REG DESIGN NO: 3007645
PATENT NO: 1546599
US PATENT NO: 7523906
Installation Safety Instructions............................................................................................................2
Parts List.............................................................................................................................................4
Installation Instructions.......................................................................................................................6
Product Dimensions..........................................................................................................................11
B-Tech Contact Details.....................................................................................................................12
INSTALLATION TOOLS REQUIRED
Crosshead /
Flathead screwdriver
B-TECH AUDIO VIDEO MOUNTS
BT33
HOME CINEMA SPEAKER WALL MOUNT
INSTALLATION GUIDE & PARTS LIST
This Pack Contains 1 Speaker Mount
PLEASE KEEP THIS FOR FUTURE REFERENCE
CONTENTS
6mm (1/4") masonry bit
Drill
or 3mm (1/8") wood bit
FEATURES
● Designed for small home cinema speakers weighing
up to 5kg (11lbs)
● Mounts speaker only 72mm (2.8") from wall
● Suitable for single point, dual point and keyhole fixings
● Distance between dual point fixings:
51 – 67mm (2" – 2.6")
● Suitable for speakers using M5, M6, UNC ¼" &
Wood Screws
● Simple installation with all mounting hardware included
Pencil
Stud finder
Level
(optional)
(optional)
Advertisement
Related Manuals for BTECH BT33
Summary of Contents for BTECH BT33
- Page 1 BT33 HOME CINEMA SPEAKER WALL MOUNT INSTALLATION GUIDE & PARTS LIST This Pack Contains 1 Speaker Mount PLEASE KEEP THIS FOR FUTURE REFERENCE FEATURES ● Designed for small home cinema speakers weighing up to 5kg (11lbs) ● Mounts speaker only 72mm (2.8”) from wall ●...
- Page 2 BT33 PARTS LIST Suitable for loads up to 5Kg (11lbs)
- Page 3 WALL FIXING KIT (FOR FIXING MOUNT TO WALL) PART NAME TOP BALL CLAMP WALL PLATE BOTTOM BALL CLAMP BALL INTERFACE ADAPTOR INTERFACE M6 x 12mm SCREW (FOR PART 5) M6 x 40mm SCREW M6 METAL WASHER (FOR PART 7) SPEAKER INTERFACE KIT M3 x 8mm SCREW (FOR ATTACHING MOUNT TO BACK OF SPEAKER)
-
Page 4: Installation Instructions
THIS MOUNT MUST BE DISASSEMBLED PRIOR TO INSTALLATION INSTALLATION INSTRUCTIONS Choose one of the four fixing methods shown that suits your speaker fixings. Attach part 4 to the speaker using screws A, B, C or D, or for keyhole fixings use screw A and part E. i. - Page 5 iii. Keyhole insert. iv. No insert.
- Page 6 Attach parts 1 & 3 to part 4 using parts 7 & 8. ASSEMBLED VIEW...
- Page 7 Fix part 2 to the wall using one of the two methods shown. i. Brick / concrete walls. 6mm (1/4") masonry bit ii. Wood / wood stud walls. 3mm (1/8") wood bit STUD FINDER (Optional)
- Page 8 Secure the mount to part 2 Hook the mount onto part 2. using part 9. WALL To adjust the tilt and swivel, slightly loosen part 7 then adjust the speaker position. Finally, retighten part 7 to fix the speaker position. Tilt &...
- Page 9 BT33 PRODUCT DIMENSIONS 72mm 41mm 2.8" 1.6" 79mm 51mm 3.1" 2" 67mm 2.6" WALL PLATE 0.3" 15mm 0.6" 0.2" 88mm 34mm 3.5" 1.3" These instructions are intended as a guide only and B-Tech accepts no liability for the accuracy of the information contained in this document.
