- Page 1 Range Name: Evie Box dimensions: L190xW60xH16(cm) Evie Shelving Unit Up to 25 minutes Two person assembly time assembly This product is intended for domestic use only, not for commercial purposes. P-1/11...
-
Page 2: Safety And Care
IMPORTANT ASSEMBLY TIP Before you begin, it's best to identify all of the parts and fittings to build your frame. Shelving Unit We advise laying these out on the clean and flat floor to check you have everything, and to familiarise yourself with all of the parts and fittings before building. -
Page 3: Parts List
Parts list Before you begin building your Evie Shelving Unit, please take a moment to read through the instructions and make sure that you have all the relevant parts listed on the parts check list. Part Number Part Description Quantity... - Page 4 Fittings Please check you have all the fittings listed below with your product. Wall Anchor Wall Bracket Attaching the Back Trim to the Shelf. P-4/11...
- Page 5 Attaching the to the Middle Panel and Bottom Panel. Attaching the Bottom Trim to the Middle Panel. P-5/11...
- Page 6 Attaching the to the Middle Panel. Attaching the Back Panel to the Middle Panel. P-6/11...
- Page 7 Attaching the to the Left Side Panel. Attaching the to the Right Side Panel. P-7/11...
- Page 8 Attaching the Side Panels, Trims, Shelves, Middle Panel and the Back Panel. Attaching the Top Panel to the Side Panels. Wall Bracket P-8/11...
- Page 9 Side Panels and the Back Panel Attaching the Bottom Panel to the Attaching the legs to the Bottom Panel. P-9/11...
- Page 10 Attaching the and the to the Doors. Attaching the Doors to the Side Panels. P-10/11...
- Page 11 Fix the Wall Bracket to the wall WALL Wall Anchor P-11/11...
