IMPORTANT: DO NOT DISCARD THIS MANUAL
This manual is considered to be part of the appliance and is to be given to the OWNER or
MANAGER of the restaurant, or to the person responsible for TRAINING OPERATORS of
this appliance. Additional manuals are available from your WELLS DEALER.
THIS MANUAL MUST BE READ AND UNDERSTOOD BY ALL PERSONS USING OR
INSTALLING THIS APPLIANCE. Contact your WELLS DEALER if you have any
questions concerning installation, operation or maintenance of this equipment.
307588
2M-
Rev. H
WELLS MANUFACTURING
265 Hobson Street, Smithville, Tennessee 37166
telephone: 314-678-6314
www.wells-mfg.com
Model F55
OWNER'S MANUAL
STANDARD
FRYERS
COUNTERTOP
MODELS
F14
F49
F55
F67
F85 F1725
Includes
INSTALLATION USE
& CARE
EXPLODED VIEW
PARTS LIST
WIRING DIAGRAM
301
03/18
