BT9240
Universal dvLED Wall Mount
Installation Guide
Universal design for wall mounting
■
latching dvLED cabinets
Mounts cabinets 60mm (2.36") from wall
■
Height & depth adjustment: +/-5mm (0.2")
■
Keyhole mounting for easy assembly
■
Simple 'Hook-on' installation
■
www.btechavmounts.com
Micro
Adjustment
Advertisement
Related Manuals for BTECH XPRESS BT9240
Summary of Contents for BTECH XPRESS BT9240
- Page 1 BT9240 Universal dvLED Wall Mount Installation Guide Universal design for wall mounting ■ latching dvLED cabinets Mounts cabinets 60mm (2.36") from wall ■ Micro Height & depth adjustment: +/-5mm (0.2") ■ Adjustment Keyhole mounting for easy assembly ■ Simple ‘Hook-on’ installation ■...
-
Page 2: Installation Safety Instructions
Contents BT9240 Installation Safety Notes Parts List Installation Instructions Product Dimensions B-Tech Contact Details Installation Safety Instructions Caution: This mount is intended for use only with the maximum weights indicated. Use with equipment heavier than the maximum indicated may result in instability causing possible injury. Do not attempt to install this product until all instructions and warnings have been read and properly understood. - Page 3 B-Tech AV Mounts 建议本产品由专业AV安装人员或其他合格人员安装。 B-Tech AV Mounts 及它的代理商、经销商不对由于 不恰当的安装而造成的损失或伤害负责。 本产品必须安装在合适的架构上，并仅用于不超过所标示的最大承重。 Společnost B-Tech AV Mounts doporučuje provést instalaci tohoto produktu instalátora AV či jinak způsobilé osoby. Společnost B-Tech AV Mounts, její distributoři a prodejci nenesou prostřednictvím odborného odpov ědnost za škody nebo zranění...
- Page 4 BT9240 Parts List Please keep this for future reference The information contained in this drawing is the sole property of B-Tech AV Mounts Corporation Limited, reproduction in part or whole without the written permission of B-Tech AV Mounts Corporation Limited is prohibited. 257mm 10.12in 560mm 22.05in Excluding End Cap...
- Page 5 Item Part number Description BT8392 Mounting Rail Rail End Cap BT8392-EXT Rail Joiners BT8392-WFK7 Wall Bracket Insert Nut M8 x 12mm Hex Screw M8 x 50mm Coach Screw M8 Washer Wall Plug 5AF Hex Key BT9240-BOB Adjustable Bobbin BT9240-IMC Interface Mounting Connector BT9240-BRS1 Bottom Row Spacer M6 x 20mm Cap Head Screw...
-
Page 6: Typical Installation
Typical Installation dvLED Cabinet BT9240-BOB Bobbin Screw BT9240-IMC Interface Connector BT8392 Rail BT8392-WFK7 Wall Plate BT9240-BRS1 Bottom Row Spacer Installation Instructions Optional To increase the length of the rail, use item 3 to join 2x item 1 together. Insert item 3 halfway into each channel on the front and back of item 1 and loosley fix in place (do not overtighten). - Page 7 Note: Refer to the Techincal Drawing (item 21) for marking the first mounting hole and installation dimensions. Mount Wall Plates To The Wall i. Using the technical drawing as a guide, mark up the position of first wall plate and drill the fixing holes in the wall. ii.
- Page 8 Option 1 - Fit Rail to Wall Plates See Option 2 for mounting the wall bracket first iii. Refering to the Techincal Drawing (item 21) for rail positioning, attach item 1 to item 4 using items 5 & 6. Max Distance: 2000mm [78.75in] iv.
- Page 9 Alternative Rail Mounting Option 2 - Mount Wall Plates To The Wall Before Fitting Rail Max Distance: 2 iii. Hook item 4 onto item 7. iv. Fix items 7 & 8 into the bottom holes on item 4, and fully tighten the top screws. stance: 2000mm [78.75in] Wall Max Distance: 2000mm [78.75in]...
- Page 10 Rail Alignment - Height Adjustment i. Use a spirit or laser level and the height adjustment screw on item 4 to align rails vertically. Level the bottom rail first, then fit the next row up. Note: Use adjustment guides to help align rails. Height Adjustment Level ii.
- Page 11 Rail Alignment - Depth Adjustment iii. Once all rails (item 1) are in place, use a spirit / laser level or plumb-line and the depth adjustment screws on item 4 to align rails horizontally. Note: Re-check all dimensions between rails are accurate before mounting cabinets.
- Page 12 dvLED Assembly Sequence *Example 4x4 Installation shown Warning! The sequence of assembly should be: Bottom row - left to right, then Upper rows - left to right. Rear View...
- Page 13 Assemble dvLED Cabinets Latching 1x2 Process dvLED Cabinet Start facing the front - left to right, bottom row first. i. Connect the two cabinets securely together using connecting screws or locking handles. Important: Ensure cabinets are aligned flush at all edges, especially the front face. Latching dvLED Cabinet Warning!
- Page 14 Clip Interface Mounting Connector Onto Bobbins iii. Slide item 12 upward and “click” onto the dvLED Cabinet neck of item 11. ‘Bobbin - collar neck “Click“ Self-hold design Note: After item 12 has been clicked onto item 11, the connector should automatically stay vertical and ready to hook onto the mounting rail.
- Page 15 Add Bottom Row Spacers i. Lift and lower the cabinet assembly onto the bottom left hand side (from front) of item 1. Note: Ensure item 12 is in the unlocked position when hanging cabinets ii. Adjust to cabinets to desired position by lightly lifting and sliding.
- Page 16 Bottom Row Spacer - Fixed Stand Off Option B - Wall Screw See Option A for installation without using wall fixings. iv: Mark position on the wall, where the bottom row spacer (item 13) sits on the cabinet. X1 distance v: Remove cabinets and drill marked position.
- Page 17 Mount Bottom Row Of Cabinets dvLED Cabinet i. Using items 12 & 13, hook the first set of cabinets Wall onto items 1 & 18, once the cabinets are in of single position, lock item 12 and tighten item 18. Locked position Row 4 Row 4...
- Page 18 Assemble Bottom Row Of Cabinets i. Using item 11, fit 2x item 12 into the top fixing holes of the remaining bottom row of cabinets and 1x item 13 to the bottom left hole on each set of cabinets. M6 / M8 / M10 Hook Bottom Row Of Cabinets Onto Wall ii.
- Page 19 Rear View Rear View iii. Lock cabinets together horizontally using locking screws/ locking handles. Then square vertically. Hook Remaining Row Of Cabinets Assemble 3rd & 4th set of cabinets*. iv. Hook on the next set of 1x2 cabinets to the left side and connect the Locked position cabinets of 1x2 securely together.
- Page 20 Assemble Upper Row Of Cabinets i. Using item 11, fit item 12 to the top fixing holes of the next row cabinets. Note: Bottom row spacers (item 13) are not required for the upper rows of cabinets. No BRS1, just 2x IMC's, 2x B-Tech Bobbins for 5,6,7,8.
- Page 21 iii. Assemble 6th, 7th & 8th Sets of Cabinets Follow steps shown in Step 5. Upper Row Bottom Row Note: For odd numbered rows, add 1 row of single cabinets, to the top row. Bottom row spacers are not required. Row 5 Row 5 Row 4...
- Page 22 BT9240 Dimensions Please keep this for future reference 24mm 0.95in 8.4mm 0.33in Assembled Side View 60mm [2.36in] 24mm 0.95in 8.4mm 0.33in (+/- 5mm Depth Adjustment) 58mm 2.28in 60mm [2.36in] 60mm [2.36in] (+/- 5mm Depth Adjustment) (+/- 5mm Depth Adjustment) 58mm 2.28in 150mm 5.91in 50mm 1.97in...
- Page 23 BT9240 Dimensions 150mm 5.91in Please keep this for future reference BT8392-WFK7 - Wall Fixing Bracket Rear View Front View 8.4mm 0.331in 18.5mm 0.73in 24mm 0.95in Centre Line 8.4mm 0.33in 60mm [2.36in] (+/- 5mm Depth Adjustment) 58mm 2.28in 8.4mm 0.33in 120mm 4.72in 150mm 5.91in 50mm 1.97in BT9240-BRS1 - Bottom Row Spacer...
- Page 24 Any reproduction, retransmission or republication of any part of this manual is strictly prohibited, unless prior written permission has been granted by B-Tech AV Mounts Corporation Ltd. Photographs are for illustrative purposes only. E&OE Made in the P.R.C. AMA-BT9240-V1-0125-BTECH www.btechavmounts.com/bt9240...
