___________
___________
Phone: (360) 893-5554 • Fax: (360) 893-1337
www.baxterbakery.com
Manual
FORM 36718 (July 2010)
Advertisement
Related Manuals for baxter OV401N
Summary of Contents for baxter OV401N
- Page 1 Model Number: ___________ Serial Number: ___________ Date of Installation: ___________ Baxter Mfg, a Division of ITW FEG, LLC • 19220 State Route 162 East • Orting, WA 98360-9236 Phone: (360) 893-5554 • Fax: (360) 893-1337 FORM 36718 (July 2010) www.baxterbakery.com...
- Page 2 Door Opening and Closing ......................8 CLEANING ............................9 Daily Cleaning ..........................9 Weekly Cleaning ..........................10 MAINTENANCE ..........................13 Baking Chamber Lamp Replacement .................... 13 Steam Generator ........................... 13 Service and Parts Information ....................... 13 TROUBLESHOOTING ........................14 – 2 – ©BAXTER MFG, 2010...
- Page 3 INSTALLATION, OPERATION AND CARE OF OV400 & OV401 SERIES DECK OVENS SAVE THESE INSTRUCTIONS GENERAL The OV400 & OV401 Series Deck Ovens (Fig. 1) are designed and suited for your baking needs. The deck ovens are available in four sizes, with up to four individual decks. They are produced with quality workmanship and material.
- Page 4 INSTALLATION The OV400 & OV401 Series Deck Ovens require some assembly and must be installed by authorized Bakery Systems trained service technicians. UNPACKING This oven was inspected before leaving the factory. The transportation company assumes full responsibility for safe delivery upon acceptance of the shipment. Immediately after unpacking, check for possible shipping damage.
- Page 5 Disconnect the electrical power to the unit and follow lockout / tagout procedures. ELECTRICAL DATA (Per Deck) Model Voltage Total Heater kW Line L1 Line L2 Line L3 OV401N 208-240 4.1 - 5.5 11.6 - 13.4 10.9 - 12.6 11.6 - 13.4 OV400N 208-240 5.6 - 7.4 14.7 - 17.0...
- Page 6 BEFORE FIRST USE Before using the oven for the fi rst time, when new stones are installed, or if the stones have been cleaned with water, the baking stones need to be slowly "baked in" prior to start-up. Use the following chart as a guide for the fi...
- Page 7 3 1/2" O.D. "E" 1 3/4" 2 1/2" 7 7/8" "D" 14" Stand Height 40" For 1 or 2 Decks 31" For 3 Decks 18" For 4 Decks Model OV401N " " " " OV400N " " " " " "...
- Page 8 OPERATION The oven and its parts are hot. Use care when operating, cleaning or servicing the oven. The baking compartment contains live steam. Stay clear when opening door. DOOR OPENING AND CLOSING To open the door (Fig. 2), pull down on the door handle slightly to allow steam to escape.
- Page 9 CLEANING Disconnect the electrical power to the machine and follow lockout / tagout procedures. The oven and its parts are hot. Use care when operating, servicing or cleaning the oven. DAILY CLEANING • Always allow the oven to cool before cleaning. Never attempt to cool the oven down with cold water.
- Page 10 WEEKLY CLEANING GLASS PANEL Baking Chamber Glass (OV400N & OV401N Only) Allow the glass to cool before cleaning. Cleaning while hot may cause the glass to shatter. NOTE: Make sure the glass does not fall when removing the attaching hardware. Do not use any scouring or sharp objects to clean the glass.
- Page 11 Split Glass (OV400W & OV401W Only) Allow the glass to cool before cleaning. Cleaning while hot may cause the glass to shatter. 1. With the door glass in the closed position, slide handle (Fig. 5) down off of pawl and open left door glass.
- Page 12 5. Pull back on detent and twist 90 degrees to insert pin into door lever (Fig. 8). 6. Slide handle back to release pawl and close left door glass (Fig. 8). Fig. 8 7. Clean inside of left door glass (Fig. 9). Fig.
- Page 13 MAINTENANCE Disconnect the electrical power to the machine and follow lockout / tagout procedures. BAKING CHAMBER LAMP REPLACEMENT NOTE: Do not touch the replacement bulb with your fi ngers. Touching the replacement bulb will shorten bulb life. Wear gloves when replacing halogen lamps. 1.
- Page 14 TROUBLESHOOTING PROBLEM POSSIBLE CAUSE CORRECTIVE ACTION Water is in the 1. Too much steam (time/quantity) 1. Check procedures. baking chamber 2. Drain hose obstructed 2. Check drain connection. 3. Solenoid valve defective 3. Contact your authorized service offi ce. 4. Flow regulator defective 4.
- Page 15 NOTES – 15 –...
- Page 16 NOTES – 16 – FORM 36718 (July 2010) PRINTED IN U.S.A.
