The length and width of the upper and lower bunk mattress and foundation are as follows :
Size
Twin
Full
Ensure thickness of upper and lower mattress and foundation combined does not exceed 9 ½"
and that the mattress is at least 5" below upper edge of guardrails.
Replacement parts, including additional guardrails, may be obtained from any
!
Follow the information on the warnings appearing on the upper bunk end structure
( 1 )
and on the carton. Do not remove warning label from bed.
Always use the recommended size mattresses or mattress support, or both,
( 2 )
to help prevent the likehood of entrapment or falls.
( 3 )
Surface of mattress must be at least 5 in. (127mm) below the upper edge of guardrails.
( 4 )
Do not allow children under 6 years of age to use the upper bunk.
( 5 )
Periodically check and ensure that the guardrail, ladder, and other component are
in their proper position, free from damage, and that all connectors are tight.
( 6 )
Do not allow horseplay on or under the bed and prohibit jumping on the bed.
Always use ladder for entering or leaving upper bunk.
( 7 )
( 8 )
Do not use substitute parts. Contact the manufacturer or dealer for replacement parts.
( 9 )
Use of a night light may provide added safety precaution for a child using the upper bunk.
(10)
Always use guardrails on both long sides of the upper bunk. If the bunk bed will be placed
next to the wall, the guardrail that runs the full length of the bed should be placed against
the wall to prevent entrapment between the bed and the wall.
(11)
The use of water or sleep flotation mattresses is prohibited.
(12)
STRANGULATION HAZARD : Never attach or hang items to any part of the bunk bed
that are not designed for use with the bed; for example, but not limited to, hooks, belts
and jump ropes.
(13)
Keep these instructions for future reference.
Size of Mattress and Foundation
Length
74"- 75"
74"- 75"
You must use only this size mattress.
This Bunk Bed uses a slat kit for mattress foundation.
Replacement Parts
afifurnishings dealer
SAFETY WARNINGS
Width
37 ½"- 38 ½"
52"- 53"
Thickness
9 ½" max
9 ½" max
!
Page 1 of 12
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for AFi BK-SCPL-WDL
Summary of Contents for AFi BK-SCPL-WDL
- Page 1 Size of Mattress and Foundation The length and width of the upper and lower bunk mattress and foundation are as follows : Size Length Width Thickness Twin 74”- 75” 37 ½”- 38 ½” 9 ½” max Full 74”- 75” 52”- 53” 9 ½”...
- Page 2 ATTENTION! If you receive a damaged or defective item, please contact afifurnishings at customerservice@afifurnishings.com or 1-800-955-3726 Adult assembly Allen wrench Customer supplied TWIN- TWIN Phillips screwdriver CODE ITEM TWIN OVER FULL SHOWN BK-SCPL-WDL B-5621X BK-SCPL-WDL B-5651X B-5611X BK-SCGR-WDL B-5411X BK-SCBS-WDL BK-SCBS-WDL B-5221X...
- Page 3 (TWIN - FULL) PARTS LIST HARDWARE A UPPER PANEL B UPPER PANEL LEFT, RIGHT END CAP 1 BOX SHORT GUARD RAIL LOWER PANEL 1 BOX FRONT, BACK GUARD RAIL 1 BOX LONG RAIL FLOOR STORAGE SIDE PANEL BOTTOM CROSS BRACE LONG SIDE PANEL BOOKSHELF SIDE PANEL FLOOR STORAGE TOP PANEL...
- Page 4 (TWIN - FULL) STEP Attach the long rails (0 ) to the upper panels (02) (03) , using JCB M6 X 3 ” (A) and barrel nut ( ). Tighten with the allen wrench ( ). JCB M6 X 3 ”...
- Page 5 (TWIN - FULL) Attach the front, back guard rails ( ) to the upper panel assemblies using a llen screw D . STEP Tighten with the allen wrench ( ). Adult assembly Allen crew ” Allen wrench STEP Insert wooden dowel (C) to the locator holes will receive C as shown below. Attach the short guard rail (0 )
- Page 6 (TWIN - FULL) Attach the short guard rail assemblies to the upper panel assemblies as shown below, using wood screw ( ), STEP tighten with the Phillips screwdriver. ( customer supplied ) INSIDE VIEW Adult assembly Note : Screw holes on end caps WOOD SCREW 1 1/4”...
- Page 7 (TWIN - FULL) Lay the full slat kit ( ) onto the bed. Fix in place using wood screws provided in the slat kit box. STEP FOR SLAT KIT ASSEMBLY follow assembly instructions included with slat kit. Adult assembly Customer supplied Phillips screwdriver Insert metal pins ( ) into the holes on top of the lower panels.
- Page 8 (TWIN - FULL) STEP Insert wooden dowel (C) to the locator holes will receive C as shown below. Adult assembly Wooden owel STEP Attach bottom cross brace (10) to the floor storage side panel(09)as shown below. Using allen screw (E). Tighten with allen wrench (M), but don’t fully tighten this yet.
- Page 9 (TWIN - FULL) Attach bookshelf side panel (12) to the floor storage side panel assemblies as shown below. Using allen screw (E). STEP But don’t fully tighten these yet. Leave them a bit loose to make fitting the back panel easier. Guide bookshelf back panel 1 (14) in carefully so that it won’t jump out of its grooves.
- Page 10 (TWIN - FULL) Attach bookshelf top panel 2 17 ) to the bookshelf side panel ( ) using allen screw E . ( ) Tighten STEP with allen wrench ( ). M But don’t fully tighten these yet. Leave them a bit loose to make fitting the back panel easier.
- Page 11 (TWIN - FULL) Attach side short guard rail 21 ) to the staircase bookshelf assemblies. U sing allen screw E . STEP Tighten with allen wrench (M). Adult assembly Allen crew 1 5/8” Allen wrench Attach hand guard rail 22 ) to the staircase bookshelf assemblies.
- Page 12 (TWIN - FULL) Move the bunk bed and staircase bookshelf assemblies where you want to place them in the room. STEP Attach staircase bookshelf assembly to the bunk bed assembly as shown below. Fix L bracket (J) to upper , lower bunk panel using wood screws as shown.
- Page 13 TRUNDLE BED ASSEMBLY INSTRUCTIONS READY FULL Before assembling your Trundle bed, please read through these instructions carefully. Familiarize yourself with the different parts. ATTENTION! If you receive a damaged or defective item, please contact afifurnishings at customerservice@afifurnishings.com or 1-800-955-3726 Allen wrench Adult assembly CODE ITEM...
- Page 14 FULL PARTS LIST HARDWARE 1 BOX SIDE CROSS RAIL 2 PCS FRONT PANEL 1 PC CENTER CROSS RAIL 1 PC SLAT KIT 2 SET FRONT RAIL 1 PC CENTER SLAT SUPPORT 2 PCS BACK RAIL 1 PC Step 1 Attach the side cross rails (05) and center cross rail (06) to the front and back rail (03)(04), using L bracket (C), JCB M6 X 1 5/8”(A).
- Page 15 FULL Attach the front panel (02) to the front rail as shown, using JCB M6 X 5/8” (B). Step 2 Tighten with the Allen wrench (D). Adult assembly JCB M6 X 5/8” Allen wrench Step 3 Attached center slat support(08) to the slat kit (07) as shown, using JCB M6 X 1 5/8” (A). Tighten with the Allen wrench (D).
- Page 16 FULL Step 4 Lay the slat kit (07) onto the rail assembly as shown, using JCB M6 X 1 5/8” (A). Tighten with the Allen wrench (D). Adult assembly JCB M6 X 1 5/8” Allen wrench Congratulations! Your Trundle bed is now ready for use. We recommend that you periodically check that all screws are tight and all parts are secure to ensure lasting safety.
