The length and width of the upper and lower bunk mattress and foundation are as follows :
Size
Twin
Full
Ensure thickness of upper and lower mattress and foundation combined does not exceed 9 ½"
and that the mattress is at least 5" below upper edge of guardrails.
Replacement parts, including additional guardrails, may be obtained from any
!
Follow the information on the warnings appearing on the upper bunk end structure
( 1 )
and on the carton. Do not remove warning label from bed.
Always use the recommended size mattresses or mattress support, or both,
( 2 )
to help prevent the likehood of entrapment or falls.
( 3 )
Surface of mattress must be at least 5 in. (127mm) below the upper edge of guardrails.
( 4 )
Do not allow children under 6 years of age to use the upper bunk.
( 5 )
Periodically check and ensure that the guardrail, ladder, and other component are
in their proper position, free from damage, and that all connectors are tight.
( 6 )
Do not allow horseplay on or under the bed and prohibit jumping on the bed.
Always use ladder for entering or leaving upper bunk.
( 7 )
( 8 )
Do not use substitute parts. Contact the manufacturer or dealer for replacement parts.
( 9 )
Use of a night light may provide added safety precaution for a child using the upper bunk.
(10)
Always use guardrails on both long sides of the upper bunk. If the bunk bed will be placed
next to the wall, the guardrail that runs the full length of the bed should be placed against
the wall to prevent entrapment between the bed and the wall.
(11)
The use of water or sleep flotation mattresses is prohibited.
(12)
STRANGULATION HAZARD : Never attach or hang items to any part of the bunk bed
that are not designed for use with the bed; for example, but not limited to, hooks, belts
and jump ropes.
(13)
Keep these instructions for future reference.
Size of Mattress and Foundation
Length
74"- 75"
74"- 75"
You must use only this size mattress.
This bunk bed uses a slat kit for mattress foundation.
Replacement Parts
afifurnishings dealer
SAFETY WARNINGS
Width
37 ½"- 38 ½"
52"- 53"
Thickness
9 ½" max
9 ½" max
!
Page 1 of 13
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for AFi BK-SCBS-COL
Summary of Contents for AFi BK-SCBS-COL
- Page 1 Size of Mattress and Foundation The length and width of the upper and lower bunk mattress and foundation are as follows : Size Length Width Thickness Twin 74”- 75” 37 ½”- 38 ½” 9 ½” max Full 74”- 75” 52”- 53” 9 ½”...
- Page 2 Please note that you will require a phillips head screwdriver and an allen wrench. ATTENTION! If you receive a damaged or defective item, please contact afifurnishings at customerservice@afifurnishings.com or 1-800-955-3726 PO : CODE ITEM Adult assembly BK-SCBS-COL B-5222X BK-SCDR-COL B-5232X BK-SCDR-COL B-5262X BK-SCGR-COL...
- Page 3 PARTS LIST TWIN OVER FULL SHOWN HARDWARE A UPPER PANEL B UPPER PANEL B-5515X LEFT, RIGHT END CAP B-5505X END GUARD RAIL HARDWARE BACK GUARD RAIL SIDE GUARD RAIL HAND GUARD RAIL BOTTOM SHELF B-522X2 LOWER PANEL B-552 X B-555 X FRONT, BACK GUARDRAIL B-54X 0 SIDE RAILS...
- Page 4 STEP 1 Attach the side rails (15) to the A upper panel (02) and B upper panel (03), using JCB M6 X 3 ½” (A), and barrel nut (F). Tighten with the Allen wrench (P). Twin upper panel shown. Full over Full bunk use Full upper panel. JCB M6 X 3 ½”...
- Page 5 Attach the guard rails (14) to the upper panel assemblies using JCB M6 X 3 ½” (A), STEP 3 and barrel nut (F). Tighten with the Allen wrench (P). JCB M6 X 3 ½” Barrel nut Allen wrench Adult assembly Attach the end guard rail (05) to the end caps (04), using wood dowels (I) JCB M6 X 2 3/8”(C) and STEP 4 barrel nut (F).
- Page 6 Attach the end guard rail assemblies to the upper panel assemblies as shown below, STEP 5 using wood screw (J), tighten with the Phillips head screwdriver. ( Customer supplied ) INSIDE VIEW Adult assembly ZOOM IN WOOD SCREW 1 1/4” Note : Screw holes on end caps should face inside section.
- Page 7 Lay the full slat kit (23) onto the bed. Fix in place using wood screws provided in the slat kit box. STEP 7 FOR SLAT KIT ASSEMBLY follow assembly instructions included with slat kit. Adult assembly Customer supplied Phillips screwdriver Full size shown Twin lower panel uses Twin slat kit Insert metal pins (G) into the holes on top of the lower panels.
- Page 8 STEP 9 Insert wooden dowels (I) into the shelves (09)(10)(11) as shown below. WOODEN DOWEL Adult assembly STEP 10 Insert wooden dowels (I) into the bottom drawer (17) and middle drawer (20) as shown below. Adult assembly Page 8 of 13...
- Page 9 Attach the bottom shelf (09) to the bottom drawer (17) and back panel (12). Using Allen screw STEP 11 M6 X 2” (C). Tighten with Allen wrench (P). M6 X 2” (50mm) Allen wrench Adult assembly Attach the middle shelf (10) to the middle drawer (20) and back panel (12). Using Allen screw STEP 12 M6 X 2”...
- Page 10 Attach the top shelf (11) to the middle drawer (20) and back panel (12). Using Allen screw STEP 13 M6 X 2” (C). Tighten with Allen wrench (P). M6 X 2” (50mm) Allen wrench Adult assembly Attach the top drawer (16) as shown below. Using wood dowels (I) and Allen screw M6 X 2” (C). STEP 14 Tighten with Allen wrench (P).
- Page 11 Attach back guard rail (06) as shown below. Using Allen screw M6 X 3 1/8” (E). STEP 15 Tighten with Allen wrench (P). M6 X 3 1/8” (80mm) Allen wrench Adult assembly Attach side guard rail (07) as shown below. Using Allen screw M6 X 1 5/8” (D). STEP 16 Tighten with Allen wrench (P).
- Page 12 Attach hand guard rail (08) as shown below. Using Allen screw M6 X 3 1/8” (E) and M6 X 1 5/8” (D). STEP 17 Tighten with Allen wrench (P). M6 X 3 1/8” (80mm) M6 X 1 5/8” (40mm) Allen wrench Adult assembly Attach special block full (19) as shown below.
- Page 13 Move the bunk bed and staircase assemblies where you want to place them in the room. STEP 19 Attach staircase assembly to the bunk bed assembly as shown below. Using mini L bracket (L), wood screw D6 X 5/8” (K). Using flat bracket (M), wood screw D6 X 5/8” (K). Using L-Bracket (N), JCB M6 X 3/4”+ washer (B) and wood screw D6 X 5/8”...
- Page 14 TRUNDLE BED ASSEMBLY INSTRUCTIONS READY FULL Before assembling your Trundle bed, please read through these instructions carefully. Familiarize yourself with the different parts. ATTENTION! If you receive a damaged or defective item, please contact afifurnishings at customerservice@afifurnishings.com or 1-800-955-3726 Allen wrench Adult assembly CODE ITEM...
- Page 15 FULL PARTS LIST HARDWARE 1 BOX SIDE CROSS RAIL 2 PCS FRONT PANEL 1 PC CENTER CROSS RAIL 1 PC SLAT KIT 2 SET FRONT RAIL 1 PC CENTER SLAT SUPPORT 2 PCS BACK RAIL 1 PC Step 1 Attach the side cross rails (05) and center cross rail (06) to the front and back rail (03)(04), using L bracket (C), JCB M6 X 1 5/8”(A).
- Page 16 FULL Attach the front panel (02) to the front rail as shown, using JCB M6 X 5/8” (B). Step 2 Tighten with the Allen wrench (D). Adult assembly JCB M6 X 5/8” Allen wrench Step 3 Attached center slat support(08) to the slat kit (07) as shown, using JCB M6 X 1 5/8” (A). Tighten with the Allen wrench (D).
- Page 17 FULL Step 4 Lay the slat kit (07) onto the rail assembly as shown, using JCB M6 X 1 5/8” (A). Tighten with the Allen wrench (D). Adult assembly JCB M6 X 1 5/8” Allen wrench Congratulations! Your Trundle bed is now ready for use. We recommend that you periodically check that all screws are tight and all parts are secure to ensure lasting safety.
