PRECAUTIONS AND GENERAL INFORMATION WARNING: This manual is considered to be Wells Bloomfield, LLC proprietary information. Dissemination of this information to anyone other than RISK OF Wells Bloomfield authorized service agents is strictly prohibited. PERSONAL INJURY Installation procedures must Technical content of this manual, including any wiring diagrams,...
Page 3
F-67, F-676 ................18 F-85, F-856 ................22 INTRODUCTION This manual contains information needed to properly service and repair Wells standard fryers. This manual applies to the following Wells Bloomfield models manufactured after Jan. 1, 2008: F-14 F-49 F-55, F-556...
PERIODIC CLEANING PERIODIC CLEANING CAUTION: BURN HAZARD Add 1/2 cup of granulated dishwasher detergent to frypot. Fill with water to the MAX OIL line. Be sure frypot and Lower the element into the frypot and set the control knob to 225ºF elements are dry before returning unit to service.
DISPOSAL OF USED OIL DANGER: BURN HAZARD Contact with hot oil will cause severe burns. Allow the fryer to cool before cleaning. Always wear protective clothing and heat resistant gloves when handling hot oil. PREPARATION CAUTION: Turn temperature control to OFF Allow fryer to cool completely before draining BURN HAZARD FREQUENCY...
Page 6
REPLACE HEATING ELEMENT (all exc. F-14) 5/8-18 NUT CAUTION: 2 places LOCK WASHER FIBER WASHER BURN HAZARD CAPILLARY CLIP 6 places Allow fryer to cool before performing this service. ELEMENT BULB CLIP CAUTION: 4 places HI-LIMIT SHOCK HAZARD Element Assembly BULB (ref) Unplug fryer from electric power before servicing.
Page 7
REPLACE CONTROL OR HI-LIMIT THERMOSTAT (all exc. F-14) REPLACE SPRING FOR FRYHEAD SUPPORT ROD HI-LIMIT CAUTION: THERMOSTAT CONTROL BURN HAZARD KNOB Allow fryer to cool before performing this service. TEMP Thermostat CONTROL CAUTION: THERMOSTAT Installation SHOCK HAZARD CAPILLARY CLIP 6 places Unplug fryer from electric BULB CLIP power before servicing.
Page 8
REPLACE SPRING FOR FRYHEAD SUPPORT ROD CAUTION: BURN HAZARD Allow fryer to cool before Support Rod performing this service. Spring Installation CAUTION: SHOCK HAZARD Unplug fryer and allow to cool before servicing. Disconnect fryer from electric A. REMOVE ELEMENT HEAD FROM FRYER power before servicing.
Page 9
F-14(LLF-14), F-49, F-55, F-67 COM1 5.75 .38 DIA COM2 BULB Æ.25” x .19” 54066 KNOB, TEMPERATURE CONTROL (WELLS) THERMOSTAT WELLS OFF (Bottom): 225ºF - 375ºF Gray Plastic Knob / SS Skirt / Black Markings Brushed Aluminum Center Insert Fryer F-14( LLF-14), F-49, F-67 2.38”...
Page 10
COUNTERTOP FRYER F-14 REPLACE ELEMENT (F-14) CAUTION: BURN HAZARD Allow fryer to cool before performing this service. CAUTION: SHOCK HAZARD Unplug fryer from electric Element Assembly power before servicing. (F-14) IMPORTANT: DO NOT damage the capillary tubes. If the tubes are pinched or kinked, they IMPORTANT: Unplug fryer and allow to cool before servicing.
Page 11
COUNTERTOP FRYER F-14 REPLACE CONTROL OR HI-LIMIT THERMOSTAT (F-14) CAUTION: BURN HAZARD Allow fryer to cool before performing this service. Thermostat Installation CAUTION: SHOCK HAZARD Unplug fryer from electric power before servicing. IMPORTANT: DO NOT damage the capillary tubes. If the tubes Unplug fryer and allow to cool before servicing.
Page 18
COUNTERTOP FRYER F-55 and BUILT-IN FRYER F-556 TERMINAL BLOCK REMOVE JUMPER WHEN EXTERNAL CONTROL USED IMPORTANT: DO NOT CONNECT ANY POWER TO FLAME SENSOR TERMINAL BLOCK TERMINAL BLOCK FLAME SENSOR CONTROL THERMOSTAT RELAY HI-LIMIT THERMO COIL HI-LIMIT THERMO WIRE NUT WIRE NUT TEMP SIGNAL...
Page 19
COUNTERTOP FRYER F-55 and BUILT-IN FRYER F-556 WIRING SCHEMATIC F-55 and F-556...
Page 20
COUNTERTOP FRYER F-67 and BUILT-IN FRYER F-676 HEAD ASSY COMPLETE F-67(6) NOTE: Unit has two identical 62915 (208V) fryer heads. Only one is shown 62916 (240V) 54066 50177 fibre washer 50176 (pk 10 ) lock washer 50133 temp control 50172 50516 amber 51157...
Page 22
COUNTERTOP FRYER F-67 and BUILT-IN FRYER F-676 TERMINAL BLOCK TERMINAL BLOCK (3 PHASE) (1 PHASE) CONTROL CONTROL THERMOSTAT THERMOSTAT RELAY RELAY HI-LIMIT HI-LIMIT HI-LIMIT HI-LIMIT THERMO THERMO THERMO THERMO COIL COIL WIRE WIRE WIRE WIRE TEMP TEMP SIGNAL SIGNAL LITE LITE LITE LITE...
Page 23
COUNTERTOP FRYER F-67 and BUILT-IN FRYER F-676 WIRING SCHEMATIC F-67 and F-676...
Page 24
COUNTERTOP FRYER F-85 and BUILT-IN FRYER F-856 HEAD ASSY COMPLETE, F-85 62903 (208V) NOTE: Unit has two identical 62904 (240V) fryer heads. Only one is shown 55511 50177 fibre washer 50176 (pk 10 ) lock washer 55510 temp control 50172 50516 amber 51157...
Page 25
COUNTERTOP FRYER F-85 and BUILT-IN FRYER F-856 F-85 CABINET 50131 61974 (pk 10) 55736 green KEPS (pk 10) 51053 (pk 100) 53068 54005 57779 (208V) 53848 57780 (240V) 20314 plastic 20563 metal (pk 4) 55127 20161 1/2 size 20162 full size F-856 CABINET COMMON COMPONENTS...
Page 26
COUNTERTOP FRYER F-85 and BUILT-IN FRYER F-856 *REMOVE JUMPER WHEN TEMP LIGHT TEMP LIGHT TROUBLE TROUBLE EXTERNAL CONTROL IS (AMBER) (AMBER) LIGHT (RED) LIGHT (RED) USED. RIGHT LEFT IMPORTANT: HEATING HEATING DO NOT CONNECT ANY ELEMENT ELEMENT POWER TO FLAME SENSOR TERMINAL CONTROL CONTROL...
Page 27
COUNTERTOP FRYER F-85 and BUILT-IN FRYER F-856 HEATING ELEMENT TEMP LIGHT JUMPER POWER SWITCH EXTERNAL CONTROL CONTACTOR CONTROL T'STAT HI-LIMIT T'STAT CONTACTOR TROUBLE LIGHT HEATING ELEMENT TEMP LIGHT HI-LIMIT T'STAT CONTROL T'STAT TROUBLE LIGHT CONTACTOR CONTACTOR WIRING SCHEMATIC F-85 and F-856 - 3 PHASE...
