- Page 1 Range Name:EVIE Box1 dimensions:L134.5xW53xH13(cm) Evie Desk P-1/12...
- Page 2 Before you begin , it's best to identify all of the parts and fittings to build your table frame. We advise laying these out on the clean and flat floor to check you have everything , and to familiarise yourself with all of the parts and fittings before building. We recommend that you assemble the table in the room you'd like it to be located.
- Page 3 Parts List Before you begin building your Evie Desk , please take a moment to read through the instructions and make sure that you have all the relevant parts listed on the parts check list. Part Number Part Number Quantity...
- Page 4 Fittings Please check you have all the fittings listed below with your product M6x35 M6x44 Φ15x11mm Φ8x30mm M3.5x14mm Screw M3x12mm Screw CAM Lock Screw CAM Lock Screw CAM Lock Wooden Dowel 6pcs+1pc extra 14pcs+1pc extra 12pcs +1pc extra 8pcs+1pc extra 24pcs+2pcs extra 4pcs 15x9mm...
- Page 5 Slides Must Be Separated Before Assembly. After Separated, Set Aside Until Needed for Assembly. Pay attention when connecting ! The sliding module must be at the front end. STEP 1 : Extend Slide Mount Lever STEP 2: Push Lever UP Push lever for the left of drawer , press the lever for the right of drawer .
- Page 6 1. Attach parts to the Top Panel. M6x35 76x32mm M4x12mm Screw CAM Lock Screw L-shaped Bracket 6pcs 2pcs 2pcs 2. Attach the Side Panels to the Top Panel . Φ15x11mm Φ8x30mm CAM Lock Wooden Dowel P-6/12 6pcs 6pcs...
- Page 7 3.Attach parts to the Left Side Panel ,Right Side Panel and Middle Panel. M3.5x14mm Screw Slide-R1 8pcs 4pcs 4. Attach the Back Panels into the Frame. P-7/12...
- Page 8 5. Attach the Bottom Panel to the Frame. Φ8x30mm M7x50mm Screw 4mm Allen Key Wooden Dowel 6pcs 6pcs 6. Attach the Legs to the Leg Supports. M6x35mm Bolt 4mm Allen Key M6 Adjustable Foot P-8/12 4pcs 6pcs...
- Page 9 7. Attach the Legs to the Frame. 100% M6x25mm Bolt 4mm Allen Key 10pcs 8. Attach the Metal support to the frame and Lock the Bolts tightly. 100% 100% M6x12mm Bolt 4mm Allen Key P-9/12 4pcs...
- Page 10 9. Attach the Plastic Buckles. 15x9mm M3.5x14mm Screw Plastic Buckle 8pcs 8pcs 10.Assemble the drawer. M6x44 M3x12mm Screw Handle M3.5x35mm Screw CAM Lock Screw P-10/12 2pcs 8pcs 8pcs 4pcs...
- Page 11 11. Slide in the Drawer Base, and attach the Drawer Front by locking the CAM Locks tightly. 100% Φ15x11mm Φ20mm Cover CAM Lock 8pcs 8pcs 12. Attach parts to the drawer. M3.5x14mm Screw Slide-R2 P-11/12 8pcs 4pcs...
- Page 12 13. Assemble the drawers in the desk. 14. Fix the L-Shaped Bracket to the wall. Φ8mm Expansion Tube 2pcs M4x40mm Screw P-12/12 2pcs...
