- Page 1 LE4050M Cellular Alarm Communicator Installation and Operation Manual Doc. No. 06002 V 1.3 02/2024 © M2M Services, 1 Kukush Str, building M8, Sofia 1309, Bulgaria www.m2mservices.com...
-
Page 2: Table Of Contents
LE4050M Installation and Operation Manual Table of Contents About this document ..............................3 Product Description ............................... 5 Main Features ................................5 Specifications ................................6 Wiring the communicator to the DSC Power Series Neo alarm panels ..............7 DSC PowerSeries NEO Panel Programming ......................... 7 Wiring the communicator to the DSC Power Series alarm panels ................ -
Page 3: About This Document
M2M Services will not take any responsibility regarding personal, property or revenue loss while using the Device. M2M Services responsibility according to local laws does not exceed the value of the purchased system. M2M Services is not affiliated with GSM operators providing cellular services, therefore is not responsible for network services, coverage or its operation. -
Page 4: Safety Instructions
Client shall have no claim against M2M Services for termination of contracts, indemnification, compensation for loss of customers, loss of profits, prospective profits, distribution rights, market share, goodwill, investments made or any similar losses that may result from any faults in the operation of the Device and the services provided by M2M Services. -
Page 5: Product Description
LE4050M Installation and Operation Manual Product Description The LE4050M is a digital serial port alarm communicator. It represents the latest communication technology for the security industry. The communicator is equipped with dual-SIM supporting multiple carriers per country. This communication solution is a complete communication platform for data transfer from alarm systems at remote sites to Central Monitoring Stations (CMS). -
Page 6: Specifications
LE4050M Installation and Operation Manual Specifications Characteristics Technical Specifications Supply Voltage +12 to +15 VDC Consumption Standby 20 mA Peak 200mA Frequency LTE CAT-M1 700/850/1700/1900/2100 MHz Dimensions 1,73”x3.58” Interface RS232 Serial Port Weight 1.5oz without antenna Environmental Operating temperature: 0°C to 49°C (32°F to 120°F) Humidity: 0 to 85% relative humidity, non-condensing Proprietary Content, v.1.3 02/2024... -
Page 7: Wiring The Communicator To The Dsc Power Series Neo Alarm Panels
▪ For Dry/Indoor use only. ▪ The LE4050M communicator mounted into the box of the DSC PowerSeries NEO alarm panel. Figure 1: Wiring Diagram for DSC Power Series Neo Alarm Panels PC Link Connect this terminal to PC Link 2 of the DSC PowerSeries NEO Panel, using... -
Page 8: Wiring The Communicator To The Dsc Power Series Alarm Panels
For Dry/Indoor use only. ▪ The LE4050M communicator is equipped with 2 Terminals for power supply and a 5 PIN connector that should be wired and mounted into the box of the DSC Power Series alarm panel. Figure 2: Wiring Diagram for DSC Power Series Alarm Panels Connect this terminal to AUX + of the DSC Power Series alarm panel. -
Page 9: Dsc Powerseries Panel Programming
LE4050M Installation and Operation Manual DSC PowerSeries Panel Programming Configure the following sections on the alarm panel: ✓ Section 301 >> Program HEX digits DCAA as a telephone number Verify that the remaining digits to the end are “F”. Leading digit D is usually programmed by default and LED keyboards usually do not display it. -
Page 10: Mounting The Communicators
LE4050M Installation and Operation Manual Mounting the Communicators This communicator comes together with 4-PIN and additional 1-PIN serial cable, external antenna, and mounting standoffs. The device must be installed within a DSC Power Series/ Power Series NEO metal enclosure. The communicator has mounting openings matching the panel openings. -
Page 11: Led Indicator Status
LE4050M Installation and Operation Manual Led Indicator Status LED Status Indication Action The LED is Off The unit is not connected to the panel. Verify the wiring, refer to the wiring diagram. The power from the panel is out. Measure the AUX output of the panel.
