Evie TV Unit
Two person
assembly
Range Name : EVIE
Box 1 Dimensions : W162xD54xH18.5cm
Product Dimension : W147xD40xH61cm
P-1-12
V-2.0
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for DUSK Evie TV Unit
Summary of Contents for DUSK Evie TV Unit
- Page 1 DUSK.COM Range Name : EVIE Box 1 Dimensions : W162xD54xH18.5cm LIVING I BEDROOM I DINING Product Dimension : W147xD40xH61cm Evie TV Unit Up to 30 minutes Two person assembly time assembly This product is intended for domestic use only,not for commercial purposes.
- Page 2 IMPORTANT ASSEMBLY TIP Before you begin, it's best to identify all of the parts and fittings to build your Evie TV Unit frame. We advise laying these out on the floor to check you have everything, and to familiarise yourself with all of the parts and fittings before building.
-
Page 3: Parts List
Parts list P-3-12 V-2.0... - Page 4 Parts list Before you begin building your Evie TV Unit,please take a moment to read through the instructions and make surethat you have all the relevant parts listed on the parts check list. Part Number Part Description Quantity Box No...
- Page 5 Fittings Please check you have all the fittings listed below with your product in box 1. M6*35mm Bolt Ø15x9.5mm Cam Lock Ø8x30mm Dowel M3.5*12mm Screw M3*14mm Screw 12pcs+1pc extra 12pcs+1pc extra 20pcs+2pcs extra 6pcs 16pcs+1pc extra 3mm Allen Key 15x9mm Plastic Buckle M4*35mm Screw M5*40mm Screw Handle...
- Page 6 1.Attach parts to panels. A x 12 K x 2 L x 2 E x 4 P x 2 M6*35mm Bolt M4*14mm Screw Wall Bracket M3*14mm Screw Pusher 12pcs 2pcs 2pcs 4pcs 2pcs 2.Attach shelf panel to middle panels. B x 4 C x 4 Ø8x30mm Dowel Ø15x9.5mm Cam Lock...
- Page 7 3.Attach panels to Top. B x 8 C x 8 Ø8x30mm Dowel Ø15x9.5mm Cam Lock 8pcs 8pcs P-7-12 V-2.0...
- Page 8 4.Assemble back panels. P-8-12 V-2.0...
- Page 9 5.Attach bottom panel to the frame. G x 12 C x 8 3mm Allen Key Ø8x30mm Dowel M5*40mm Screw 8pcs 12pcs P-9-12 V-2.0...
- Page 10 6.Attach legs to the frame. K x 20 M4*14mm Screw 20pcs 7.Attach plastic backles. E x 12 I x 12 M3*14mm Screw 15x9mm Plastic Buckle 12pcs 12pcs P-10-12 V-2.0...
- Page 11 8.Attach hinges to the door. Q x 8 O x 4 D x 6 M x 2 J x 2 M4*14mm Screw M3.5*12mm Screw Handle Hinge Washer 6pcs 2pcs 4pcs 2pcs 8pcs 9.Attach door panels to the frame. Q x 16 M4*14mm Screw 16pcs P-11-12...
- Page 12 10.Fix the L-shaped Bracket to the wall. Ø6x30mm Wall Plug M4*35mm Screw 2pcs 2pcs P-12-12 V-2.0...
