BT7372
DESK MOUNT WITH SINGLE ARM
INSTALLATION GUIDE & PARTS LIST
This Pack Contains 1 Desk Mount
PLEASE KEEP THIS FOR FUTURE REFERENCE
Installation Safety Notes.....................................................................................................................2
Parts List.............................................................................................................................................4
Installation Instructions.......................................................................................................................6
Product Dimensions..........................................................................................................................15
B-Tech Contact Details.....................................................................................................................16
INSTALLATION TOOLS REQUIRED
Crosshead
screwdriver
B-TECH AUDIO VIDEO MOUNTS
FEATURES
●
Designed for screens up to 24" (61cm) / 9kg (20lbs)
●
Fits screens with VESA mounting patterns:
75 x 75mm and 100 x 100mm
●
Optional desk clamp and grommet included
●
Easy tilt adjustment +/-40° tilt
●
Maximum extension is 285mm (11.2")
●
Features two swivel points: 360° at pole, 360° at pivot
and 180° at interface
●
Simple installation with all mounting hardware included
CONTENTS
2.5mm Hex Key
(Supplied)
www.btechavmounts.com
4mm Hex Key
(Supplied)

Advertisement

loading
Need help?

Need help?

Do you have a question about the BT7372 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for BTECH BT7372

Summary of Contents for BTECH BT7372

  • Page 1: Table Of Contents

    BT7372 DESK MOUNT WITH SINGLE ARM INSTALLATION GUIDE & PARTS LIST This Pack Contains 1 Desk Mount PLEASE KEEP THIS FOR FUTURE REFERENCE FEATURES ● Designed for screens up to 24" (61cm) / 9kg (20lbs) ● Fits screens with VESA mounting patterns: 75 x 75mm and 100 x 100mm ●...

  • Page 2: Installation Safety Notes

    INSTALLATION SAFETY INSTRUCTIONS CAUTION: This mount is intended for use only with the maximum weights indicated. Use with flat screens heavier than the maximum indicated may result in instability causing possible injury. Do not attempt to install this product until all instructions and warnings have been read and properly understood.
  • Page 3 Společnost B-Tech International Ltd. doporučuje provést instalaci tohoto produktu prostřednictvím odborného instalátora AV či jinak způsobilé osoby. Společnost B-Tech International Ltd, její distributoři a prodejci nenesou odpovědnost za škody nebo zranění způsobená nevhodnou instalací. Tento výrobek je nutno umístit do vhodné konstrukce a používat jen po uvedenou maximální...

  • Page 4: Parts List

    BT7372 PARTS LIST GROMMET CLAMP Suitable for loads up to 9kg (20lbs)
  • Page 5 PART NAME INTERFACE ASSEMBLY HEIGHT ADJUSTMENT COLLAR POLE ASSEMBLY TOP CLAMP CLAMP PLATE BOTTOM CLAMP SHORT HANDWHEEL M6 x 15mm HEX SCREW M5 x 5mm GRUB SCREW M6 x 8mm HEX SCREW M10 E-RING M10 METAL WASHER M10 NUT GROMMET PLATE LONG HANDWHEEL POLE END CAP CABLE CLIP...

  • Page 6: Installation Instructions

    INSTALLATION INSTRUCTIONS Choose a preferred mounting method. i. Clamp (page 6) ii. Grommet (page 8) i. Desk clamp option. Max 70mm (2.8")
  • Page 7 Attach the foam pads to the underside of the clamp base. Place the mount over edge of the desk and tighten the short handwheel. DESKTOP...
  • Page 8 ii. Grommet Clamp Max 95mm (3.7")
  • Page 9 Remove the desk clamp and attach the grommet plate. Then attach the foam pads onto the grommet plate. Place the mount over the cable management hole and screw the handwheel into the grommet plate, then tighten the nut to clamp the desk. DESKTOP...
  • Page 10 Attach the interface plate to the flat screen. FLAT SCREEN To lock height of adjustment collar, hold the top of the collar and rotate the lower part of the adjustment collar. LOCK COLLAR...
  • Page 11 Slide the flat screen and arms onto the pole, adjust height, then tighten the grub screw. FLAT SCREEN iii. LOCK COLLAR UNLOCK COLLAR...
  • Page 12 OPTIONAL : Cable Management. Insert the cable into the cable management slots on the underside of the arm. WARNING: Ensure arm is fully extended before connecting cables. FLAT SCREEN CABLE CABLE CABLE CAUTION: Ensure there is adequate cable slack for movement of the screen, and that cables will not be pinched when the mount is closed.
  • Page 13 To increase tilt resistance, tighten part 9. +/-40° If this does not hold the screen at the required tilt, remove the flat screen from the interface. Then remove plastic nut cover and tighten the M8 nyloc nut.
  • Page 14 Tilt and swivel. 360° 360° +/-90° FLAT SCREEN...

  • Page 15: Product Dimensions

    BT7372 PRODUCT DIMENSIONS 285mm 11.2" 305mm 12" 35mm 1.4" INTERFACE PLATE DESK CLAMP, GROMMET & BASE 169mm 6.7" 100mm 3.9" 75mm 3" 83.7mm 72mm 3.3" 2.8" 120mm 4.7" THESE INSTRUCTIONS ARE INTENDED AS A GUIDE ONLY AND B-TECH ACCEPTS NO...

  • Page 16: B-Tech Contact Details
